Philips Alpha Series User Manual

4
Exploded views
1.
2.
3.
4.
5.
6.
7.
Plastic battery cover x1
Lithium battery x1
M6 anchor screw x2
Rear escutcheon x1
Compressed spring x2
Square shaft x2
M5 anchor screw x2
8.
9.
10.
11.
12.
13.
Mounting plate x1
Mortise x1
M5 threaded pipe x2
M6 threaded pipe x2
Front escutcheon x1
Screw cap x1
11 22 33 44
55
66
77
88
99 1010
1111
1212
1313

Philips Alpha Series Specifications

General

Connectivity	Bluetooth
Power Source	Battery
Battery Type	4 AA Batteries
Features	Auto-lock
Finish	Satin Nickel
Backset	2-3/8 inches or 2-3/4 inches
