RESISTORS
ELECTRICAL PARTS LIST - FRONT BOARD ELECTRICAL PARTS LIST - FRONT BOARD
6-10
6-10
3816 4822 117 10837 100k 1% 0,1W
3817 4822 117 11454 820R 1% 0,1W
3915 4822 117 10833 10k 1% 0,1W
3916 4822 051 20479 47R 5% 0,1W
3917 4822 051 20479 47R 5% 0,1W
3918 4822 051 20479 47R 5% 0,1W
3919 4822 117 10833 10k 1% 0,1W
3921 4822 051 20479 47R 5% 0,1W
3924 4822 117 11449 2k2 5% 0,1W
3925 4822 051 20562 5k6 5% 0,1W
3931 4822 051 20471 470R 5% 0,1W
3932 4822 117 10833 10k 1% 0,1W
3933 4822 117 10833 10k 1% 0,1W
3934 4822 117 10833 10k 1% 0,1W
3935 4822 051 20223 22k 5% 0,1W
3936 4822 051 20479 47R 5% 0,1W
3937 4822 051 20479 47R 5% 0,1W
3938 4822 051 20479 47R 5% 0,1W
3947 4822 051 20471 470R 5% 0,1W
3948 4822 051 20829 82R 5% 0,1W
3949 4822 051 20829 82R 5% 0,1W
3950 4822 051 20829 82R 5% 0,1W
4401 4822 051 20008 0R Jumper 0805
4422 4822 051 20008 0R Jumper 0805
4441 4822 051 20008 0R Jumper 0805
4442 4822 051 20008 0R Jumper 0805
4443 4822 051 20008 0R Jumper 0805
4444 4822 051 20008 0R Jumper 0805
4445 4822 051 20008 0R Jumper 0805
4446 4822 051 20008 0R Jumper 0805
4447 4822 051 20008 0R Jumper 0805
4448 4822 051 20008 0R Jumper 0805
4449 4822 051 20008 0R Jumper 0805
4450 4822 051 20008 0R Jumper 0805
4451 4822 051 20008 0R Jumper 0805
4452 4822 051 20008 0R Jumper 0805
4453 4822 051 20008 0R Jumper 0805
4454 4822 051 20008 0R Jumper 0805
4455 4822 051 20008 0R Jumper 0805
4456 4822 051 20008 0R Jumper 0805
4457 4822 051 20008 0R Jumper 0805
4458 4822 051 20008 0R Jumper 0805
4459 4822 051 20008 0R Jumper 0805
4460 4822 051 20008 0R Jumper 0805
4461 4822 051 20008 0R Jumper 0805
4462 4822 051 20008 0R Jumper 0805
4463 4822 051 20008 0R Jumper 0805
4464 4822 051 20008 0R Jumper 0805
4465 4822 051 20008 0R Jumper 0805
4466 4822 051 20008 0R Jumper 0805
4467 4822 051 20008 0R Jumper 0805
4468 4822 051 20008 0R Jumper 0805
4469 4822 051 20008 0R Jumper 0805
4470 4822 051 20008 0R Jumper 0805
4471 4822 051 20008 0R Jumper 0805
4472 4822 051 20008 0R Jumper 0805
4473 4822 051 20008 0R Jumper 0805
4474 4822 051 20008 0R Jumper 0805
4475 4822 051 20008 0R Jumper 0805
4476 4822 051 20008 0R Jumper 0805
4477 4822 051 20008 0R Jumper 0805
4478 4822 051 20008 0R Jumper 0805
4479 4822 051 20008 0R Jumper 0805
4480 4822 051 20008 0R Jumper 0805
4481 4822 051 20008 0R Jumper 0805
4482 4822 051 20008 0R Jumper 0805
4483 4822 051 20008 0R Jumper 0805
4484 4822 051 20008 0R Jumper 0805
4485 4822 051 20008 0R Jumper 0805
4486 4822 051 20008 0R Jumper 0805
4490 4822 051 20008 0R Jumper 0805
4491 4822 051 20008 0R Jumper 0805
4492 4822 051 20008 0R Jumper 0805
4494 4822 051 20008 0R Jumper 0805
4607 4822 051 20008 0R Jumper 0805
4691 4822 051 20008 0R Jumper 0805
4692 4822 051 20008 0R Jumper 0805
4693 4822 051 20008 0R Jumper 0805
4694 4822 051 20008 0R Jumper 0805
4695 4822 051 20008 0R Jumper 0805
4701 4822 051 20008 0R Jumper 0805
4702 4822 051 20008 0R Jumper 0805
4703 4822 051 20008 0R Jumper 0805
4705 4822 051 20008 0R Jumper 0805
4801 4822 051 20008 0R Jumper 0805
4905 4822 051 20008 0R Jumper 0805
4906 4822 051 20008 0R Jumper 0805
4910 4822 051 20008 0R Jumper 0805
