Philips 49BDL5057P - IR Connection

49BDL5057P
15
PC
DISPLAY 1 DISPLAY 2
[DVI-I IN]
[VGA]
[DVI-I OUT] [DVI-I IN]
3.4.4. OPS video connection
ConnectOPSOUTconnectortoHDMI1/HDMI2connectorandthenselectthecorrespondingHDMIinputsourceforOPSvideo.
HDMI 1/HDMI 2 IN [OPS OUT]
3.5. IR connection
[IR IN]
External
IR Receiver
[IR IN]
[IR OUT]
DISPLAY 1
DISPLAY 2
NOTE: 
1. Thisdisplay’sremotecontrolsensorwillstopworkingifthe[IR IN]isconnected.
2. IRloopthroughconnectioncansupportupto9displays.
