BU RF Solutions
- 6 -
2. Pinning Configurations
Both CU and TU have common pinning configurations. Refer to Table 2.1.
PIN SYMBOL DESCRIPTION
1 RF Mod_in RF Modulator input (depends on versions)
2 Ant_5V Antenna 5V [Do not connect if active antenna is not used.]
3 N.C Not connected
4 5V (LT) Loop Through Supply Voltage +5V (depends on version)
5 AGC Automatic Gain Control (external) +4V
[Do not connect for normal usage with Wideband AGC]
6 5V Tuner Supply Voltage +5V
7 AS NIM Address Select
8 Vt Tuner Tuning Voltage
[For monitoring purpose only, do not connect to power supply]
9 N.C Not connected
10 GND Ground
11 1.8V Supply +1.8V
12 3.3V Supply +3.3V
13 IF Intermediate Frequency (unfiltered)
14 GND
Ground
15 MPEG D0/SER Parallel MPEG Transport Output Data Bit 0/Serial Output
16 MPEG D1 Parallel MPEG Transport Output Data Bit 1
17 MPEG D2 Parallel MPEG Transport Output Data Bit 2
18 MPEG D3 Parallel MPEG Transport Output Data Bit 3
19 MPEG D4 Parallel MPEG Transport Output Data Bit 4
20 MPEG D5 Parallel MPEG Transport Output Data Bit 5
21 MPEG D6 Parallel MPEG Transport Output Data Bit 6
22 MPEG D7 Parallel MPEG Transport Output Data Bit 7
23 MPEG_TS_CLK MPEG Transport Stream Clock
24 SDA I
2
C-Bus Serial Data
25 SCL I
2
C-Bus Serial Clock
26 RST Reset
27 MPEG_DATA_VAL MPEG Data Valid
28 MPEG_PKT_SYNC MPEG Packet Sync
29 MPEG_ERR MPEG error out
30 N.C Not connected
31 N.C Not connected
32 N.C Not connected
M1,M2,
M3,M4
GND Mounting Tags (Ground)
