3. Quick Startup Guide for the user.
A quick guide is as followed. Further information and instructions for hardware and software requirements are
given in the next sections.
1) Apply +5V power supply at connector 1000.
2) Connect parallel port from IIC controller (PC), which generates the IIC protocol connector 1040 (IIC Input
Connector).
3) Set Tuner Address Select/ AS to C0 by putting a jumper at pin 3 & 4 of connector 1034.
4) Load DUT at socket 1030.
5) For CU1216, load TDA10021 software and follow the software instruction guide as in section 5 OR
6) For TU1216, load TDA10046 software and follow the software instruction guide as in section 5.
7) Connect the QAM/COFDM input signal at RFin connector of the DUT. Check min supply current
.
CU1216LM = 380mA
CU1216LS = 340mA
CU1216A = 336mA
TU1216L = 380mA
If not, reset board at connector 1038 with a jumper.
8) MPEG2 TS output available at connector 1020 for further MPEG2 decoding.
