SERVICE INFORMATION FOR EEPROM IC SETTING(VCR)
MODEL NAME HEX BINARY
DVP3350V/01 OPT0 90 00000000
OPT1 F4 00000000
OPT2 60 00000000
OPT3 40 00000000
OPT4 03 00000000
OPT5 4B 00000000
DVP3350V/02 OPT0 90 00000000
OPT1 D4 00000000
OPT2 6B 00000000
OPT3 40 00000000
OPT4 0D 00000000
OPT5 4B 00000000
DVP3350V/05 OPT0 90 00000000
OPT1 F4 00000000
OPT2 21 00000000
OPT3 80 00000000
OPT4 0D 00000000
OPT5 4B 00000000
DVP3350V/19 OPT0 90 00000000
OPT1 FC 00000000
OPT2 E8 00000000
OPT3 40 00000000
OPT4 06 00000000
OPT5 4B 00000000
WR : OK I : EXIT MOVE :
EDIT :
1. DETECT NEW EEPROM (OPTION EDIT
SCREEN)
- Eeprom EDIT screen automatically appears if
replacing Eeprom.
- Setup option data using the cursor Up/Down key
of a remote control.
(Setup upon BOM depending on OPT0~OPT5
model)
• Since an initial remote control is set to LG for LG
model, appropriately set optiona data using the
cursor Up/Down key.
2. EEPROM WRITED AND EEPROM INITIAL
- Writes data on EEPROM by using REMOCON
"OK" + FRONT PLAY KEY FOR MORE THAN 5
SECONDS.
3. PG ADJUST
1) Payback the SP standard tape
2) Press the “OK” key on the Remote controller
and the “PLAY” key on the Front Panel the
same time, then it goes in to Tracking initial
mode.
3) Repeat the above step(No.2), then it finishes
the PG adjusting automatically.
4) Stop the playback, then it goes out to PG
adjusting mode after mony the PG data.
EEPROM option code No. setting EEPROM option code No. setting procedure
NAME HEX BINARY
OPT0 00 00000000
OPT1 00 00000000
OPT2 00 00000000
OPT3 00 00000000
OPT4 00 00000000
OPT5 00 00000000
12/26 - 00 V00 <--- μ-COM Ver.
ID : LG
VERSION : 05 ROM
DATE : 02.17.05 Correction Ver.
