Option 2: Connect to S-Video socket
S-VIDEO IN
1 Connect an S-video cable (not supplied)
from the S-VIDEO OUT socket to the
S-Video input socket on the TV.
2 Connect an audio cable (red/white ends -
not supplied) from the AUDIO OUT-L/R
sockets to the matching audio input
sockets on the TV.
Tips
The S-video input socket on your TV may be labelled
as Y/C or S-VHS.
If your TV has a digital audio input socket, you can
enjoy multi-channel surround sound output. See
chapter “Connect other devices - Connect to AV
amplifi er/receiver”.
•
•
Option 3: Connect to VIDEO (CVBS)
socket
1 Connect a composite video cable (yellow
end - not supplied) from the CVBS OUT
socket to the video input socket on the
TV.
2 Connect an audio cable (red/white ends -
not supplied) from the AUDIO OUT-L/R
sockets to the matching audio input
sockets on the TV.
Tips
The video input socket on your TV may be labelled
as A/V IN, VIDEO IN, COMPOSITE or BASEBAND.
If your TV has a digital audio input socket, you can
enjoy multi-channel surround sound output. See
chapter “Connect other devices - Connect to AV
amplifi er/receiver”.
•
•
