Philips DVP620VR/00 - Page 371

ELECTRICAL PARTS LIST
CAPACITORS
1-18-4
C1107 * 9965 000 19660 ELCAP. 220UF /6.3V M
C2014 4822 126 14142 0.01UF 500V
C2015 4822 124 42027 470UF 20% 6,3V
C2015 * 9965 000 19558 ELCAP. 470UF /6.3V M
RESISTORS
R1001 9965 000 20944
!
GL GLAZE RES. 1/2W J 5.6MOHM
R1001 * 9965 000 24001
!
POWER ANTI-S1/2W J 5.6M OHM
R1004 4822 053 11823 82K 5% 2W
R1004 * 9965 000 24002 METAL OXIDE 2W J 82K OHM
R1011 9965 000 24003 METAL OXIDE 1W J 1.3 OHM
R1043 9965 000 09861 METAL OXIDE FILM RES. 1W J 150K
R1043 * 4822 117 12744 2.7R 5% 1W
R1043 * 9965 000 24004 METAL OXIDE 1W J 2.7 OHM
COILS & FILTERS
L010 9965 000 05627 CHOKE COIL 47UH-K
L010 * 9965 000 05702 CHOKE COIL 47UH-K
L010 * 9965 000 23990 CHOKE COIL 47UH-K
L013 9965 000 05627 CHOKE COIL 47UH-K
L013 * 9965 000 05702 CHOKE COIL 47UH-K
L013 * 9965 000 23990 CHOKE COIL 47UH-K
L1001 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1002 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1003! 9965 000 13005
!
LINE FILTER 50MH LF-4D-E503 OR
L1004 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1005 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1009 9965 000 05627 CHOKE COIL 47UH-K
L1009 * 9965 000 05702 CHOKE COIL 47UH-K
L1009 * 9965 000 23990 CHOKE COIL 47UH-K
L1011 9965 000 05627 CHOKE COIL 47UH-K
L1011 * 9965 000 05702 CHOKE COIL 47UH-K
L1011 * 9965 000 23990 CHOKE COIL 47UH-K
L1012 9965 000 05627 CHOKE COIL 47UH-K
L1012 * 9965 000 05702 CHOKE COIL 47UH-K
L1012 * 9965 000 23990 CHOKE COIL 47UH-K
DIODES
D013 4822 130 11654 BA158
D014 9965 000 19668 SCHOTTKY BARRIER DIODE SB390
D015 9965 000 08649 ZENER DIODE DZ-5.6BSCT265
D015 * 4822 130 10926 UZ5.6BSC
D016 4822 130 32715 SB340
D017 9965 000 23356 ZENER DIODE DZ-18BSBT265
D017 * 9965 000 13882 ZENER DIODE MTZJT-7718B OR
D018 4822 130 11654 BA158
D019 9965 000 19669 RECTIFIER DIODE FR203
D1001 4822 130 31933 1N5061
D1001 * 9965 000 23978 1N4005
D1002 4822 130 31933 1N5061
D1002 * 9965 000 23978 1N4005
D1003 4822 130 31933 1N5061
D1003 * 9965 000 23978 1N4005
D1004 4822 130 31933 1N5061
D1004 * 9965 000 23978 1N4005
D1006 4822 130 30621 1N4148
D1006 * 4822 130 32778 1SS133
D1008 5322 130 81917 SB140
D1011 5322 130 34979 BYV96E
D1011 * 9965 000 23999 BA159
D1011 * 4822 130 81244 ERA22-10
D1012 4822 130 30621 1N4148
D1012 * 4822 130 32778 1SS133
D1016 9965 000 14882 RECTIFIER DIODE FR101
D1017 9965 000 23356 ZENER DIODE DZ-18BSBT265
D1017 * 9965 000 13882 ZENER DIODE MTZJT-7718B OR
D1018 4822 130 30621 1N4148
D1018 * 4822 130 32778 1SS133
D1019 9965 000 14881 ZENER DIODE DZ-6.8BSBT265
D1019 * 9965 000 23556 ZENER DIODE MTZJT-776.8B
D1022 4822 130 30621 1N4148
D1022 * 4822 130 32778 1SS133
D1024 4822 130 30621 1N4148
D1024 * 4822 130 32778 1SS133
D1025 4822 130 30621 1N4148
D1025 * 4822 130 32778 1SS133
D1030 5322 130 81917 SB140
TRANSISTORS
Q1001 9965 000 17186
!
FET 2SK3566
Q1003 4822 130 41306 2SC1815GR
Q1004 4822 130 10462 KTA1267-GR
Q1004 * 4822 130 11482 KTA1267(Y)
Q1004 * 4822 130 11646 2SA1175J
Q1004 * 9965 000 19587 TRANSISTOR 2SA1175(H)
Q1004 * 9965 000 05644 TRANSISTOR 2SA1175(F)
Q1008 4822 130 10103 KTC3199Y
Q1008 * 9965 000 10994 2SC3199-GR/KTC3199-GR
Q1008 * 4822 130 11647 2SC2785J
Q1008 * 9965 000 19583 TRANSISTOR 2SC2785(H)
Q1008 * 9965 000 05643 TRANSISTOR 2SC2785(F)
Q1008 * 9965 000 09882 TRANSISTOR BN1L4M-T
Q1008 * 4822 130 41306 2SC1815GR
INTEGRATED CIRCUITS
IC1001! 9965 000 19672
!
PHOTOCOUPLER EL817A
IC1001! 9965 000 24000
!
PHOTOCOUPLER PS2561A-1(Q)
JUNCTION CBA
CN051A 9965 000 20932 CONNECTOR, 18P TUC-P18X-B1
