Philips DVP620VR/00 - Page 370

TRANSISTORS
ELECTRICAL PARTS LIST
1-18-3
Q1352 * 9965 000 09882 TRANSISTOR BN1L4M-T
Q1502 9965 000 16624 CHIP TRANSISTOR KRC103S RTK
Q1502 * 9965 000 12361 CHIP TRANSISTOR RN1511(TE85R)
Q1503 9965 000 13683 CHIP TRANSISTOR KTC3875Y-RTK
INTEGRATED CIRCUITS
IC101 9965 000 13852 IC:SWITCH TC4053BF(N) OR
IC101 * 9965 000 23979 MULTIPLEXERS CD4053BCSJX
IC102 9965 000 23981 DRIVER FOR DVD MM1637XVBE
IC301 9965 000 12180 IC:Y/C/A LA71750AM-MTB
IC451 9965 000 16618 IC:HIFI LA72648M
IC501 9965 000 25724 SYSCON IC M3776AMFA-AC4GP
IC502 9965 000 16620 IC:EEPROM CAT24WC02JI
IC611 9965 000 23984 V.F.D. 7-BT-298N
IC612 9965 000 19575 FL DRIVER IC PT6313-S-TP
IC631 9965 000 12198 IC:VPS/PDC SLICER LC74793JM-TRM
IC751 9965 000 13852 IC:SWITCH TC4053BF(N) OR
IC751 * 9965 000 23979 MULTIPLEXERS CD4053BCSJX
IC775 9965 000 12184 IC:COMPARATOR KIA339F EL
IC1002 9965 000 23986 VOLTAGE REG PQ070XZ5MZP
IC1003 9965 000 23987 VOLTAGE REG BA3948FP-E2
IC1201 9965 000 15314 IC:OP AMP KIA4558P
IC1201 * 9965 000 25723 IC:OP AMP RC4580IP
IC1204 9965 000 15318 FIBER OPTIC TRANS.MODULE 0C-0805
IC1403 * 9965 000 23989 DRIVER FOR DVD MM1636XWRE
IC1404 9965 000 13852 IC:SWITCH TC4053BF(N) OR
IC1404 * 9965 000 23979 MULTIPLEXERS CD4053BCSJX
POWER SW CBA
D651 9965 000 08621 LED(RED) 204HD/E
SW651 4822 276 13954 KSM0614B
SW651 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
DVD OPEN/CLOSE CBA
SW2020 4822 276 13954 TACT SWITCH KSM0614B
SW2020 * 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SENSOR CBA
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12
Q503 * 9965 000 20922 PHOTO TRANSISTOR MID-32A22F
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12
Q504 * 9965 000 20922 PHOTO TRANSISTOR MID-32A22F
AFV PCB ASSEMBLY CPD0500/9701
D2 4822 130 30621 1N4148
D2 * 4822 130 32778 1SS133
IC1 9965 000 14760 AUD UP MSP3417G-QG-B8-V3
L1 4822 157 10889 10UH
L3 4822 157 11318 18UH 10%
L4 4822 157 10889 10UH
X1 9965 000 12200 X’TAL 18.432MHZ
Note: Only the parts mentioned in this list are normal service spare parts.
PSV CBA UNIT
PSV CBA UNIT consists of POWER SUPPLY CBA, JUNCTION and JACK CBA
POWER SUPPLY CBA
MISCELLANEOUS
AC1001! 9965 000 20940
!
MAINS CORD
F1001! 4822 070 31602
!
FUSE 1.6A 250V
SA1001 9965 000 20946
!
SURGE ABSORBER PVR-10D471KB
SA1001 4822 252 11373
!
JVR-10N471K
T0011! 9965 000 24005
!
SWITCHING TRANSFORMER
CAPACITORS
C013 9965 000 14852 ELCAP. 10UF /50V M
C013 * 9965 000 19661 ELCAP. 10UF /50V M
C014 9965 000 14853 ELCAP. 470UF /16V M
C014 * 9965 000 19567 ELCAP. 470UF /16V M
C015 9965 000 15246 ELCAP. 100UF /16V M
C015 * 9965 000 09789 CHIP CAP CG J 68PF/50V
C017 9965 000 14857 ELCAP. 1000UF /16V M
C018 4822 124 42027 470UF 20% 6,3V
C018 * 9965 000 19558 ELCAP. 470UF /6.3V M
C020 4822 124 81151 22UF 50V
C020 * 9965 000 19549 ELCAP. 22UF /50V M
C022 9965 000 19663 ELCAP. 470UF /35V M
C022 * 9965 000 19655 ELCAP. 470UF /35V M
C1001! 9965 000 14854
!
MET FILM CAP. 0.068UF /275V K
C1001! * 9965 000 06521
!
METALLIZED FILM CAP. 0.068UF /250
C1001! * 9965 000 23998
!
MET FILM 0.068UF /250V K
C1001! * 9965 000 09743
!
METALLIZED FILM CAP. 0.068UF /250
C1004 4822 124 12446 1000UF 20% 400V
C1005 4822 126 14141 56PF 1KV
C1005 * 9965 000 06567 CERAMIC CAP. SL J 56PF/1KV
C1006! 9965 000 23354
!
SAFTY CAP. 2200PF/250V
C1007 9965 000 19664 ELCAP. 1000UF /6.3V M
C1018 4822 124 41584 100UF 20% 10V
C1018 * 9965 000 19666 ELCAP. 100UF /10V M
C1032 9965 000 09762 ELCAP 220UF /6.3V M H7
C1032 * 9965 000 19554 ELCAP. 10UF /16V M
C1035 4822 124 42027 470UF 20% 6,3V
C1035 * 9965 000 19558 ELCAP. 470UF /6.3V M
C1106 9965 000 19667 ELCAP. 100UF /35V M
C1106 * 9965 000 19656 ELCAP. 100UF /35V M
C1107 9965 000 09827 CHIP CAP CH J 100PF/50V
