8-7
ELECTRICAL PARTS LIST - AV BOARD
MISCELLANEOUS
8-7
ELECTRICAL PARTS LIST - AV BOARD
1505 4822 267 31449 Cinch Socket - Aux-in/Line-out/
Surround Out
1507 4822 267 31729 Cinch Socket - Audio Digital Out
1509 4822 267 31996 Cinch Socket - Video Out (CVBS)
1510 4822 265 11553 Flex Connector 19P
1511 4822 267 10732 Flex Connector 12P
1512 4822 265 11553 Flex Connector 19P
1514 2422 025 14518 Flex Connector 9P
1517 2422 025 14518 Flex Connector 9P
1518 4822 267 31729 Cinch Socket - Sub-Woofer Out
1523 4822 267 10757 Flex Connector 23P
1528 4822 267 10731 Flex Connector 6P
1529 4822 265 11515 Flex Connector 8P
1901 4822 267 10994 S-Video Out Socket
1902 2422 025 12352 Scart Connector
CAPACITORS
2501 4822 124 40769 4,7µF 20% 100V
2502 4822 124 40769 4,7µF 20% 100V
2503 5322 122 32531 100pF 5% 50V
2504 5322 122 32531 100pF 5% 50V
2505 4822 126 14585 100nF 10% 50V
2506 4822 126 14585 100nF 10% 50V
2507 4822 124 40769 4,7µF 20% 100V
2508 4822 124 40769 4,7µF 20% 100V
2509 4822 124 41407 0,47µF 20% 63V
2510 4822 124 41407 0,47µF 20% 63V
2511 5322 122 31866 6,8nF 10% 63V
2512 5322 122 31866 6,8nF 10% 63V
2513 5322 122 32654 22nF 10% 63V
2514 5322 122 32654 22nF 10% 63V
2515 4822 126 13838 100nF +80/-20% 50V
2516 4822 126 13838 100nF +80/-20% 50V
2519 5322 122 32654 22nF 10% 63V
2520 5322 122 32654 22nF 10% 63V
2521 5322 126 10223 4,7nF 10% 63V
2522 5322 126 10223 4,7nF 10% 63V
2523 4822 126 14043 1µF +80/-20% 16V
2524 4822 126 14043 1µF +80/-20% 16V
2525 5322 122 32268 470pF 10% 50V
2526 5322 122 32268 470pF 10% 50V
2527 4822 124 40433 47µF 20% 25V
2528 4822 124 40433 47µF 20% 25V
2529 5322 122 34099 470pF 10% 63V
2530 5322 122 34099 470pF 10% 63V
2531 4822 126 13692 47pF 1% 63V
2532 4822 126 13692 47pF 1% 63V
2533 4822 121 51252 470nF 5% 63V
2534 4822 121 51252 470nF 5% 63V
2535 4822 121 51252 470nF 5% 63V
2536 4822 121 51252 470nF 5% 63V
2537 4822 121 51252 470nF 5% 63V
2538 4822 121 51252 470nF 5% 63V
2539 5322 122 31647 1nF 10% 63V
2540 5322 122 31647 1nF 10% 63V
2541 4822 124 40769 4,7µF 20% 100V
2542 4822 124 40769 4,7µF 20% 100V
2543 4822 126 13692 47pF 1% 63V
2544 4822 126 13692 47pF 1% 63V
2545 5322 122 34099 470pF 10% 63V
2546 5322 122 34099 470pF 10% 63V
2547 4822 124 40769 4,7µF 20% 100V
2548 4822 124 40769 4,7µF 20% 100V
2549 4822 124 81151 22µF 50V
2550 4822 124 81151 22µF 50V
2551 5322 122 32531 100pF 5% 50V
2552 5322 122 32531 100pF 5% 50V
2553 5322 122 34099 470pF 10% 63V
2554 5322 122 34099 470pF 10% 63V
2555 4822 126 12105 33nF 5% 50V
2556 4822 126 12105 33nF 5% 50V
2557 4822 121 51252 470nF 5% 63V
2558 4822 121 51252 470nF 5% 63V
2559 4822 126 10847 1,8nF 10% 63V
2560 4822 126 10847 1,8nF 10% 63V
2561 5322 122 31647 1nF 10% 63V
2562 5322 122 31647 1nF 10% 63V
2563 4822 122 33891 3,3nF 10% 63V
2564 4822 122 33891 3,3nF 10% 63V
2565 5322 122 34099 470pF 10% 63V
2566 5322 122 34099 470pF 10% 63V
2567 4822 126 14585 100nF 10% 50V
2568 4822 126 14585 100nF 10% 50V
2569 4822 122 33575 220pF 5% 63V
2570 4822 122 33575 220pF 5% 63V
2571 5322 122 34099 470pF 10% 63V
2572 5322 122 34099 470pF 10% 63V
2573 4822 124 40433 47µF 20% 25V
2574 4822 124 40769 4,7µF 20% 100V
2575 4822 124 21913 1µF 20% 63V
2576 4822 126 14585 100nF 10% 50V
2577 5322 122 32654 22nF 10% 63V
2578 4822 124 40433 47µF 20% 25V
2579 4822 126 14585 100nF 10% 50V
2580 4822 124 40207 100µF 20% 25V
2581 4822 124 40207 100µF 20% 25V
2582 4822 122 33127 2,2nF 10% 63V
2583 4822 126 13838 100nF +80/-20% 50V
2584 4822 126 14585 100nF 10% 50V
2585 4822 124 40207 100µF 20% 25V
2586 4822 124 40207 100µF 20% 25V
2587 4822 124 80791 470µF 20% 16V
2588 4822 124 40248 10µF 20% 63V
