Service Modes, Error Codes, and Fault Finding
EN 29BJ3.1E LA 5.
Figure 5-12 “Semi Stand-by” to “POD Stand-by” flowchart
G_15960_134.eps
011206
action holder: MIPS
autonomous action
action holder: St-by
POD standby
Semi Stand by
Switch OFF all supplies which are not needed in POD
standby by switching HIGH the ON-MODE I/O line.
Disable +8V6 supply detection algorithm
Reboot
Power-down HDMI and 1394 hardware by keeping
POWERDOWN-1394 GPIO 0 line high.
Set Viper HW blocks (TM1, TM2, MBS, VMSP1 and
VMSP2) to powerdown mode.
Hibernate the PNX2015 memory and keep the
PNX2015 in reset state
Disable audio protection algorithm
To Next Page
