DIODES
ELECTRICAL PARTS LIST
1-18-2
D1011 4822 130 11654 BA158
D1012 4822 130 30621 1N4148
D1016 9965 000 14882 RECTIFIER DIODE FR101
D1017 9965 000 23356 DZ-18BSBT265
D1018 4822 130 30621 1N4148
D1020 5322 130 81917 SB140
D1022 4822 130 30621 1N4148
D1024 4822 130 30621 1N4148
D1025 4822 130 30621 1N4148
D1036 4822 130 31933 1N5061
D1037 4822 130 31933 1N5061
D1038 4822 130 31933 1N5061
D1058 4822 130 31933 1N5061
D1301 9965 000 08622 DZ-5.6BSBT265
INTEGRATED CIRCUITS
IC301 9965 000 24158 IC:Y/C/A LA71205M-MPB-E
IC451 9965 000 24159 IC:HIFI LA72670BM-MPB-E
IC501 9965 000 24160 MICROCONT. 8BIT MN101D08DFT
IC571 9965 000 19575 FL DRIVER IC PT6313-S-TP
IC751 9965 000 13852 IC:SWITCH TC4053BF(N) OR
IC751 9965 000 23979 MUX CD4053BCSJX (ALTERNATIVE)
IC752 9965 000 13852 IC:SWITCH TC4053BF(N) OR
IC752 9965 000 23979 MUX CD4053BCSJX (ALTERNATIVE)
IC1001! 4822 130 11655
!
PHOTOCOUPLER LTV817B-F
IC1001! 9965 000 19657
!
EL817B (ALTERNATIVE)
IC1001! 9965 000 24000
!
PS2561A-1(Q) (ALTERNATIVE)
IC1001! 9965 000 09187
!
LTV-817C-F (ALTERNATIVE)
IC1002 9965 000 23986 VOLTAGE REG PQ070XZ5MZP
IC1004 9965 000 23987 VOLTAGE REG BA3948FP-E2
IC1201 9965 000 15314 IC:OP AMP KIA4558P
IC1402 9965 000 23981 DRIVER FOR DVD MM1637XVBE
IC1403 9965 000 23989 DRIVER FOR DVD MM1636XWRE
COILS & FILTERS
L009 9965 000 05627 CHOKE COIL 47UH-K
L009 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L303 4822 157 10649 100UH
L304 9965 000 05627 CHOKE COIL 47UH-K
L304 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L421 9965 000 05705 INDUCTOR 47UH-K-5FT
L502 9965 000 05627 CHOKE COIL 47UH-K
L502 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L701 4822 157 11312 4.7UH 10%
L1001! 9965 000 24162 LINE FILTER 27MH TLF14CB2730R4
L1004 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1007 9965 000 05627 CHOKE COIL 47UH-K
L1007 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L1020 9965 000 05627 CHOKE COIL 47UH-K
L1020 9965 000 23990 CHOKE COIL 47UH-K (ALTERNATIVE)
L1350 4822 157 10649 100UH
L1351 9965 000 15331 INDUCTOR 0.47UH-K-26T
L1522 9965 000 05705 INDUCTOR 47UH-K-5FT
L2001 4822 157 10649 100UH
TRANSISTORS
Q031 4822 130 63144 2SA1267(YG)
Q031 4822 130 11646 2SA1175J (ALTERNATIVE)
Q031 9965 000 05644 2SA1175(F) (ALTERNATIVE)
Q052 9965 000 23377 RES. BUILT-IN KRC103M
Q055 4822 130 63485 KTC3198-Y
Q055 9965 000 05370 2SC536NF-NPA-AT (ALTERNATIVE)
Q056 4822 130 42292 2SC2120Y
Q057 4822 130 10923 KTC3199(BL)
Q057 4822 130 41319 2SC1815BL (ALTERNATIVE)
Q301 4822 130 42959 2SA1015Y
Q302 4822 130 10102 KTC3193Y
Q391 4822 130 42959 2SA1015Y
Q421 4822 130 42959 2SA1015Y
Q422 4822 130 42292 2SC2120Y
Q425 4822 130 10145 KRA103M
Q426 9965 000 12361 CHIP RN1511(TE85R)
Q501 4822 130 10923 KTC3199(BL)
Q501 4822 130 41319 2SC1815BL (ALTERNATIVE)
Q506 9965 000 08630 PHOTO PT204-6B-12
Q566 4822 130 10103 KTC3199Y
Q566 4822 130 11647 2SC2785J (ALTERNATIVE)
Q566 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q567 4822 130 10103 KTC3199Y
Q567 4822 130 11647 2SC2785J (ALTERNATIVE)
Q567 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q1001! 9965 000 24163
!
FET 2SK3543
Q1003 4822 130 41306 2SC1815GR
Q1004 4822 130 42292 2SC2120Y
Q1005 4822 130 10103 KTC3199Y
Q1005 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1005 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q1006 4822 130 63144 2SA1267(YG)
Q1006 4822 130 11646 2SA1175J (ALTERNATIVE)
Q1006 9965 000 05644 2SA1175(F) (ALTERNATIVE)
Q1008 4822 130 10103 KTC3199Y
Q1011 4822 130 42292 2SC2120Y
Q1201 4822 130 10103 KTC3199Y
Q1201 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1201 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q1202 4822 130 10103 KTC3199Y
Q1202 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1202 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q1204 4822 130 42959 2SA1015Y
Q1351 4822 130 10103 KTC3199Y
Q1351 4822 130 11647 2SC2785J (ALTERNATIVE)
Q1351 9965 000 05643 2SC2785(F) (ALTERNATIVE)
Q1385 4822 130 10103 KTC3199Y
Q1385 4822 130 11647 2SC2785J (ALTERNATIVE)
