D716 ZENER DIODE MM5Z5V6B ND1BMM5Z5V6B
D1101 DIODE SCHOTTKY BARRIER SB2150BD NDWZ00SB2150
D1103 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1104 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1105 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1201 DIODE SCHOTTKY BARRIER SB2150BD NDWZ00SB2150
D1203 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1204 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1205 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1301 DIODE SCHOTTKY BARRIER SB2150BD NDWZ00SB2150
D1303 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1304 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1305 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1401 DIODE SCHOTTKY BARRIER SB2150BD NDWZ00SB2150
D1403 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1404 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1405 ZENER DIODE SMD TFZVTR20B QD1B00TFZV20
D1603 DIODE FAST RECOVERY 30PFB60 QDWZ030PFB60
D1605 DIODE FAST RECOVERY 30PFB60 QDWZ030PFB60
D1608 ZENER DIODE SMD TFZVTR16B QD1B00TFZV16
D1705 DIODE FAST RECOVERY RS1KJTD ND1Z0RS1KJTD
D1707 DIODE ZENER 1ZB36BB NDWZ0001ZB36
ICS
IC601 IC SWITCHING FA5640N-C6-TE3/SOP-8 QSCA0T0FD007
IC602# O-E DEVICE PHOTO COUPLER
TLP785F(D4FNBLLF(C
QPEL0TLP785F
IC604 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
IC1101 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
IC1201 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
IC1301 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
IC1401 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
IC1601 IC DUAL-PHASE PFC CONTROLLER
UCC28063DR/R-PDSO-G
NSCA0T0TY087
IC1602# O-E DEVICE PHOTO COUPLER
TLP785F(D4FNBLLF(C
QPEL0TLP785F
IC1702# O-E DEVICE PHOTO COUPLER
TLP785F(D4FNBLLF(C
QPEL0TLP785F
IC1703 IC SWITCHING FA5640N-C6-TE3/SOP-8 QSCA0T0FD007
COILS
L601A# COIL LINE FILTER LCL-2457 LLEG0ZMEK017
L602A# COIL LINE FILTER LCL-2457 LLEG0ZMEK017
L1101 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
L1201 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
L1301 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
L1401 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
TRANSISTORS
Q601 FET MOS TK3A65D(FND Q) QEWZTK3A65DQ
Q602 FET MOS TK3P50D RQ(S QF2Z0TK3P50D
Q603 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q650 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q653 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q654 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q691 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q701 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q702 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q703 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q705 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1101 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1103 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Ref. No. Description Part No.
Q1201 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1203 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1301 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1303 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1401 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1403 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1601 FET MOS TK7P60W.RVQ(S QF2Z0TK7P60W
Q1602 FET MOS TK7P60W.RVQ(S QF2Z0TK7P60W
Q1604 NPN TRANSISTOR SMD 2SC5344SY NQZY2SC5344S
Q1607 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1608 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1701 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1702 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1704 FET MOS TK5A65D(STA4 A Q) QFEZTK5A65DQ
RESISTORS
R601# RES. CARBON FILM J 1/2W J 1.2M RCX2125T1003
R604 RES CHIP 1608 1/10W F 2.70k RTW2701HH008
R605 RES CHIP 3216 1/4W J 270 RRX4271HH034
R606 RES CHIP 1608 1/10W J 22k RRXA223HH013
R607 RES CHIP 1608 1/10W J 4.7k RRXA472HH013
R608 RES CHIP 3216 1/4W J 10 RRX4100HH034
R609 RES CHIP 1608 1/10W J 820k RRXA824HH013
R610 RES CHIP 3216 1/4W J 15k RRX4153HH034
R611 RES CHIP 3216 1/4W J 15k RRX4153HH034
R614 RES CHIP 3216 1/4W J 15k RRX4153HH034
R617 RES CHIP 3216 1/4W J 4.7k RRX4472HH034
R618 METAL OXIDE FILM RES. 2W J 0.22 RN02R22ZU001
R619 RES CHIP 1608 1/10W J 4.7 RRXA4R7HH013
R620 RES CHIP 1608 1/10W J 47k RRXA473HH013
R623 RES CHIP 1608 1/10W F 2.70k RTW2701HH008
R624 RES CHIP 3216 1/4W F 510k RTC5103YF004
R625 RES CHIP 3216 1/4W F 510k RTC5103YF004
R626 RES CHIP 3216 1/4W F 510k RTC5103YF004
R627 RES CHIP 1608 1/10W F 39.0k RTW3902HH008
R628 RES CHIP 1608 1/10W J 22k RRXA223HH013
R629 RES CHIP 1608 1/10W J 47k RRXA473HH013
R630 RES CHIP 3216 1/4W J 560k RRX4564HH034
R631 RES CHIP 3216 1/4W J 560k RRX4564HH034
R632 RES CHIP 1608 1/10W J 8.2k RRXA822HH013
R633 RES CHIP 1608 1/10W J 8.2k RRXA822HH013
R651 RES CHIP 1608 1/10W J 1.0 RRXA1R0HH013
R652 RES CHIP 1608 1/10W J 10k RRXA103HH013
R653 RES CHIP 1608 1/10W F 22.0k RTW2202HH008
R654 RES CHIP 3216 1/4W J 180 RRX4181HH034
R655 RES CHIP 3216 1/4W J 180 RRX4181HH034
R656 RES CHIP 1608 1/10W J 8.2k RRXA822HH013
R657 RES CHIP 3216 1/4W J 3.9k RRX4392HH034
R658 RES CHIP 1608 1/10W J 2.7k RRXA272HH013
R659 RES CHIP 1608 1/10W F 3.90k RTW3901HH008
R660 RES CHIP 1608 1/10W F 27.0k RTW2702HH008
R661 RES CHIP 1608 1/10W F 3.30k RTW3301HH008
R662 RES CHIP 1608 1/10W J 47k RRXA473HH013
R666 RES CHIP 1608 1/10W 0 RRXA000HH014
R667 RES CHIP 1608 1/10W F 15.0k RTW1502HH008
R668 RES CHIP 1608 1/10W J 47k RRXA473HH013
R669 RES CHIP 1608 1/10W J 10k RRXA103HH013
R674 RES CHIP 1608 1/10W 0 RRXA000HH014
R675 RES CHIP 1608 1/10W F 68.0k RTW6802HH008
R691 RES CHIP 1608 1/10W J 2.2k RRXA222HH013
R692 RES CHIP 1608 1/10W J 330 RRXA331HH013
R693 RES CHIP 1608 1/10W J 47k RRXA473HH013
R701 RES CHIP 1608 1/10W J 10k RRXA103HH013
Ref. No. Description Part No.
