ENGLISH
25
8
Place an empty container under the Cappuccinatore.
9
Press the " " button. The following icon is displayed. Press the "
" button to start dispensing steam.
10
When the rinsing water is  nished, stop dispensing by pressing the "
" button.
11
Remove the suction tube.
12
Remove the Cappuccinatore from the machine.
13
Remove all the parts shown in the  gure.
14
Wash the parts with lukewarm water or in the dishwasher.
15
The carafe coupling should not be covered with milk residues. Clean
with an abrasive damp cloth.
Clean thoroughly and reassemble the parts. Then, reassemble the Cappuccina-
tore on the machine.
