Philips CDR796 - Page 49

ELECTRICAL PARTSLIST HEADPHONE BOARD
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1500 4822 265 11207 FFC-CONNECTOR, 6P, SIDE ENTRY
1501 4822 267 31453 HEADPHONE SOCKET 6,3mm
1505 2422 128 03032 TACT SWITCH
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2500 4822 124 81286 47µF 20% 16V
2501 4822 124 12032 4,7µF 20% 50V
2502 © 4822 126 13881 470pF 5% 50V
2503 © 5322 126 11579 3,3nF 10% 63V
2504 © 4822 126 14315 390pF 5% 50V
2505 4822 124 81286 47µF 20% 16V
2506 4822 124 12032 4,7µF 20% 50V
2507 © 2238 586 59812 100nF 10% 50V
2508 © 4822 126 13881 470pF 5% 50V
2509 © 5322 126 11579 3,3nF 10% 63V
2510 © 4822 126 14315 390pF 5% 50V
2511 © 2238 586 59812 100nF 10% 50V
2512 © 2238 586 59812 100nF 10% 50V
2513 © 2238 586 59812 100nF 10% 50V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3500 ! 4822 052 10109 10Ω 5% NFR
3501 © 4822 051 30102 1kΩ 5% 0,06W
3502 4822 101 21199 POTMETER 2x10KΩ
3503 © 4822 117 12139 22Ω 5% 0,06W
3504 © 4822 051 30101 100Ω 5% 0,06W
3505 © 4822 051 30103 10kΩ 5% 0,06W
3506 © 4822 051 30103 10kΩ 5% 0,06W
3507 ! 4822 052 10109 10Ω 5% NFR
3508 © 4822 051 30472 4,7kΩ 5% 0,06W
3509 © 4822 051 30102 1kΩ 5% 0,06W
3511 © 4822 117 12139 22Ω 5% 0,06W
3512 © 4822 051 30101 100Ω 5% 0,06W
3513 © 4822 051 30103 10kΩ 5% 0,06W
3514 © 4822 051 30103 10kΩ 5% 0,06W
3515 © 4822 051 30472 4,7kΩ 5% 0,06W
3516 © 4822 051 30561 560Ω 5% 0,06W
4503 © 4822 051 30008 CHIP JUMPER 0603
4506 © 4822 051 30008 CHIP JUMPER 0603
4509 © 4822 051 30008 CHIP JUMPER 0603
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7500 © 4822 209 31378 NJM4556M, 2-FOLD OP-AMP.
10-5
