Philips DVDR3545V/37 - Page 98

20070328 1-19-11 E9H90EL
D1014 SCHOTTKY BARRIER DIODE SB190 1
D1015 SCHOTTKY BARRIER DIODE SB340 1
D1015 SCHOTTKY BARRIER DIODE SB340 1
D1016 SCHOTTKY BARRIER DIODE SB340 1
D1016 SCHOTTKY BARRIER DIODE SB340 1
D1017 ZENER DIODE MTZJT-7715C 1
D1017 DIODE ZENER 15BSC-T26 1
D1017 ZENER DIODE DZ-15BSCT265 1
D1018 RECTIFIER DIODE BA158 1
D1018 RECTIFIER DIODE BA158 1
D1020 PCB JUMPER D0.6-P5.0 1
D1021 SCHOTTKY BARRIER DIODE SB340 1
D1021 SCHOTTKY BARRIER DIODE SB340 1
D1022 SCHOTTKY BARRIER DIODE SB340 1
D1022 SCHOTTKY BARRIER DIODE SB340 1
D1023 SCHOTTKY BARRIER DIODE SB140 1
D1023 SCHOTTKY BARRIER DIODE SB140 1
D1024 ZENER DIODE MTZJT-7718C 1
D1024 DIODE ZENER 18BSC-T26 1
D1024 ZENER DIODE DZ-18BSCT265 1
D1025 ZENER DIODE MTZJT-776.8B 1
D1025 DIODE ZENER 6V8BSB-T26 1
D1025 ZENER DIODE DZ-6.8BSBT265 1
D1028 RECTIFIER DIODE BA158 1
D1028 RECTIFIER DIODE BA158 1
D1029 SWITCHING DIODE 1SS133(T-77) 1
D1029 DIODE SWITCHING 1N4148-F0021 1
D1029 SWITCHING DIODE 1N4148M 1
D1030 SWITCHING DIODE 1SS133(T-77) 1
D1030 DIODE SWITCHING 1N4148-F0021 1
D1030 SWITCHING DIODE 1N4148M 1
D1035 SWITCHING DIODE 1SS133(T-77) 1
D1035 DIODE SWITCHING 1N4148-F0021 1
D1035 SWITCHING DIODE 1N4148M 1
D1036 ZENER DIODE MTZJT-776.8B 1
D1036 DIODE ZENER 6V8BSB-T26 1
D1036 ZENER DIODE DZ-6.8BSBT265 1
ICS
IC1010 # 996500025506 PHOTOCOUPLER PS2561A-1(W) 1
IC1010 # 996500019657 PHOTOCOUPLER EL817B 1
IC1010 # 996510002182 PHOTOCOUPLER LTV-817B-F 1
IC1010 # 996500024000 PHOTOCOUPLER PS2561A-1(Q) 1
COILS
L1001 # 996510002067
COIL LINE FILTER ST0603FT20-009
0.027
1
L1001 # 996510002068 LINE FILTER 27MH 5703 1
L1002 BEAD CORE B16 RH 3.5X10X1.3 1
L1002 BEAD CORE HF70BB3.5X10X1.3 1
L1010
POWER INDUCTORS CWKBNP-
180K
1
L1010
POWER INDUCTORS TWKBNP-
180K
1
L1010 CHOKE COIL(18UH) LHL10NB180K 1
L1012
POWER INDUCTORS CWKBNP-
150K
1
L1012
POWER INDUCTORS TWKBNP-
150K
1
L1012 CHOKE COIL(15UH) LHL10NB150K 1
L1013
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP
1
L1013 CHOKE COIL 47UH 1
L1013 CHOKE COIL 47UH-K 1
TRANSISTORS
Q1001 # 996510002069 FET MOS 2SK3563(Q) 1
Q1001 # 996510002070 MOS FET KHB4D5N60F-U/PMC 1
Q1001 # 996510002071 FET POWER MOS FQPF5N50C 1
Q1003 TRANSISTOR KTC3199-Y-AT/P 1
