Philips DVP3350V - Section 5: Mechanism of DVD Part (DP-10 C)

DECK MECHANISM PARTS
LOCATIONS
• Top View..................................................5-1
• Top View(without Tray Disc) .................5-1
• Bottom View ...........................................5-1
DECK MECHANISM
DISASSEMBLY
1. Main Base .........................................5-2
1-1. Clamp Assembly Disc.......................5-2
1-1-1. Plate Clamp ..................................5-2
1-1-2. Magnet Clamp ..............................5-2
1-1-3. Clamp Upper.................................5-2
2. Tray Disc ...........................................5-2
3. Base Assembly Sled........................5-3
3-1. Gear Feed.........................................5-3
3-2. Gear Middle ......................................5-3
3-3. Gear Rack.........................................5-3
4. Rubber Rear......................................5-3
5. Frame Assembly Up/Down..............5-4
6. Belt Loading......................................5-4
7. Gear Pulley .......................................5-4
8. Gear Loading....................................5-4
9. Guide Up/Down.................................5-4
10. PWB Assembly Loading................5-4
11. Base Main........................................5-4
EXPLODED VIEW
1. Deck Mechanism Exploded View....5-5
CONTENTS
SECTION 5 MECHANISM OF DVD PART (DP-10C)
