A
RESET or Power On.
Flash Memory operates
properly?
Show LOGO?
Does Tray move inside when
it is not at closed position?
B
Check connection lines between
FLASH & ZR36882 and the FLASH
access time whether is suitable or not.
SDRAM works properly?
Check connection lines
between SDRAM & ZR36882
and the SDRAM is damaged.
ZR36882 VIDEO outputs
properly?
Check the related circuit of
ZR36882
Have TV signal output?
Check AV cable connection
to TV set.
Normal OUTSW & INSW
signals?
Check the filtering and amp
circuit of TV signal.
Check the load OPEN &
CLOSE switch
Normal OPEN & CLOSE
signal?
Check the Tray control IO
pins on ZR36882 &
AM5869S
Normal LOAD+ & LOAD -
signal?
Check the cable connection
between main PCBA and
loader.
Check the Tray control
amplifying circuit on Motor
driver.
To Next Page
