3-67
6. LASER POWER CONTROL RELATED SIGNAL(NO DISC CONDITION)
MDI1(0V/180mV)
LD01(5.0V//3.5V)
LD02(5.0V/3.6V)
FIG 6-1
7. DISC TYPE JUDGEMENT WAVEFORM
F+
FE
RFL
FIG 7-1 (DVD)
