20070328 1-19-10 E9H90EL
SW1609 TACT SWITCH KSM0614B 1
SW1609 TACT SWITCH TC-1104(H=9.5) 1
SW1611 TACT SWITCH SKQSAF001A 1
SW1611 TACT SWITCH KSM0614B 1
SW1611 TACT SWITCH TC-1104(H=9.5) 1
SW1613 TACT SWITCH SKQSAF001A 1
SW1613 TACT SWITCH KSM0614B 1
SW1613 TACT SWITCH TC-1104(H=9.5) 1
SW1616 TACT SWITCH SKQSAF001A 1
SW1616 TACT SWITCH KSM0614B 1
SW1616 TACT SWITCH TC-1104(H=9.5) 1
POWER SW CBA
W101
WIRE ASSEMBLY 4P 4PIN/
AWG26#2651/P2.0
1
DIODE
D1564 LED(RED) 204HD/E 1
SWITCHES
SW1601 TACT SWITCH SKQSAF001A 1
SW1601 TACT SWITCH KSM0614B 1
SW1601 TACT SWITCH TC-1104(H=9.5) 1
DVD OPEN/CLOSE SW CBA
W102
WIRE ASSEMBLY 3PIN 3PIN/
AWG26#2651/P2.0
1
SWITCHES
SW1615 TACT SWITCH SKQSAF001A 1
SW1615 TACT SWITCH KSM0614B 1
SW1615 TACT SWITCH TC-1104(H=9.5) 1
SENSOR CBA
TRANSISTORS
Q1503 PHOTO TRANSISTOR PT204-6B-12 1
Q1503 PHOTO TRANSISTOR MID-32A22F 1
Q1504 PHOTO TRANSISTOR PT204-6B-12 1
Q1504 PHOTO TRANSISTOR MID-32A22F 1
ASSY 2 996510002061
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
1
ASSY 3 996510004025 PSV CBA 1
Consists of the following:
ASSY 3a POWER SUPPLY CBA 1
ASSY 3b FRONT JACK CBA 1
POWER SUPPLY CBA
2B18 HEATSINK V2600PZ 1
2L019
SCREW S-TIGHT M3X8 BIND
HEAD+
1
AC1001 # 996510002063
AC CORD WITH A GND WIRE UL/
CSA 1750 BLACK
1
AC1001 # 996510002064
AC CORD WITH A GND WIRE UL/
CSA 1750 BLACK
1
F1001 # 996510002065 FUSE CURRENT PEG20C0NG001 1
F1001 # 996510002066
FUSE TIME RAG SIC 1A 250V UC
PSE
1
FH1001 FUSE HOLDER MSF-015 LF (B110) 1
FH1001 FUSE HOLDER DFH-001 1
FH1002 FUSE HOLDER MSF-015 LF (B110) 1
FH1002 FUSE HOLDER DFH-001 1
GP1001 # GAP. FNR-G3.10D 1
SA1001 # SURGE ABSORBER 470V+-10PER 1
SA1001 # SURGE ABSORBER CNR-10D471K 1
T1001 # 996510002072 TRANS POWER 06762-S02 1
W1001
WIRE ASSEMBLY FFC 30P 30 111
WHITE
1
CAPACITORS
C1001 #
ACROSS THE LINE CAP. 0.068UF/
250V
1
C1001 #
METALIZED FILM CAP. 0.068UF/250V
M
1
C1003 CERAMIC CAP. B K 0.01UF/500V 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
C1004
ELECTROLYTIC CAPACITOR
ZR200TA221K18EB
1
C1004 ELECTROLYTIC CAP. 220UF/200V M 1
C1006 # SAFETY CAP. 3300PF/250V 1
C1006 # SAFETY CAP. 3300PF/250V 1
C1007 CERAMIC CAP. YV Z 0.022UF/50V 1
C1009 ELECTROLYTIC CAP. 10UF/16V M 1
C1010 CERAMIC CAP.(AX) X K 2200PF/16V 1
C1011 CERAMIC CAP.(AX) B K 1000PF/50V 1
C1012 ELECTROLYTIC CAP. 470UF/16V M 1
C1013 ELECTROLYTIC CAP. 10UF/50V M H7 1
C1014 ELECTROLYTIC CAP. 470UF/16V M 1
C1014 ELECTROLYTIC CAP. 470UF/16V M 1
C1015 ELECTROLYTIC CAP. 1000UF/16V M 1
C1017
ELECTROLYTIC CAP. 4700UF/6.3V
SL
1
C1017
ELECTROLYTIC CAP. 4700UF/6.3V
SM
1
C1018 CERAMIC CAP. B K 220PF/500V 1
C1019 ELECTROLYTIC CAP. 1000UF/6.3V M 1
C1021 ELECTROLYTIC CAP. 470UF/6.3V M 1
C1023 CERAMIC CAP. B K 470PF/500V 1
C1024 ELECTROLYTIC CAP. 22UF/50V M 1
C1027
ELECTROLYTIC CAP. 3300UF/6.3V
SL
1
C1027
ELECTROLYTIC CAP. 3300UF/6.3V
SM
1
C1028
ELECTROLYTIC CAP. 3300UF/6.3V
SL
1
C1028
ELECTROLYTIC CAP. 3300UF/6.3V
SM
1
C1030 CERAMIC CAP.(AX) B K 0.01UF/50V 1
C1031 CERAMIC CAP.(AX) B K 0.1UF/50V 1
C1032 ELECTROLYTIC CAP. 220UF/6.3V M 1
C1033 ELECTROLYTIC CAP. 220UF/6.3V M 1
C1035 CERAMIC CAP. B K 470PF/500V 1
C1036 CERAMIC CAP. B K 470PF/500V 1
C1037
ELECTROLYTIC CAP. 3300UF/6.3V
SL
1
C1037
ELECTROLYTIC CAP. 3300UF/6.3V
SM
1
DIODES
D1001 DIODE 1N5397-B 1
D1001 DIODE 1N5397BD 1
D1002 DIODE 1N5397-B 1
D1002 DIODE 1N5397BD 1
D1003 DIODE 1N5397-B 1
D1003 DIODE 1N5397BD 1
D1004 DIODE 1N5397-B 1
D1004 DIODE 1N5397BD 1
D1006 SWITCHING DIODE 1SS133(T-77) 1
D1006 DIODE SWITCHING 1N4148-F0021 1
D1006 SWITCHING DIODE 1N4148M 1
D1007 ZENER DIODE MTZJT-7733B 1
D1007 DIODE ZENER 33BSB-T26 1
D1007 ZENER DIODE DZ-33BSBT265 1
D1009 SWITCHING DIODE 1SS133(T-77) 1
D1009 DIODE SWITCHING 1N4148-F0021 1
D1009 SWITCHING DIODE 1N4148M 1
D1010 SWITCHING DIODE 1SS133(T-77) 1
D1010 DIODE SWITCHING 1N4148-F0021 1
D1010 SWITCHING DIODE 1N4148M 1
D1011 RECTIFIER DIODE BA158 1
D1011 RECTIFIER DIODE BA158 1
D1012 SCHOTTKY BARRIER DIODE SB390 1
D1012 SCHOTTKY BARRIER DIODE SB390 1
D1013 RECTIFIER DIODE BA158 1
D1013 RECTIFIER DIODE BA158 1
D1014 SCHOTTKY BARRIER DIODE SB190 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
To Next Page
