4.1.3. Jumper Configurations
1001 :
+2.5Volts option
1002 :
+1.8Volts option
1031 :
+5.0Volts Antenna Power Up option
1034 : PLL synthesizer Address Selection option:
AS1 = C6 (pin 1 & 3)
AS1 = C0 (pin 2 & 4)
1035 :
PLL synthesizer Address Selection option /AS0. (not application for CU/TU1216)
1039 : +1.2Volts supply option (not application for CU/TU1216)
1036 : +4.0Volts External AGC supply option
4.1.4. Hard Reset
Connect Jumper 1038 to do a hard reset on the DUT.
