Philips FW-D5/21 - Electrical Parts List - Front Board

1401 4822 276 13775 Tact Switch
1402 4822 276 13775 Tact Switch
1403 4822 276 13775 Tact Switch
1404 4822 276 13775 Tact Switch
1405 4822 276 13775 Tact Switch
1406 4822 265 11207 Flex Connector 6P
1411 4822 267 10733 Flex Connector 4P
1421 4822 276 13775 Tact Switch
1422 4822 276 13775 Tact Switch
1423 4822 276 13775 Tact Switch
1424 4822 276 13775 Tact Switch
1425 4822 276 13775 Tact Switch
1426 4822 276 13775 Tact Switch
1427 4822 276 13775 Tact Switch
1428 4822 276 13775 Tact Switch
1429 4822 276 13775 Tact Switch
1430 4822 276 13775 Tact Switch
1431 4822 276 13775 Tact Switch
1432 4822 276 13775 Tact Switch
1435 4822 267 10958 Flex Connector 5P
1436 2422 129 16348 Rotary Encoder 24P
1441 4822 276 13775 Tact Switch
1442 4822 276 13775 Tact Switch
1443 4822 276 13775 Tact Switch
1444 4822 276 13775 Tact Switch
1445 4822 276 13775 Tact Switch
1446 4822 276 13775 Tact Switch
1447 4822 276 13775 Tact Switch
1448 4822 276 13775 Tact Switch
1449 4822 276 13775 Tact Switch
1450 4822 276 13775 Tact Switch
1451 4822 276 13775 Tact Switch
1457 3139 110 52380 FTD Display
1458 2422 129 16385 Rotary Encoder 12P
1459 2422 129 16385 Rotary Encoder 12P
1461 4822 276 13775 Tact Switch
1462 4822 276 13775 Tact Switch
1464 4822 276 13775 Tact Switch
1465 4822 276 13775 Tact Switch
1466 4822 276 13775 Tact Switch
1467 4822 276 13775 Tact Switch
1470 4822 265 11535 Flex Connector 8P
1471 4822 265 11545 Flex Connector 19P
1472 4822 265 11183 Flex Connector 4P
1473 4822 267 10958 Flex Connector 5P
1474 4822 267 51453 Flex Connector 12P
1475 4822 265 11183 Flex Connector 4P
1476 4822 265 11535 Flex Connector 8P
1478 4822 265 11207 Flex Connector 6P
1702 4822 267 10731 Flex Connector 6P
1703 4822 265 11529 Headphone Socket
1801 2422 026 05059 Microphone Socket
1803 4822 276 13775 Tact Switch
1901 4822 267 10733 Flex Connector 4P
1903 2422 025 16525 Flex Connector 16P
1904 2422 025 16526 Flex Connector 22P
1905 2422 025 14518 Flex Connector 9P
1908 2422 025 14518 Flex Connector 9P
1931 4822 265 11515 Flex Connector 8P
CAPACITORS
2401 5322 122 32531 100pF 5% 50V
2421 5322 122 32531 100pF 5% 50V
2425 4822 122 33177 10nF 20% 50V
2426 4822 122 33177 10nF 20% 50V
2441 4822 124 80483 47µF 20% 6,3V
2442 4822 126 14585 100nF 10% 50V
2443 4822 126 14585 100nF 10% 50V
2444 4822 124 80483 47µF 20% 6,3V
2445 4822 124 80483 47µF 20% 6,3V
2446 4822 124 80195 470µF 20% 10V
2447 5322 122 32658 22pF 5% 50V
2448 4822 126 13486 15pF 2% 63V
2449 5322 122 32658 22pF 5% 50V
2450 5322 122 32658 22pF 5% 50V
2451 5322 122 32658 22pF 5% 50V
2455 4822 122 33177 10nF 20% 50V
2456 4822 126 14585 100nF 10% 50V
2457 4822 122 33177 10nF 20% 50V
2458 4822 126 14585 100nF 10% 50V
2461 4822 126 13751 47nF 10% 63V
2462 4822 122 33127 2,2nF 10% 63V
2463 4822 122 33177 10nF 20% 50V
2464 4822 122 33177 10nF 20% 50V
2466 4822 126 13692 47pF 1% 63V
2467 4822 126 13692 47pF 1% 63V
2468 4822 126 13692 47pF 1% 63V
2469 4822 126 13692 47pF 1% 63V
2470 5322 122 32531 100pF 5% 50V
2471 4822 126 13695 82pF 1% 63V
2472 4822 126 13692 47pF 1% 63V
2473 4822 122 33173 560pF 10% 50V
2474 4822 126 13692 47pF 1% 63V
2475 4822 122 33173 560pF 10% 50V
2476 4822 124 22652 2,2µF 20% 50V
2477 4822 126 14585 100nF 10% 50V
2480 4822 126 14585 100nF 10% 50V
2482 5322 122 32531 100pF 5% 50V
2483 5322 122 32531 100pF 5% 50V
2488 4822 122 33177 10nF 20% 50V
2489 4822 122 33177 10nF 20% 50V
2490 4822 126 14585 100nF 10% 50V