2589 4822 124 40248 10µF 20% 63V
2590 5322 122 34098 10nF 10% 63V
2591 4822 124 40433 47µF 20% 25V
2592 5322 122 32654 22nF 10% 63V
2593 4822 124 80144 220µF 20% 25V
2594 4822 124 80144 220µF 20% 25V
2596 4822 126 14043 1µF +80/-20% 16V
2597 5322 122 32531 100pF 5% 50V
2598 5322 122 32531 100pF 5% 50V
2601 4822 124 40769 4,7µF 20% 100V
2602 4822 124 40769 4,7µF 20% 100V
2603 4822 122 32535 680pF 10% 63V
2604 4822 122 32535 680pF 10% 63V
2605 5322 122 32659 33pF 5% 50V
2606 5322 122 32659 33pF 5% 50V
2607 5322 122 32531 100pF 5% 50V
2608 4822 124 21913 1µF 20% 63V
2609 4822 124 21913 1µF 20% 63V
2612 4822 122 33127 2,2nF 10% 63V
2613 4822 122 33127 2,2nF 10% 63V
2614 5322 122 32448 10pF 5% 63V
2615 5322 122 32448 10pF 5% 63V
2616 4822 126 14585 100nF 10% 50V
2617 2020 552 96305 4,7µF +80/-20% 10V
2618 4822 126 13838 100nF +80/-20% 50V
2619 4822 126 13838 100nF +80/-20% 50V
2625 4822 122 33575 220pF 5% 63V
2626 4822 122 33575 220pF 5% 63V
2678 4822 126 14585 100nF 10% 50V
2715 4822 124 40769 4,7µF 20% 100V
2716 4822 124 40769 4,7µF 20% 100V
2717 5322 122 34099 470pF 10% 63V
2718 5322 122 34099 470pF 10% 63V
2719 4822 126 13838 100nF +80/-20% 50V
2720 4822 126 13838 100nF +80/-20% 50V
2721 4822 126 13838 100nF +80/-20% 50V
2722 4822 124 40769 4,7µF 20% 100V
2723 4822 126 13838 100nF +80/-20% 50V
2724 5322 122 32658 22pF 5% 50V
2726 5322 122 34099 470pF 10% 63V
2728 4822 126 13692 47pF 1% 63V
2729 4822 126 14043 1µF +80/-20% 16V
2732 4822 124 22652 2,2µF 20% 50V
2733 4822 124 40248 10µF 20% 63V
2734 4822 124 40248 10µF 20% 63V
2735 4822 124 40769 4,7µF 20% 100V
2736 4822 124 40769 4,7µF 20% 100V
2737 5322 122 32658 22pF 5% 50V
2738 5322 122 32658 22pF 5% 50V
2739 4822 126 13486 15pF 2% 63V
2740 4822 126 13486 15pF 2% 63V
2741 4822 126 13692 47pF 1% 63V
2742 4822 126 13692 47pF 1% 63V
2743 4822 124 41751 47µF 20% 50V
2744 4822 124 41751 47µF 20% 50V
2745 4822 124 22652 2,2µF 20% 50V
2746 4822 124 22652 2,2µF 20% 50V
2747 4822 124 40248 10µF 20% 63V
2748 4822 124 40248 10µF 20% 63V
2749 4822 124 40769 4,7µF 20% 100V
2750 4822 126 13486 15pF 2% 63V
2751 5322 122 32658 22pF 5% 50V
2752 4822 124 41751 47µF 20% 50V
2753 4822 124 22652 2,2µF 20% 50V
2754 4822 126 13692 47pF 1% 63V
2799 4822 124 41751 47µF 20% 50V
2800 4822 126 13486 15pF 2% 63V
2801 4822 126 14585 100nF 10% 50V
2830 2020 552 96305 4,7µF +80/-20% 10V
2831 2020 552 96305 4,7µF +80/-20% 10V
2832 5322 122 32448 10pF 5% 63V
2833 5322 122 32448 10pF 5% 63V
2835 4822 126 13751 47nF 10% 63V
2836 4822 126 13751 47nF 10% 63V
2838 4822 126 13692 47pF 1% 63V
2866 5322 122 32448 10pF 5% 63V
2867 5322 122 32448 10pF 5% 63V
2870 4822 124 41584 100µF 20% 10V
2876 4822 126 14585 100nF 10% 50V
2876 4822 124 81151 22µF 50V /22
2877 4822 122 33575 220pF 5% 63V
2878 4822 126 13838 100nF +80/-20% 50V
2887 4822 122 33127 2,2nF 10% 63V
2888 4822 122 33127 2,2nF 10% 63V
2889 4822 126 14585 100nF 10% 50V
2890 4822 126 14585 100nF 10% 50V
2891 4822 126 13838 100nF +80/-20% 50V
2893 4822 126 13751 47nF 10% 63V
2894 4822 126 13751 47nF 10% 63V
2896 4822 124 40769 4,7µF 20% 100V
2897 4822 124 40769 4,7µF 20% 100V
2898 4822 126 13838 100nF +80/-20% 50V
2899 4822 126 13751 47nF 10% 63V
2901 4822 124 21913 1µF 20% 63V
2902 4822 124 21913 1µF 20% 63V
2903 4822 122 33575 220pF 5% 63V
2904 4822 122 33575 220pF 5% 63V
2905 4822 124 21913 1µF 20% 63V
2906 4822 124 21913 1µF 20% 63V
2907 4822 122 33575 220pF 5% 63V
2908 4822 122 33575 220pF 5% 63V
2921 4822 124 21913 1µF 20% 63V
2922 4822 124 21913 1µF 20% 63V
2923 4822 122 33575 220pF 5% 63V
2924 4822 122 33575 220pF 5% 63V
PCS 103 841
