Philips DVDR3545V/37

To Next Page

To Previous Page

20070328 1-19-8 E9H90EL

R1646 CHIP RES. 1/10W J 3.3K OHM 1

R1646 RES CHIP 1608 1/10W J 3.3K OHM 1

R1647 CHIP RES. 1/10W J 2.2K OHM 1

R1647 RES CHIP 1608 1/10W J 2.2K OHM 1

R1648 CHIP RES. 1/10W J 3.3K OHM 1

R1648 RES CHIP 1608 1/10W J 3.3K OHM 1

R1650 CHIP RES. 1/10W J 1K OHM 1

R1650 RES CHIP 1608 1/10W J 1.0K OHM 1

R1651 CHIP RES. 1/10W J 560 OHM 1

R1651 RES CHIP 1608 1/10W J 560 OHM 1

R1702 CARBON RES. 1/4W J 1.8K OHM 1

R2221 CHIP RES. 1/10W J 2.2K OHM 1

R2221 RES CHIP 1608 1/10W J 2.2K OHM 1

R2222 CHIP RES.(1608) 1/10W F 10K OHM 1

R2222 CHIP RES. 1/10W F 10K OHM 1

R2222 RES CHIP 1608 1/10W F 10.0K OHM 1

R2223 CHIP RES.(1608) 1/10W F 1.5K OHM 1

R2223 CHIP RES. 1/10W F 1.5K OHM 1

R2223 RES CHIP 1608 1/10W F 1.50K OHM 1

R2224 CHIP RES. 1/10W F 15K OHM 1

R2224 RES CHIP 1608 1/10W F 15.0K OHM 1

R2225 CHIP RES. 1/10W J 47K OHM 1

R2225 RES CHIP 1608 1/10W J 47K OHM 1

R2228 CHIP RES. 1/10W J 2.7K OHM 1

R2228 RES CHIP 1608 1/10W J 2.7K OHM 1

R2229 CHIP RES. 1/10W J 2.2K OHM 1

R2229 RES CHIP 1608 1/10W J 2.2K OHM 1

R2230 CHIP RES.(1608) 1/10W F 10K OHM 1

R2230 CHIP RES. 1/10W F 10K OHM 1

R2230 RES CHIP 1608 1/10W F 10.0K OHM 1

R2231 CHIP RES. 1/10W F 1.1K OHM 1

R2231 RES CHIP 1608 1/10W F 1.10K OHM 1

R2232 CHIP RES.(1608) 1/10W F 3.9K OHM 1

R2232 CHIP RES. 1/10W F 3.9K OHM 1

R2232 RES CHIP 1608 1/10W F 3.90K OHM 1

R2234 CHIP RES. 1/10W J 47K OHM 1

R2234 RES CHIP 1608 1/10W J 47K OHM 1

R2327 CHIP RES. 1/10W J 470 OHM 1

R2327 RES CHIP 1608 1/10W J 470 OHM 1

R2328 CHIP RES. 1/10W J 3K OHM 1

R2328 RES CHIP 1608 1/10W J 3.0K OHM 1

R2329 CHIP RES. 1/10W J 3K OHM 1

R2329 RES CHIP 1608 1/10W J 3.0K OHM 1

R2330 CHIP RES. 1/10W J 1K OHM 1

R2330 RES CHIP 1608 1/10W J 1.0K OHM 1

R2331 CHIP RES. 1/10W J 12K OHM 1

R2331 RES CHIP 1608 1/10W J 12K OHM 1

R2332 CHIP RES. 1/10W J 12K OHM 1

R2332 RES CHIP 1608 1/10W J 12K OHM 1

R2333 CHIP RES. 1/10W J 470 OHM 1

R2333 RES CHIP 1608 1/10W J 470 OHM 1

R2351 CHIP RES. 1/10W J 1.8K OHM 1

R2351 RES CHIP 1608 1/10W J 1.8K OHM 1

R2352 CHIP RES. 1/10W J 2.2K OHM 1

R2352 RES CHIP 1608 1/10W J 2.2K OHM 1

R2353 CHIP RES. 1/10W J 2.2K OHM 1

R2353 RES CHIP 1608 1/10W J 2.2K OHM 1

R2354 CHIP RES. 1/10W J 220 OHM 1

R2354 RES CHIP 1608 1/10W J 220 OHM 1

R2355 CHIP RES. 1/10W J 75 OHM 1

R2355 RES CHIP 1608 1/10W J 75 OHM 1

R2356 CHIP RES. 1/10W J 100K OHM 1

R2356 RES CHIP 1608 1/10W J 100K OHM 1

R2358 CHIP RES.(1608) 1/10W 0 OHM 1

R2358 RES CHIP 1608 1/10W J 0 OHM 1

R2391 CARBON RES. 1/4W J 560 OHM 1

ELECTRICAL PARTS LIST

DVDR3545V/37

Pos.No. # 12 NC Description

