MISCELLANEOUS
1901 4822 265 31015
!
Mains Socket
1901# 2422 030 00328
!
Mains Socket
1902* 4822 272 10269
!
Voltage Selector
1903* 4822 071 52001
!
Fuse T200mA 250V IEC
1905^ 4822 071 55002
!
Fuse T5A 250V IEC
1905# 4822 252 51123
!
Fuse T6,3A 250V UL
1906* 4822 071 55002
!
Fuse T5A 250V IEC
1907* 4822 071 55002
!
Fuse T5A 250V IEC
1909* 4822 267 10728
!
Primary Connector 4P
1910 4822 265 20723
!
Primary Connector 2P
1920 4822 071 55002
!
Fuse T5A 250V IEC
1923 4822 071 55002
!
Fuse T5A 250V IEC
1924 4822 071 52502
!
Fuse T2,5A 250V IEC
1925 4822 071 52502
!
Fuse T2,5A 250V IEC
CAPACITORS
2902 4822 121 43526 47nF 5% 250V
2903 4822 121 43526 47nF 5% 250V
2904* 4822 124 40255 100µF 20% 63V
2905* 4822 124 40207 100µF 20% 25V
RESISTORS
3901# 4822 053 21106
!
10M 5% 0,5W
3902 4822 050 11002 1k 1% 0,4W
3903 4822 050 11002 1k 1% 0,4W
3904* 4822 116 52283 4k7 5% 0,5W
3904** 4822 116 52244 15k 5% 0,5W
3905* 4822 116 52256 2k2 5% 0,5W
3906* 4822 050 21003 10k 1% 0,6W
3908^ 4822 053 10471 470R 5% 1W
3908# 4822 053 10121 120R 5% 1W
3920* 4822 052 10108
!
1R 5% 0,33W
COILS & FILTERS
5901^ 4822 157 11832
!
400µH 3A
5902* 4822 157 11628
!
Mains Choke
5903* 4822 146 11144
!
Standby Transformer
5903^ 4822 146 11143
!
Standby Transformer
5903# 4822 146 11142
!
Standby Transformer
5905 4822 280 10382
!
Relay 1P
DIODES
6900** 4822 130 31878 1N4003G
6901 4822 130 31878 1N4003G
6902 4822 130 31878 1N4003G
6903 4822 130 31878 1N4003G
6904 4822 130 31878 1N4003G
6905 4822 130 30621 1N4148
6906 4822 130 30621 1N4148
6908* 4822 130 34382 BZX79-C8V2
6909* 4822 130 32245 BYV10-40
6910* 4822 130 31878 1N4003G
6911 4822 130 30621 1N4148
6912 4822 130 30621 1N4148
TRANSISTORS & INTEGRSTED CIRCUITS
7901* 4822 130 41246 BC327-25
7902* 4822 130 40959 BC547B
* For /21/21M only
** Not for /21/21M
^ For /22/30 only
# For /37 only
Note : Only the parts mentioned in this list are normal
service spare parts.
MISCELLANEOUS
1205 4822 071 52002
!
Fuse T2A 250V IEC
1321 4822 267 31176 L/R Loudspeaker Terminal
CAPACITORS
2251 5322 121 42578 100nF 5% 250V
2252 5322 121 42578 100nF 5% 250V
2253 5322 121 42578 100nF 5% 250V
2254 5322 121 42578 100nF 5% 250V
2257 4822 124 80415 4700µF 20% 50V
2258 4822 124 80415 4700µF 20% 50V
2259 4822 124 40255 100µF 20% 63V
2260 4822 124 21913 1µF 20% 63V
2262 4822 124 81151 22µF 50V
2263 4822 124 80563 4700µF 20% 35V
2264 5322 121 42578 100nF 5% 250V
2265 4822 124 40255 100µF 20% 63V
2266 4822 122 10577 3,3nF 10% 16V
2267 4822 124 40433 47µF 20% 25V
2268 4822 124 40769 4,7µF 20% 100V
2269 4822 124 21913 1µF 20% 63V
2270 4822 124 41584 100µF 20% 10V
2271 2020 012 93745 10000µF 20% 16V
2273 4822 126 12882 100nF +80/-20% 50V
2274 4822 124 40248 10µF 20% 63V