2491 4822 126 14585 100nF 10% 50V
2501 4822 126 14043 1µF +80/-20% 16V
2502 4822 126 14585 100nF 10% 50V
2503 4822 126 13751 47nF 10% 63V
2504 5322 122 31866 6,8nF 10% 63V
2505 4822 122 33806 820pF 10% 63V
2506 4822 126 14076 220nF +80/-20% 25V
2507 4822 126 14076 220nF +80/-20% 25V
2508 4822 126 14076 220nF +80/-20% 25V
2511 4822 124 12032 4,7µF 20% 50V
2512 4822 126 14043 1µF +80/-20% 16V
2513 4822 124 12032 4,7µF 20% 50V
2514 5322 122 32531 100pF 5% 50V
2516 5322 122 32531 100pF 5% 50V
2518 5322 122 32531 100pF 5% 50V
2520 5322 122 32531 100pF 5% 50V
2522 5322 122 32531 100pF 5% 50V
2524 5322 122 32531 100pF 5% 50V
2531 5322 122 32448 10pF 5% 63V
2532 5322 122 32448 10pF 5% 63V
2533 4822 126 13838 100nF +80/-20% 50V
2534 4822 124 40433 47µF 20% 25V
2591 5322 122 32531 100pF 5% 50V
2702 5322 122 32654 22nF 10% 63V
2703 4822 126 14585 100nF 10% 50V
2704 4822 126 14585 100nF 10% 50V
2705 5322 122 32654 22nF 10% 63V
2802 4822 124 40433 47µF 20% 25V
2803 5322 126 10223 4,7nF 10% 63V
2804 4822 126 14076 220nF +80/-20% 25V
2805 5322 122 31647 1nF 10% 63V
2806 4822 126 13482 470nF +80/-20% 16V
2812 4822 126 13482 470nF +80/-20% 16V
2813 5322 122 31647 1nF 10% 63V
2814 4822 124 21732 10µF 20% 25V
2815 4822 124 80231 47µF 20% 16V
2921 5322 122 32654 22nF 10% 63V
2922 4822 126 14585 100nF 10% 50V
2923 4822 124 11912 220µF 20% 6,3V
2924 5322 122 32654 22nF 10% 63V
2925 4822 126 14585 100nF 10% 50V
2926 5322 122 32654 22nF 10% 63V
2927 4822 124 41584 100µF 20% 10V
2931 4822 124 40207 100µF 20% 25V
2932 4822 126 13482 470nF +80/-20% 16V
2933 4822 122 33891 3,3nF 10% 63V
2934 5322 126 10223 4,7nF 10% 63V
2935 4822 126 13695 82pF 1% 63V
2936 5322 122 32654 22nF 10% 63V
2937 5322 122 32654 22nF 10% 63V
2938 5322 122 32654 22nF 10% 63V
2939 4822 124 40769 4,7µF 20% 100V
2940 4822 124 40769 4,7µF 20% 100V
2941 5322 122 32531 100pF 5% 50V
2946 4822 124 40207 100µF 20% 25V
RESISTORS
3401 4822 117 10833 10k 1% 0,1W
3402 4822 051 20472 4k7 5% 0,1W
3403 4822 117 12955 2k7 1% 0,1W
3404 4822 051 20182 1k8 5% 0,1W
3405 4822 051 20122 1k2 5% 0,1W
3406 4822 117 11448 180R 1% 0,1W
3407 4822 117 11448 180R 1% 0,1W
3408 4822 117 11448 180R 1% 0,1W
3411 4822 117 11503 220R 1% 0,1W
3412 4822 117 11503 220R 1% 0,1W
3413 4822 117 11503 220R 1% 0,1W
3421 4822 117 11503 220R 1% 0,1W
3422 4822 117 11503 220R 1% 0,1W
3423 4822 117 11504 270R 1% 0,1W
3424 4822 051 20391 390R 5% 0,1W
3425 4822 051 20561 560R 5% 0,1W
3426 4822 117 11454 820R 1% 0,1W
3427 4822 051 20122 1k2 5% 0,1W
3428 4822 051 20182 1k8 5% 0,1W
3429 4822 117 12955 2k7 1% 0,1W
3430 4822 051 20472 4k7 5% 0,1W
3431 4822 117 10833 10k 1% 0,1W
3441 4822 051 10102 1k 2% 0,25W
3442 4822 051 10102 1k 2% 0,25W
3443 4822 051 10102 1k 2% 0,25W
3444 4822 051 10102 1k 2% 0,25W
3445 4822 051 10102 1k 2% 0,25W
3446 4822 051 10102 1k 2% 0,25W
3447 4822 051 10102 1k 2% 0,25W
3448 4822 051 10102 1k 2% 0,25W
3449 4822 051 10102 1k 2% 0,25W
3450 4822 051 10102 1k 2% 0,25W
3451 4822 051 10102 1k 2% 0,25W
3452 4822 051 10102 1k 2% 0,25W
3453 4822 051 10102 1k 2% 0,25W
3454 4822 051 10102 1k 2% 0,25W
3455 4822 051 10102 1k 2% 0,25W
3456 4822 051 10102 1k 2% 0,25W
3457 4822 051 10102 1k 2% 0,25W
3458 4822 051 10102 1k 2% 0,25W
3459 4822 051 10102 1k 2% 0,25W
3460 4822 051 10102 1k 2% 0,25W
3461 4822 051 10102 1k 2% 0,25W
3462 4822 051 10102 1k 2% 0,25W
3463 4822 051 10102 1k 2% 0,25W
ELECTRICAL PARTS LIST - FRONT BOARD
MISCELLANEOUS
ELECTRICAL PARTS LIST - FRONT BOARD
PCS 103 832
