Philips DVP3350V - Page 21

3-5
No Motor_Vcc
Check or Replace
the D124
Is the Vcc(14V)
supplied to C134?
Check or Replace
the Cap / Drum
NO
YES
YES
(6) No Motor_Vcc (To Cap, Drum Motor )
No REG 12V
Is the Vcc(14V) supplied
to Q165 Collector?
YES
Is the Vcc(14V) sup-
plied to Q165 Base?
YES
Check or Replace
the Q165
YES
(7) No REG 12V
Check or Replace
the D124
NO
NO
Check the PWR CTL
“H” signal from μ-com