R2392 CARBON RES. 1/4W J 560 OHM 1

R2395 PCB JUMPER D0.6-P5.0 1

R2397 CHIP RES. 1/10W J 220 OHM 1

R2397 RES CHIP 1608 1/10W J 220 OHM 1

R2402 CHIP RES. 1/10W J 75 OHM 1

R2402 RES CHIP 1608 1/10W J 75 OHM 1

R2403 CHIP RES. 1/10W J 75 OHM 1

R2403 RES CHIP 1608 1/10W J 75 OHM 1

R2404 CHIP RES. 1/10W J 75 OHM 1

R2404 RES CHIP 1608 1/10W J 75 OHM 1

R2407 CHIP RES. 1/10W J 75 OHM 1

R2407 RES CHIP 1608 1/10W J 75 OHM 1

R2409 CHIP RES.(1608) 1/10W F 220 OHM 1

R2409 CHIP RES. 1/10W F 220 OHM 1

R2409 RES CHIP 1608 1/10W F 220 OHM 1

R2410 CHIP RES.(1608) 1/10W F 3.3K OHM 1

R2410 CHIP RES. 1/10W F 3.3K OHM 1

R2410 RES CHIP 1608 1/10W F 3.30K OHM 1

R2421 CHIP RES.(1608) 1/10W F 240 OHM 1

R2421 CHIP RES. 1/10W F 240 OHM 1

R2421 RES CHIP 1608 1/10W F 240 OHM 1

R2422 CHIP RES.(1608) 1/10W F 4.7K OHM 1

R2422 CHIP RES. 1/10W F 4.7K OHM 1

R2422 RES CHIP 1608 1/10W F 4.70K OHM 1

R2441 CHIP RES.(1608) 1/10W F 200 OHM 1

R2441 CHIP RES. 1/10W F 200 OHM 1

R2441 RES CHIP 1608 1/10W F 200 OHM 1

R2443 CHIP RES. 1/10W J 75 OHM 1

R2443 RES CHIP 1608 1/10W J 75 OHM 1

R2461 CHIP RES.(1608) 1/10W F 220 OHM 1

R2461 CHIP RES. 1/10W F 220 OHM 1

R2461 RES CHIP 1608 1/10W F 220 OHM 1

R2462 CHIP RES. 1/10W J 75 OHM 1

R2462 RES CHIP 1608 1/10W J 75 OHM 1

R2481 CHIP RES.(1608) 1/10W F 220 OHM 1

R2481 CHIP RES. 1/10W F 220 OHM 1

R2481 RES CHIP 1608 1/10W F 220 OHM 1

R2482 CHIP RES. 1/10W J 75 OHM 1

R2482 RES CHIP 1608 1/10W J 75 OHM 1

R2521 CHIP RES. 1/10W J 2.2K OHM 1

R2521 RES CHIP 1608 1/10W J 2.2K OHM 1

R2615 CHIP RES. 1/10W J 1.2K OHM 1

R2615 RES CHIP 1608 1/10W J 1.2K OHM 1

R2616 CHIP RES. 1/10W J 33K OHM 1

R2616 RES CHIP 1608 1/10W J 33K OHM 1

R2617 CHIP RES. 1/10W J 360 OHM 1

R2617 RES CHIP 1608 1/10W J 360 OHM 1

R2751 CHIP RES. 1/10W J 75 OHM 1

R2751 RES CHIP 1608 1/10W J 75 OHM 1

R2771 CHIP RES.(1608) 1/10W 0 OHM 1

R2771 RES CHIP 1608 1/10W J 0 OHM 1

R2772 CHIP RES.(1608) 1/10W 0 OHM 1

R2772 RES CHIP 1608 1/10W J 0 OHM 1

R2777 CARBON RES. 1/6W J 3.9K OHM 1

R2777 CARBON RES. 1/4W J 3.9K OHM 1

R2802 CHIP RES.(1608) 1/10W F 68K OHM 1

R2802 CHIP RES. 1/10W F 68K OHM 1

R2802 RES CHIP 1608 1/10W F 68.0K OHM 1

R2803 CHIP RES.(1608) 1/10W F 68K OHM 1

R2803 CHIP RES. 1/10W F 68K OHM 1

R2803 RES CHIP 1608 1/10W F 68.0K OHM 1

R2806 CHIP RES. 1/10W J 180K OHM 1

R2806 RES CHIP 1608 1/10W J 180K OHM 1

R2809 CHIP RES. 1/10W J 180K OHM 1

R2809 RES CHIP 1608 1/10W J 180K OHM 1

R2810 CHIP RES. 1/10W J 75 OHM 1

R2810 RES CHIP 1608 1/10W J 75 OHM 1

R2825 CHIP RES.(1608) 1/10W F 68K OHM 1

ELECTRICAL PARTS LIST

DVDR3545V/37

Pos.No. # 12 NC Description

Main Page

Philips DVDR3545V/37 - Page 95
