8. Input Mode
VGA/HDMI timing support
Item Mode Resolution H.Freq.(KHz) V.Freq.(Hz)
1 IBMVGA10H 640x350 31.469 70.086
2 MACINTOSH 640x480 35 66.67
3 VESA 640x480 37.861 72.809
4 VESA 640x480 37.5 75
5 IBMVGA3H 720x400 31.469 70.087
6 VESA 800x600 37.879 60.317
7 VESA 800x600 48.077 72.188
8 VESA 800x600 46.875 75.000
9 MACINTOSH 832x624 49.726 74.551
10 VESAStandardAddDMT 848x480 31 60.000
11 VESA 1024x768 48.363 60.004
12 VESA 1024x768 56.476 70.069
13 1152x864 63.851 70.012
14 VESA 1152x864 67.5 75.000
15 SUNWS 1152x900 61.846 66.004
16 - 1280x720 44.772 60.000
17 CVT 1280x800 62.8 74.930
18 VESA 1280x1024 63.981 60.020
19 SUNWS 1280x1024 71.691 67.189
20 VESA 1280x1024 79.976 75.025
21 VESAStandardAddDMT 1360x768 47.712 60.015
22 VESA 1440x900 70.635 74.984
23 VESA 1600x1200 75 60
24 VESAStandardVDMTREV 1920x1080 67.5 60.000
HDMI only:
Item Mode Resolution H.Freq.(KHz) V.Freq.(Hz)
1 3840x2160 53.946 23.900
2 3840x2160 54 24.000
3 3840x2160 56.25 25.000
4 3840x2160 67.432 29.900
5 3840x2160 67.5 30.000
Note:OPS/DisplayPortsupport3840x2160@30Hz.
• ThePCtextqualityisoptimuminHD1080mode(1920x1080,60Hz).
• YourPCdisplayscreenmightappeardifferentdependingonthemanufacturer(andyourparticularversionofWindows).
• CheckyourPCinstructionbookforinformationaboutconnectingyourPCtoadisplay.
• Ifaverticalandhorizontalfrequency-selectmodeexists,select60Hz(vertical)and31.5KHz(horizontal).Insomecases,abnormalsignals(suchas
stripes)mightappearonthescreenwhenthePCpoweristurnedoff(orifthePCisdisconnected).Ifso,pressthe[INPUT]buttontoenterthe
videomode.Also,makesurethatthePCisconnected.
• WhenhorizontalsynchronoussignalsseemirregularinRGBmode,checkPCpowersavingmodeorcableconnections.
• ThedisplaysettingstablecompliestotheIBM/VESAstandards,andbasedontheanaloginput.
• TheDVIsupportmodeisregardedassametothePCsupportmode.
• Thebesttimingfortheverticalfrequencytoeachmodeis60Hz.
• Resolution3840x216050/60HzmustbeequippedwithHDMIcertiedcable(PremiumHighSpeedHDMICables).
