Philips DVDR3545V/37

To Next Page

To Previous Page

20070328 1-19-9 E9H90EL

R2825 CHIP RES. 1/10W F 68K OHM 1

R2825 RES CHIP 1608 1/10W F 68.0K OHM 1

R2827 CHIP RES.(1608) 1/10W 0 OHM 1

R2827 RES CHIP 1608 1/10W J 0 OHM 1

R2829 CHIP RES.(1608) 1/10W F 68K OHM 1

R2829 CHIP RES. 1/10W F 68K OHM 1

R2829 RES CHIP 1608 1/10W F 68.0K OHM 1

R2831 CHIP RES.(1608) 1/10W 0 OHM 1

R2831 RES CHIP 1608 1/10W J 0 OHM 1

R2833 CHIP RES.(1608) 1/10W F 75K OHM 1

R2833 CHIP RES. 1/10W F 75K OHM 1

R2833 RES CHIP 1608 1/10W F 75.0K OHM 1

R2835 CHIP RES.(1608) 1/10W F 75K OHM 1

R2835 CHIP RES. 1/10W F 75K OHM 1

R2835 RES CHIP 1608 1/10W F 75.0K OHM 1

R2837 CHIP RES.(1608) 1/10W F 68K OHM 1

R2837 CHIP RES. 1/10W F 68K OHM 1

R2837 RES CHIP 1608 1/10W F 68.0K OHM 1

R2840 CHIP RES.(1608) 1/10W F 68K OHM 1

R2840 CHIP RES. 1/10W F 68K OHM 1

R2840 RES CHIP 1608 1/10W F 68.0K OHM 1

R2841 CHIP RES.(1608) 1/10W F 68K OHM 1

R2841 CHIP RES. 1/10W F 68K OHM 1

R2841 RES CHIP 1608 1/10W F 68.0K OHM 1

R2842 CHIP RES. 1/10W J 620 OHM 1

R2842 RES CHIP 1608 1/10W J 620 OHM 1

R2843 CHIP RES.(1608) 1/10W F 68K OHM 1

R2843 CHIP RES. 1/10W F 68K OHM 1

R2843 RES CHIP 1608 1/10W F 68.0K OHM 1

R2844 CHIP RES. 1/10W J 20K OHM 1

R2844 RES CHIP 1608 1/10W J 20K OHM 1

R2845 CHIP RES. 1/10W J 13K OHM 1

R2845 RES CHIP 1608 1/10W J 13K OHM 1

R2847 CHIP RES. 1/10W J 1K OHM 1

R2847 RES CHIP 1608 1/10W J 1.0K OHM 1

R2852 CHIP RES.(1608) 1/10W F 3.6K OHM 1

R2852 CHIP RES. 1/10W F 3.6K OHM 1

R2852 RES CHIP 1608 1/10W F 3.60K OHM 1

R2853 CHIP RES. 1/10W J 3.3K OHM 1

R2853 RES CHIP 1608 1/10W J 3.3K OHM 1

R2854 CHIP RES.(1608) 1/10W F 11K OHM 1

R2854 CHIP RES. 1/10WF 11K OHM 1

R2854 RES CHIP 1608 1/10W F 11.0K OHM 1

R2855 CHIP RES.(1608) 1/10W F 3.6K OHM 1

R2855 CHIP RES. 1/10W F 3.6K OHM 1

R2855 RES CHIP 1608 1/10W F 3.60K OHM 1

R2856 CHIP RES. 1/10W J 3.3K OHM 1

R2856 RES CHIP 1608 1/10W J 3.3K OHM 1

R2857 CHIP RES.(1608) 1/10W F 11K OHM 1

R2857 CHIP RES. 1/10WF 11K OHM 1

R2857 RES CHIP 1608 1/10W F 11.0K OHM 1

R2858 CHIP RES. 1/10W J 100K OHM 1

R2858 RES CHIP 1608 1/10W J 100K OHM 1

R2859 CHIP RES. 1/10W J 470 OHM 1

R2859 RES CHIP 1608 1/10W J 470 OHM 1

R2860 CHIP RES. 1/10W J 100K OHM 1

R2860 RES CHIP 1608 1/10W J 100K OHM 1

R2861 CHIP RES. 1/10W J 470 OHM 1

R2861 RES CHIP 1608 1/10W J 470 OHM 1

R2863 CHIP RES.(1608) 1/10W 0 OHM 1

R2863 RES CHIP 1608 1/10W J 0 OHM 1

R2865 CHIP RES. 1/10W J 100K OHM 1

R2865 RES CHIP 1608 1/10W J 100K OHM 1

R2867 CHIP RES. 1/10W J 1K OHM 1

R2867 RES CHIP 1608 1/10W J 1.0K OHM 1

R2868 CHIP RES. 1/10W J 1K OHM 1

