C1112 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1114 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1116 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1117 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1118 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1119 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1201 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1202 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1203 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1205 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1206 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1207 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1208 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1209 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1210 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1212 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1213 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1214 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1216 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1217 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1218 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1219 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1301 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1302 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1303 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1305 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1306 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1307 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1308 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1309 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1310 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1312 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1313 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1314 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1316 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1317 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1318 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1319 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1401 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1402 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1403 CAP ELE 100µF/63V/M/85 CEG1010V8006
C1405 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1406 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1407 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1408 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1409 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1410 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1412 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1413 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1414 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1416 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1417 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1418 ELECTROLYTIC CAP SK100M470YZZP50R CE2AMASTH470
C1419 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1601 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1602 CAP ELE 4.7µF/50V/M/85 CEF4R70V8006
C1603 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1604 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C1605 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C1606 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1607 CHIP CERAMIC CAP. B K 1200pF/50V CHD1JK30B122
C1608 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
Ref. No. Description Part No.
C1609 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1610 CHIP CERAMIC CAP. CH J 27pF/50V CHD1JJ3CH270
C1611 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1612# CAP METALLIZED FILM 0.22µF/310V /K/LE-MX CTA2240DC001
C1618 CAP CHIP 3216 B K 10µF/25V CA1E106MR082
C1621 CAP ELECTROLYTIC 100µF/400V/M/22/25 CA2H101DYG17
C1622 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1623 CERAMIC CAP. RB 150pF/2kV CA3D151TE006
C1624 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1701 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1702 CHIP CERAMIC CAP. CH J 150pF/50V CHD1JJ3CH151
C1703 CAP CHIP 1608 J/C0G/100pF/50V CHD101EYA030
C1704 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1706 CERAMIC CAP. RB 100pF/2kV CA3D101TE006
C1708 CAP ELE 33µF/400V/M/85 CEN3300V8007
C1709 CAP ELE 220µF/10V/M/85 CEB2210V8006
C1710 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1711 CAP CERAMIC 470pF/250V KX CA2E471MR100
CONNECTORS
CN501 FFC CONNECTOR IMSA-9615S-23A-PP-A JC96J23ER007
CN601# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
CN1101 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
CN1201 PH CONNECTOR TOP 4P B4B-PH-K-S
(LF)(SN)
J3PHC04JG029
CN1401 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
DIODES
D601 DIODE 1N5406BH NDL1001N5406
D602 DIODE 1N5406BH NDL1001N5406
D603 DIODE 1N5406BH NDL1001N5406
D604 DIODE 1N5406BH NDL1001N5406
D605 RECTIFIER DIODE 1N4005 NDWZ001N4005
D606 RECTIFIER DIODE 1N4005 NDWZ001N4005
D607 DIODE 1N5406BH NDL1001N5406
D609A DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D613 DIODE ZENER 1ZB36BB NDWZ0001ZB36
D614 ZENER DIODE SMD TFZVTR27B QD1B00TFZV27
D615 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D617 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D618 ZENER DIODE SMD TFZVTR18B QD1B00TFZV18
D619A DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D620A DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D621A DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D623 ZENER DIODE MM5Z5V6B ND1BMM5Z5V6B
D650 DIODE SHOTTKY SB3200BR NDWZ3200D027
D653 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D654 DIODE ZENER 1ZB20BB NDWZ0001ZB20
D655 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D656 DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D657 ZENER DIODE MM5Z4V3B ND1BMM5Z4V3B
D660 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
D661 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D662 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D663 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D664 DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D704 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
D705 ZENER DIODE SMD TFZVTR27B QD1B00TFZV27
D710 DIO DE SCHOTTKY BARRIER SB3200BS NDWZSB3200BS
D711 DIO DE SCHOTTKY BARRIER SB3200BS NDWZSB3200BS
D712 DIO DE SCHOTTKY BARRIER SB3200BS NDWZSB3200BS
D714 DIODE FAST RECOVERY FR106BB NDWZ0FR106BB
D715 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
Ref. No. Description Part No.
