20 21
Lock status indicator
Low battery indicator
Outside forced lock indicator
Colors of the light and the corresponding
meanings:
Blue: After the system wakes up, the light will
glow blue, indicating that you can operate the
lock.
Green: After the door is unlocked, the light will
glow green, indicating that the door has been
opened.
Red: After the door is locked, the light will glow
red, indicating that the door has been closed.
Colors of the light and the corresponding
meanings:
Red: After waking up, the system will run an
automatic examination on the battery voltage.
If the voltage is too low, the light will ash in
red and there will be a voice prompt of “Low
battery. Please replace all batteries”.
Colors of the light and the corresponding
meanings:
White:
1. When the door is locked, the light will light
up alone, indicating that you can enable the
outside forced lock function.
2. If you have enabled the outside forced lock
function, the light will light up after the system
wakes up, indicating this function is in use.
7 Meanings and use of the indicators
Outside forced
Low battery
Mute mode indicator
Colors of the light and the
corresponding meanings:
1. White: Indicates the mute mode is o.
2. Green:Indicates the mute mode is on.
Inside deadlock indicator
System lock indicator
When the door is inside dead locked,
the digital functions of the outside
escutcheon will be disabled.
If the system is waken up manually, the
keypad will display the combination of “15937
(X)” and there will be a voice prompt saying
that the inside deadlock has been enabled.
3 ashes 2 ashes 1 ash
Only when touching to wake
up the keypad or inputting the
locked type of verication will
the system give such a prompt.
Mute mode
Attention
3 minutes 2 minutes 1 minute
If there are 5 consecutive
and incorrect inputs of any
of the 3 types of verication
information (ngerprint/
PIN code/card), this type of
verication will be locked for
3 minutes.
Lock
status
indicator
indicator
lock indicator
indicator
