Philips DVP620VR/00 - Page 173

1-18-1
ELECTRICAL PARTS LIST
MISCELLANEOUS
9965 000 24113 DVD MAIN CBA UNIT
9965 000 24114 MCV CBA
9965 000 24118 SENSOR CBA
MCV CBA UNIT
MCV CBA UNIT consists of MAIN CBA, POWER SWITCH CBA, DVD OPEN/
CLOSE CBA and SENSOR CBA.
MAIN CBA
MISCELLANEOUS
F1001! 9965 000 24157 FUSE SIC 1A 250V U/C T
FIP502 9965 000 23984 V.F.D. 7-BT-298N
GP1001! 9965 000 08671
!
GAP. FNR-G3.10D
JK751 4822 265 11657 MSP-283V-B-324
JK752 4822 265 11656 MSP-293V3-324
JK753 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B
JK754 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B
JK755 9965 000 00423 MSP-281V3-A RCA JACK(RED)
JK756 9965 000 13039 RCA JACK 0.01282V-12 PBSN
JK1202 9965 000 15322 RCA JACK(BLACK) MSP-281V2-B
JK1401 9965 000 15323 S TYPE JACK MDC-050V-2.4
JK1403 9965 000 24161 RCA JACK MSP-283V-B-752 NI LF
RM2001 9965 000 10857 REMOTE RECEIVER
SA1001! 9965 000 20946
!
SURGE ABSORBER PVR-10D471KB
SW502 4822 276 13954 KSM0614B
SW502 9965 000 19590 TC-1104 (ALTERNATIVE)
SW505 4822 276 13954 KSM0614B
SW505 9965 000 19590 TC-1104 (ALTERNATIVE)
SW508 4822 276 13954 KSM0614B
SW508 9965 000 19590 TC-1104 (ALTERNATIVE)
SW509 4822 276 13954 KSM0614B
SW509 9965 000 19590 TC-1104 (ALTERNATIVE)
SW511 9965 000 16625 LEAF SWITCH MXS01830MVP0
SW512 9965 000 23359 ROTARY MODE SWITCH SSS-53MD
SW513 4822 276 13954 KSM0614B
SW513 9965 000 19590 TC-1104 (ALTERNATIVE)
SW514 4822 276 13954 KSM0614B
SW514 9965 000 19590 TC-1104 (ALTERNATIVE)
SW515 4822 276 13954 KSM0614B
SW515 9965 000 19590 TC-1104 (ALTERNATIVE)
SW516 4822 276 13954 KSM0614B
SW516 9965 000 19590 TC-1104 (ALTERNATIVE)
SW2002 4822 276 13954 KSM0614B
SW2002 9965 000 19590 TC-1104 (ALTERNATIVE)
SW2003 4822 276 13954 KSM0614B
SW2003 9965 000 19590 TC-1104 (ALTERNATIVE)
T001! 9965 000 24166 SWITCHING TRANSFO CSA-SW0412A
TU701 9965 000 24167 TUNER UNIT VH025AFE
W001 9965 000 24168 FFC CABLE, 27P FFC/P1.00/230
W003 9965 000 24169 FFC CABLE, 19P FFC/P1.00/195
X301 9965 000 12363 X’TAL 3.579545MHZ(20PPM)
X301 9965 000 24170 X’TAL 3.579545MHZ (ALTERNATIVE)
X501 9965 000 09220 X’TAL 14.31818MHZ
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM)
X502 9965 000 19592 X’TAL 32.768KHZ(20PPM) (ALTERNATIVE)
CAPACITORS
C020 4822 124 12427 1000UF 20% 10V
C424 9965 000 15255 CERAMIC CAP. B K 470PF/100V
C425 9965 000 24150 FILM CAP.(P) 0.018UF/100V J
C1001! 9965 000 24151
!
MET. FILM 0.022UF/275
C1001! 9965 000 24152
!
MET. FILM 0.022UF/250 (ALTERNATIVE)
C1003 4822 126 14142 0.01UF 500V
C1004 9965 000 24153 ELCAP 220UF/200V M
C1005 9965 000 08657 CAP B K 120PF/500V
C1006! 9965 000 05384
!
SAFETY CAP. 3300PF/250V
C1007 9965 000 24154 ELCAP 1000UF/6.3V M
C1008 9965 000 08657 CAP B K 120PF/500V
C1023 9965 000 15255 CERAMIC CAP. B K 470PF/100V
RESISTORS
R1004 4822 053 11823 82K 5% 2W
R1011 9965 000 24164 METAL OXIDE 0.68R 1W
R1011 9965 000 24165 METAL OXIDE 0.68R 1W
R1043 9965 000 19665 METAL OXIDE 2.7R 1W
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B
DIODES
D013 4822 130 11654 BA158
D015 9965 000 24155 SCHOTTKY BARRIER DIODE SB370
D016 4822 130 32715 SB340
D030 4822 130 11654 BA158
D031 9965 000 23356 DZ-18BSBT265
D040 9965 000 14881 DZ-6.8BSBT265
D052 9965 000 09283 DZ-10BSBT265
D080 4822 130 31933 1N5061
D081 4822 130 31933 1N5061
D082 4822 130 31933 1N5061
D100 4822 130 30621 1N4148
D101 4822 130 30621 1N4148
D501 4822 130 30621 1N4148
D502 4822 130 30621 1N4148
D504 9965 000 23356 DZ-18BSBT265
D510 4822 130 30621 1N4148
D555 9965 000 19572 LED MIE-534A2
D566 9965 000 24156 LED(YELLOW) 204YD/E
D567 9965 000 24156 LED(YELLOW) 204YD/E
D701 9965 000 09183 DZ-33BSDT265
D1001 4822 130 31933 1N5061
D1002 4822 130 31933 1N5061
D1003 4822 130 31933 1N5061
D1004 4822 130 31933 1N5061
D1008 5322 130 81917 SB140
D1010 4822 130 11654 BA158
