20070328 1-19-12 E9H90EL
CN2605
FE CONNECTOR TOP 8P 08FE-BT-
VK-N
1
RESISTORS
R2800 CARBON RES. 1/6W J 180K OHM 1
R2800 CARBON RES. 1/4W J 180K OHM 1
R2801 CARBON RES. 1/6W J 180K OHM 1
R2801 CARBON RES. 1/4W J 180K OHM 1
R2804 CARBON RES. 1/6W J 75 OHM 1
R2804 CARBON RES. 1/4W J 75 OHM 1
R2812 CARBON RES. 1/6W J 75 OHM 1
R2812 CARBON RES. 1/4W J 75 OHM 1
R2815 CARBON RES. 1/6W J 75 OHM 1
R2815 CARBON RES. 1/4W J 75 OHM 1
ASSY 4 996510002076 TUNER ASSEMBLY 1
Consists of the following:
ASSY 4a TUNER CBA 1
ASSY 4b 996510002081 DTV MODULE CBA UNIT 1
TUNER CBA
2B86 HIMELON TAPE(30*5) E7C40UD 1
BC5001
BEAD INDUCTOR FBR07HA121TB-
00
1
JC5002 CHIP RES.(1608) 1/10W 0 OHM 1
JC5002 RES CHIP 1608 1/10W J 0 OHM 1
JC5004 CHIP RES.(1608) 1/10W 0 OHM 1
JC5004 RES CHIP 1608 1/10W J 0 OHM 1
JC5005 CHIP RES.(1608) 1/10W 0 OHM 1
JC5005 RES CHIP 1608 1/10W J 0 OHM 1
JP5001 PCB JUMPER D0.6-P5.0 1
JP5002 PCB JUMPER D0.6-P12.5 1
JP5003 PCB JUMPER D0.6-P5.0 1
JP5008 PCB JUMPER D0.6-P7.5 1
JP5009 PCB JUMPER D0.6-P7.5 1
JP5010 PCB JUMPER D0.6-P15.0 1
JP5011 PCB JUMPER D0.6-P15.0 1
JP5013 PCB JUMPER D0.6-P10.0 1
JP5014 PCB JUMPER D0.6-P7.5 1
JP5015 PCB JUMPER D0.6-P17.5 1
JP5016 PCB JUMPER D0.6-P17.5 1
JP5017 PCB JUMPER D0.6-P6.0 1
JP5018 PCB JUMPER D0.6-P6.0 1
JP5019 PCB JUMPER D0.6-P6.5 1
JP5020 PCB JUMPER D0.6-P5.0 1
JP5022 PCB JUMPER D0.6-P12.5 1
JP5023 PCB JUMPER D0.6-P15.0 1
JP5025 PCB JUMPER D0.6-P20.0 1
JP5026 PCB JUMPER D0.6-P17.5 1
JP5027 PCB JUMPER D0.6-P11.5 1
JP5028 PCB JUMPER D0.6-P7.5 1
JP5029 PCB JUMPER D0.6-P17.5 1
JP5030 PCB JUMPER D0.6-P5.0 1
JP5031 PCB JUMPER D0.6-P9.0 1
JP5033 PCB JUMPER D0.6-P5.0 1
JP5034 PCB JUMPER D0.6-P6.5 1
JP5037 PCB JUMPER D0.6-P12.5 1
TU5001 996510002080 TUNER 115U1003AF 1
W501
WIRE ASSEMBLY 20PIN FFC 20P/
90MM
1
CAPACITORS
C5001 ELECTROLYTIC CAP. 4.7UF/50V M 1
C5002 ELECTROLYTIC CAP. 2.2UF/50V M 1
C5003 ELECTROLYTIC CAP. 2.2UF/50V M 1
C5004 ELECTROLYTIC CAP. 2.2UF/50V M 1
C5005 ELECTROLYTIC CAP. 10UF/16V M 1
C5006 ELECTROLYTIC CAP. 3.3UF/50V M 1
C5007 ELECTROLYTIC CAP. 3.3UF/50V M 1
C5008
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
C5009
CHIP CERAMIC CAP.(1608) B K
0.022UF/50V
1
C5010 ELECTROLYTIC CAP. 2.2UF/50V M 1
C5011
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C5013
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C5014
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C5015 ELECTROLYTIC CAP. 0.33UF/50V M 1
C5016
CHIP CERAMIC CAP.(1608) CH J
1000PF/50V
1
C5017 ELECTROLYTIC CAP. 1UF/50V M H7 1
C5018 ELECTROLYTIC CAP. 1UF/50V M H7 1
C5019
CHIP CERAMIC CAP.(1608) B K
0.033UF/50V
1
C5020
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C5022 ELECTROLYTIC CAP. 100UF/6.3V M 1
C5023
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C5024
CHIP CERAMIC CAP.(1608) B K
0.1UF/50V
1
C5032
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C5033
CHIP CERAMIC CAP.(1608) B K
0.01UF/50V
1
C5039 CHIP CERAMIC CAP. F Z 0.01UF/50V 1
C5043
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
C5051
CHIP CERAMIC CAP.(1608) CH J
47PF/50V
1
C5052 ELECTROLYTIC CAP. 1000UF/6.3V M 1
C5053 ELECTROLYTIC CAP. 100UF/6.3V M 1
C5057
CHIP CERAMIC CAP.(1608) CH J
47PF/50V
1
C5058 ELECTROLYTIC CAP. 10UF/16V M 1
C5059 ELECTROLYTIC CAP. 10UF/16V M 1
C5067
CHIP CERAMIC CAP.(1608) F Z
0.1UF/50V
1
CONNECTORS
CN5003
WIRE ASSEMBLY 6PIN FFC 6PIN/
225MM
1
CN5006 18PIN FFC WX1E9H00-001 1
CN5007
FMN CONNECTOR SIDE 20P
20FMN-STRK-A(LF)(SN)
1
DIODES
D5003 SWITCHING DIODE 1SS133(T-77) 1
D5003 DIODE SWITCHING 1N4148-F0021 1
D5003 SWITCHING DIODE 1N4148M 1
ICS
IC5001 996510002077 IC MTS DECORDER AN5832SA-E1V 1
IC5003 996510002078 EEP-ROM 128K M24128-BWMN6TP 1
IC5003 996510002079 IC EEPROM AT24C128N-10SU-1.8 S 1
COILS
L5001 PCB JUMPER D0.6-P5.0 1
L5007 CHOKE COIL 22UH-K 1
L5007 CHOKE COIL 22UH-K 1
L5008 PCB JUMPER D0.6-P5.0 1
L5009 PCB JUMPER D0.6-P5.0 1
TRANSISTORS
Q5002 TRANSISTOR KTC3199-GR-AT/P 1
Q5002 TRANSISTOR 2SC1815-GR(TE2 F T) 1
Q5002 TRANSISTOR KTC3199-Y-AT/P 1
Q5002 TRANSISTOR 2SC1815-Y(TE2 F T) 1
Q5003 TRANSISTOR KTC3199-GR-AT/P 1
Q5003 TRANSISTOR 2SC1815-GR(TE2 F T) 1
Q5003 TRANSISTOR KTC3199-Y-AT/P 1
Q5003 TRANSISTOR 2SC1815-Y(TE2 F T) 1
RESISTORS
ELECTRICAL PARTS LIST
DVDR3545V/37
Pos.No. # 12 NC Description