4911 4822 051 20008 0R Jumper 0805
4912 4822 051 20008 0R Jumper 0805
4931 4822 051 20008 0R Jumper 0805
4932 4822 051 20008 0R Jumper 0805
4933 4822 051 20008 0R Jumper 0805
4934 4822 051 20008 0R Jumper 0805
4935 4822 051 20008 0R Jumper 0805
4940 4822 051 20008 0R Jumper 0805
4941 4822 051 20008 0R Jumper 0805
4942 4822 051 20008 0R Jumper 0805
4943 4822 051 20008 0R Jumper 0805
4944 4822 051 20008 0R Jumper 0805
4945 4822 051 20008 0R Jumper 0805
4946 4822 051 20008 0R Jumper 0805
4947 4822 051 20008 0R Jumper 0805
4948 4822 051 20008 0R Jumper 0805
4949 4822 051 20008 0R Jumper 0805
4950 4822 051 20008 0R Jumper 0805
4951 4822 051 20008 0R Jumper 0805
4952 4822 051 20008 0R Jumper 0805
4953 4822 051 20008 0R Jumper 0805
4954 4822 051 20008 0R Jumper 0805
4955 4822 051 20008 0R Jumper 0805
4956 4822 051 20008 0R Jumper 0805
4957 4822 051 20008 0R Jumper 0805
COILS & FILTERS
5441 5322 242 73686 RES CER 12MHz
5442 2422 543 01069 RES XTL 32kHz768
5443 4822 157 62552 Coil 2,2µH 5%
5444 4822 157 62552 Coil 2,2µH 5%
5445 4822 157 62552 Coil 2,2µH 5%
5446 4822 157 62552 Coil 2,2µH 5%
5448 4822 157 62552 Coil 2,2µH 5%
5450 4822 157 62552 Coil 2,2µH 5%
5451 4822 242 72195 QUARZ 4,332MHz
5701 4822 157 62552 Coil 2,2µH 5%
5702 4822 157 10586 Coil 2,2µH 10%
5703 4822 157 62552 Coil 2,2µH 5%
5803 4822 157 62552 Coil 2,2µH 5%
5901 4822 157 10586 Coil 2,2µH 10%
5902 4822 157 10586 Coil 2,2µH 10%
DIODES
6401 4822 130 10791 LTL-1CHGE
6402 4822 130 10791 LTL-1CHGE
6403 4822 130 10791 LTL-1CHGE
6411 4822 130 10791 LTL-1CHGE
6412 4822 130 10791 LTL-1CHGE
6413 4822 130 10791 LTL-1CHGE
6415 9322 153 37676 LB3333RT-E7898
6441 9322 153 38676 LO3336UV-E7898
6442 9322 153 38676 LO3336UV-E7898
6443 9322 153 38676 LO3336UV-E7898
6444 9322 153 38676 LO3336UV-E7898
6445 9322 153 38676 LO3336UV-E7898
6451 4822 130 10791 LTL-1CHGE
6452 4822 130 10791 LTL-1CHGE
6453 4822 130 10791 LTL-1CHGE
6454 4822 130 10791 LTL-1CHGE
6455 4822 130 11589 LTL-1CHAE
6457 4822 130 82978 LTL-1CHPE
6458 9322 153 53676 LED VS LB5416
6459 9322 153 53676 LED VS LB5416
6460 4822 130 10165 GR1U28XP
6461 4822 130 31878 1N4003G
6463 4822 130 30621 1N4148
6471 4822 130 30621 1N4148
6472 4822 130 30621 1N4148
6473 4822 130 30621 1N4148
6474 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7441 3139 110 52370 TMP88CU77 - 'D51S52371'
7442 9322 145 26668 M24C02-WMN6
7443 4822 209 15449 74HC4094D
7444 4822 209 15449 74HC4094D
7445 4822 209 31981 SAA6579T/V1
7448 5322 130 60159 BC847B
7449 5322 130 60159 BC847B
7451 5322 130 60159 BC847B
7452 5322 130 60159 BC847B
7454 5322 130 60159 BC847B
7455 5322 130 60159 BC847B
7456 5322 130 60159 BC847B
7457 5322 130 60159 BC847B
7458 5322 130 60159 BC847B
7459 5322 130 60159 BC847B
7491 5322 209 11306 HEF4094BT
7492 5322 130 60159 BC847B
7493 5322 130 60159 BC847B
7803 5322 130 60159 BC847B
7804 4822 130 60373 BC857B
7806 5322 130 60159 BC847B
7903 4822 209 17423 UDA1328T/N1
7904 4822 130 42804 BC817-25
7931 4822 209 15973 TC9409BF
7932 9337 137 50653 74HCT157D
Note : Only the parts mentioned in this list are normal
service spare parts.