R2868 RES CHIP 1608 1/10W J 1.0K OHM 1

R2871 CHIP RES. 1/10W J 220 OHM 1

ELECTRICAL PARTS LIST

DVDR3545V/37

Pos.No. # 12 NC Description

R2871 RES CHIP 1608 1/10W J 220 OHM 1

R2872 CHIP RES. 1/10W J 220 OHM 1

R2872 RES CHIP 1608 1/10W J 220 OHM 1

R2875 CHIP RES. 1/10W J 4.7K OHM 1

R2875 RES CHIP 1608 1/10W J 4.7K OHM 1

R2876 CHIP RES. 1/10W J 4.7K OHM 1

R2876 RES CHIP 1608 1/10W J 4.7K OHM 1

R3015 CHIP RES. 1/10W J 2.7K OHM 1

R3015 RES CHIP 1608 1/10W J 2.7K OHM 1

R5014 CHIP RES. 1/10W J 2.2K OHM 1

R5014 RES CHIP 1608 1/10W J 2.2K OHM 1

R5015 CHIP RES.(1608) 1/10W F 10K OHM 1

R5015 CHIP RES. 1/10W F 10K OHM 1

R5015 RES CHIP 1608 1/10W F 10.0K OHM 1

R5016 CHIP RES.(1608) 1/10W F 10K OHM 1

R5016 CHIP RES. 1/10W F 10K OHM 1

R5016 RES CHIP 1608 1/10W F 10.0K OHM 1

R5018 CHIP RES. 1/10W J 47K OHM 1

R5018 RES CHIP 1608 1/10W J 47K OHM 1

R5019 CHIP RES. 1/10W J 2.7K OHM 1

R5019 RES CHIP 1608 1/10W J 2.7K OHM 1

R5026 CHIP RES.(1608) 1/10W F 120 OHM 1

R5026 CHIP RES. 1/10W F 120 OHM 1

R5026 RES CHIP 1608 1/10W F 120 OHM 1

R5027 CHIP RES. 1/10W J 2.7K OHM 1

R5027 RES CHIP 1608 1/10W J 2.7K OHM 1

R5028 CHIP RES. 1/10W J 220 OHM 1

R5028 RES CHIP 1608 1/10W J 220 OHM 1

R5029 CHIP RES. 1/10W J 4.7K OHM 1

R5029 RES CHIP 1608 1/10W J 4.7K OHM 1

R5046 CHIP RES.(1608) 1/10W 0 OHM 1

R5046 RES CHIP 1608 1/10W J 0 OHM 1

R5049 PCB JUMPER D0.6-P5.0 1

R5050 PCB JUMPER D0.6-P5.0 1

R5051 CHIP RES. 1/10W J 18K OHM 1

R5051 RES CHIP 1608 1/10W J 18K OHM 1

R5052 CHIP RES. 1/10W J 27K OHM 1

R5052 RES CHIP 1608 1/10W J 27K OHM 1

R5053 CHIP RES. 1/10W J 27K OHM 1

R5053 RES CHIP 1608 1/10W J 27K OHM 1

R5054 CHIP RES. 1/10W J 18K OHM 1

R5054 RES CHIP 1608 1/10W J 18K OHM 1

SWITCHES

SW1511 LEAF SWITCH MXS01830MVP0 1

SW1512 SWITCH ROTARY SSS-53MD-1 1

SW1602 TACT SWITCH SKQSAF001A 1

SW1602 TACT SWITCH KSM0614B 1

SW1602 TACT SWITCH TC-1104(H=9.5) 1

SW1603 TACT SWITCH SKQSAF001A 1

SW1603 TACT SWITCH KSM0614B 1

SW1603 TACT SWITCH TC-1104(H=9.5) 1

SW1604 TACT SWITCH SKQSAF001A 1

SW1604 TACT SWITCH KSM0614B 1

SW1604 TACT SWITCH TC-1104(H=9.5) 1

SW1605 TACT SWITCH SKQSAF001A 1

SW1605 TACT SWITCH KSM0614B 1

SW1605 TACT SWITCH TC-1104(H=9.5) 1

SW1606 TACT SWITCH SKQSAF001A 1

SW1606 TACT SWITCH KSM0614B 1

SW1606 TACT SWITCH TC-1104(H=9.5) 1

SW1607 TACT SWITCH SKQSAF001A 1

SW1607 TACT SWITCH KSM0614B 1

SW1607 TACT SWITCH TC-1104(H=9.5) 1

SW1608 TACT SWITCH SKQSAF001A 1

SW1608 TACT SWITCH KSM0614B 1

SW1608 TACT SWITCH TC-1104(H=9.5) 1

SW1609 TACT SWITCH SKQSAF001A 1

ELECTRICAL PARTS LIST

DVDR3545V/37

Pos.No. # 12 NC Description