Q1003 TRANSISTOR 2SC1815-Y(TE2 F T) 1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
Q1008 TRANSISTOR KTC3199-Y-AT/P 1
Q1008 TRANSISTOR 2SC1815-Y(TE2 F T) 1
Q1008 TRANSISTOR KTC3199-GR-AT/P 1
Q1008 TRANSISTOR 2SC1815-GR(TE2 F T) 1
Q1031 TRANSISTOR KTA1267-Y-AT/P 1
Q1031 TRANSISTOR 2SA1015-Y(TE2 F T) 1
Q1031 TRANSISTOR KTA1267-GR-AT/P 1
Q1031 TRANSISTOR 2SA1015-GR(TE2 F T) 1
RESISTORS
R1004
METAL OXIDE FILM RES. 2W J 82K
OHM
1
R1004
METAL OXIDE FILM RES. 2W J 82K
OHM
1
R1005 CARBON RES. 1/4W J 1M OHM 1
R1006 CARBON RES. 1/4W J 1M OHM 1
R1007
METAL OXIDE FILM RES. 2W J 0.68
OHM
1
R1007
METAL OXIDE FILM RES. 2W J 0.68
OHM
1
R1008 CARBON RES. 1/6W G 680 OHM 1
R1008 CARBON RES. 1/4W G 680 OHM 1
R1009 CARBON RES. 1/6W J 22K OHM 1
R1009 CARBON RES. 1/4W J 22K OHM 1
R1015 CARBON RES. 1/4W J 820 OHM 1
R1016 CARBON RES. 1/6W J 330 OHM 1
R1016 CARBON RES. 1/4W J 330 OHM 1
R1017 PCB JUMPER D0.6-P5.0 1
R1018 CARBON RES. 1/6W J 4.7K OHM 1
R1018 CARBON RES. 1/4W J 4.7K OHM 1
R1019 CARBON RES. 1/6W J 1.8K OHM 1
R1019 CARBON RES. 1/4W J 1.8K OHM 1
R1020 PCB JUMPER D0.6-P5.0 1
R1021 CARBON RES. 1/6W G 2.4K OHM 1
R1021 CARBON RES. 1/4W G 2.4K OHM 1
R1022 CARBON RES. 1/6W G 5.6K OHM 1
R1022 CARBON RES. 1/4W G 5.6K OHM 1
R1029 CARBON RES. 1/6W J 150K OHM 1
R1029 CARBON RES. 1/4W J 150K OHM 1
R1032 CARBON RES. 1/6W J 120 OHM 1
R1032 CARBON RES. 1/4W J 120 OHM 1
R1034 CARBON RES. 1/4W J 330K OHM 1
R1035 CARBON RES. 1/6W J 100K OHM 1
R1035 CARBON RES. 1/4W J 100K OHM 1
R1037 CARBON RES. 1/6W J 10K OHM 1
R1037 CARBON RES. 1/4W J 10K OHM 1
R1038 CARBON RES. 1/6W J 100K OHM 1
R1038 CARBON RES. 1/4W J 100K OHM 1
R1039 CARBON RES. 1/6W J 470K OHM 1
R1039 CARBON RES. 1/4W J 470K OHM 1
R1043
METAL OXIDE FILM RES. 2W J 1.8
OHM
1
R1043
METAL OXIDE FILM RES. 2W J 1.8
OHM
1
R1044 CARBON RES. 1/4W J 1K OHM 1
FRONT JACK CBA
JK2800 996510002073
RCA JACK(RED) MTJ-032-11A-31
FE01
1
JK2801 996510002074
RCA JACK(WHITE) MTJ-032-11B-41
FE01
1
JK2803 996510002075
RCA JACK(YELLOW) MTJ-032-11B-
40 FE01
1
JK2806 996510002055 S TYPE JACK MDC-050V-2.4 LF(B110 1
JK2806 996510002056 S TYPE JACK DIN-425-01 1
W003
WIRE ASSEMBLY FFC 8PIN
FFC_8PIN/105MM/P1.25
1
CAPACITORS
C2800 CERAMIC CAP.(AX) B K 1000PF/50V 1
C2801 CERAMIC CAP.(AX) B K 1000PF/50V 1
CONNECTOR
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
