Philips CEM3000 User Manual

25
10 Product
information
Note
Product information is subject to change •
without prior notice.
Power supply 12 V DC (11 V -
16 V), negative
ground
Fuse 15 A
Suitable speaker
impedance
4 - 8
Maximum power output 50 W x 4 channels
Continuous power
output
24 W x 4 RMS
(4
10% T.H.D.)
Pre-Amp output voltage 2.5 V
Subwoofer output
voltage
2.0 V
Aux-in level
500 mV
Dimensions (W x H x D) 188 x 58 x 201 mm
Weight 1.47 kg
Radio
Frequency range -
FM
87.5 - 108.0 MHz
(100kHz per step in auto
search and 50kHz per
step in manual search)
Frequency range -
AM(MW)
522 - 1620 KHz (9 kHz)
530 - 1710 kHz (10 kHz)
Usable sensitivity -
FM
8 μV
Usable sensitivity -
AM(MW) (S/N =
20 dB)
30 μV
DAB Tuner
Frequency range - FM 174 - 240 MHz
Sensitivity -100dBm(Band III)
Selectivity 40dB
Note
If the new fuse gets damaged again, there may •
be an internal malfunction. Consult your Philips
dealer.
Remove the unit
You can remove the unit from the dashboard.
1 Detach the front panel.
2 Pull out the unit by using the disassembly
tools.
English
EN

Philips CEM3000 Specifications

Power

power supply	12V DC

Audio Output

output power (MAX)	50Wx4 channels
output power (RMS)	24Wx4 channels (4 ohms, 10% T.H.D.)

Dimensions

product dimensions	188 x 58 x 190 mm