2275 4822 126 12882 100nF +80/-20% 50V
2276 4822 124 11947 10µF 20% 16V
2277 4822 124 21913 1µF 20% 63V
2278 4822 124 21913 1µF 20% 63V
2279 4822 124 40248 10µF 20% 63V
2281 4822 124 40207 100µF 20% 25V
2282 4822 124 41584 100µF 20% 10V
2283 4822 121 51387 10nF 20% 16V
2284 4822 122 30043 10nF 80% 63V
2286 2020 012 93594 47µF 20% 100V
2287 2020 012 93741 100µF 20% 100V
2288 4822 124 11767 470µF 20% 25V
2320 5322 122 32261 4,7nF 10% 100V
2321 4822 124 22652 2,2µF 20% 50V
2322 4822 124 22652 2,2µF 20% 50V
2323 5322 122 32331 1nF 10% 100V
2324 5322 122 32331 1nF 10% 100V
2326 5322 122 32818 2,2nF 10% 100V
2329 4822 124 41751 47µF 20% 50V
2330 4822 124 41751 47µF 20% 50V
2331 4822 122 10465 4,7pF 10% 50V
2332 4822 122 10465 4,7pF 10% 50V
2337 5322 121 42386 100nF 5% 63V
2338 5322 121 42386 100nF 5% 63V
2339 5322 122 32261 4,7nF 10% 100V
2340 5322 122 32261 4,7nF 10% 100V
2341 4822 124 40248 10µF 20% 63V
2342 4822 124 40248 10µF 20% 63V
2344 4822 126 11585 22nF +80/-20% 25V
2345 4822 126 11585 22nF +80/-20% 25V
2346 4822 126 11585 22nF +80/-20% 25V
2347 4822 124 40248 10µF 20% 63V
2348 4822 124 81144 1000µF 16V
2349 5322 121 42386 100nF 5% 63V
2350 5322 121 42386 100nF 5% 63V
2351 5322 122 32818 2,2nF 10% 100V
RESISTORS
3245 4822 116 52238 12k 5% 0,5W
3246 4822 116 83884 47k 5% 0,5W
3247 4822 116 83872 220R 5% 0,5W
3248 4822 116 52269 3k3 5% 0,5W
3249 4822 052 10479
!
47R 5% 0,33W
3250 4822 052 10479
!
47R 5% 0,33W
3251 4822 116 52269 3k3 5% 0,5W
3252 4822 052 10479
!
47R 5% 0,33W
3253 4822 052 10479
!
47R 5% 0,33W
3254 4822 116 52257 22k 5% 0,5W
3255 4822 117 11342 0R33 5% 2W
3256 4822 116 52256 2k2 5% 0,5W
3258 4822 116 83883 470R 5% 0,5W
3260 4822 116 52256 2k2 5% 0,5W
3261 4822 116 52206 120R 5% 0,5W
3262 4822 050 21003 10k 1% 0,6W
3263 4822 116 52206 120R 5% 0,5W
3264 4822 050 11002 1k 1% 0,4W
3265 4822 050 23303 33k 1% 0,6W
3266 4822 116 52238 12k 5% 0,5W
3269 4822 050 11002 1k 1% 0,4W
3273 4822 052 10109
!
10R 5% 0,33W
3274 4822 116 52239 120k 5% 0,5W
3275 4822 050 21003 10k 1% 0,6W
3276 4822 117 11342 0R33 5% 2W
3277 4822 116 80176 1R 5% 0,5W
3278 4822 116 52228 680R 5% 0,5W
3279 4822 116 52228 680R 5% 0,5W
3280 4822 116 52228 680R 5% 0,5W
3282 4822 116 83961 6k8 5%
3284 4822 116 52249 1k8 5% 0,5W
3285 4822 050 11002 1k 1% 0,4W
3286 4822 050 11002 1k 1% 0,4W
3287 4822 116 52289 5k6 5% 0,5W
3288 4822 050 21003 10k 1% 0,6W
3289 4822 116 52256 2k2 5% 0,5W
3290 4822 117 11744 0R22 5% 1W
3291 4822 116 52291 56k 5% 0,5W
3292 4822 116 83884 47k 5% 0,5W
3293 4822 116 52238 12k 5% 0,5W
3294 4822 116 83884 47k 5% 0,5W
3295 4822 050 21003 10k 1% 0,6W
ELECTRICAL PARTS LIST - MAINS BOARD ELECTRICAL PARTS LIST - SUPPLY & LEFT/RIGHT AMPLIFIER BOARD
11-11
11-11
PCS 103 868
