Philips 43PUT6801 - 10.16 ALC 715 G7789 LED board

EN 168QM16.3A LA 10.
Circuit Diagrams and PWB Layouts
2016-Jun-08
back to
div.table
10.16 ALC 715G7789 LED board
10-16-1 LOGO
20030 542 eps
LOGO
ALC ALC
2015-06-30
715G7789
LOGO
LOGO
3V3SB
CN301
CONN
1
2
3
4
56
Lighting LOGO
R301
2R2 1/16W 5%
R303
1K 1/16W 5%
3V3SB
LED302
CHIP LED WHITE 99-113UNC/2223010/TR8
2 1
LED301
CHIP LED WHITE 99-113UNC/2223010/TR8
2 1
R302
2R2 1/16W 5%
3V3SB
LOGO
Q301
BC847BW
