Philips 43PUT6801 - 7.3 DC;DC Converters

Circuit Descriptions
EN 41QM16.3A LA 7.
2016-Jun-08
Table 2-1
7.2.3 Connector overview
Table 7-1 Connector overview
7.3 DC/DC Converters
The on-board DC/DC converters deliver the following voltages
(depending on set execution):
• +3V5-SB, permanent voltage for the Stand-by Power
system and WIFI
• +3V3-STANDBY,voltage for IR/Key board
• +12V, input from the power supply for the panel
common(active mode)
• +12V, input from the power supply for LNB supply
• +3V3-EMMC, +V-EMMC-IO, voltage for EMMC when TV
on
• +1V5-DDR, +VREF-A2-DQ,, +VREF-A2-CA, voltage for
DDR
• TUNER_3V3, supply voltage for tuner
• +5V-SW, input intermediate supply voltage for USB Power
• +12V-AUDIO1 for the AUDIO AMP
• +3.3VA_T2, +1.2V_T2 voltage for Demodulator IC channel
decoder
• +3V3-WIFI,voltage for WIFI
Figures gives a graphical representation of the DC/DC
converters with its current consumptions :
Connector
Number
43" 47" 55" 65" 75"
CN9101 CN8601 CN9303 CN8101 CN9101 CN8101 CN9101 CN8601 CN9101 CN8103 CN8104
Description to SSB to panel to SSB to panel to SSB to panel to SSB to panel to SSB to panel to panel
Pin 161216121612161216 1114
1 DIM +VLED DIM +VLED DIM +VLED DIM VLED DIM VLED- VLED-
2 BL_O/F nc BL_O/F nc BL_O/F nc BL_O/F VLED BL_O/F VLED- VLED-
3 PS_ON -VLED-1 PS_ON -VLED1 PS_ON -VLED1 PS_ON -VLED2 PS_ON VLED- VLED-
4 3D_ON -VLED-1 3D_ON -VLED1 3D_ON -VLED1 3D_ON -VLED2 Scan BL EN
(A3D)
NG NG
5 GND -VLED-1 GND -VLED1 GND -VLED1 GND -VLED2 GND NG NG
6 GND nc GND nc GND nc GND -VLED2 GND +VLED- +VLED-
7 GND nc GND nc GND nc GND -VLED1 GND NG NG
8 GND -VLED-2 GND -VLED2 GND -VLED2 GND -VLED1 GND NG NG
9 +12VA -VLED-2 +12VA -VLED2 +12VA -VLED2 +12VA -VLED1 12V(Audio) +VLED- +VLED-
10 +12VA -VLED-2 +12VA -VLED2 +12VA -VLED2 +12VA -VLED1 12V(Audio) NG NG
11 +12V nc +12V nc +12V nc +12V +VLED 12V NG NG
12 +12V +VLED +12V +VLED +12V +VLED +12V +VLED 12V - VLED-
13 +12V - +12V - +12V - +12V - 12VA - VLED-
14 +12V - +12V - +12V - +12V - 12VA - VLED-
15 +5V - +5V - +3.5V - +5V - +3.5V/+5V - -
16 +5V - +5V - +3.5V - +5V - +3.5V/+5V - -
