Philips LC4.9E User Manual

Spare Parts List
EN 146 LC4.9E AB10.
10. Spare Parts List
Set Levels per CTN
42PF5520D/10
1004h 9322 224 88682 PDP PDP42V7A062
1004
h 9322 226 61682 PDP PDP42V7K062
1004
h 9322 233 81682 PDP PP42SD015F
1012 3104 328 39571 LED Panel [J]
1014 3104 328 39561 Side Control Assy [E]
1062 2422 549 00148 Socket 3p m
1062 2422 549 00151 Socket 3p m
1081 3139 188 85021 IBO Zapper [K]
1116 3104 328 40501 Side I/O Assy [G] 42"/50"
1174 3104 328 40312 Audio-Stdby Assy [C]
8101 3104 311 10751 Cable 3p/1K7/3p
8102 3104 311 03601 Cable 7p/400/7p
8102 3104 311 07241 Cable 7p/1000/7p
8103 3104 311 07391 Cable 10p/220/10p
8103 3104 311 08821 Cable 10p/400/10p
8120 3104 311 07421 Cable 6p/680/6p
8136 3104 311 10733 Cable 11p/1000/11p
8146 3104 311 06991 Cable 11p/280/11p
8146 3104 311 08621 Cable 11p/220/11p
8150 3104 311 08831 Cable 31p/300/31p
8150 3104 311 10492 Cable 31P/220/31P
8152 3104 311 09921 Cable 9p/680/9p
8301 3139 131 06371 Cable 04P/220/03P
8301 3139 131 06501 Cable 04p/340/03p
8321 3104 311 08731 Cable Posi/100/posi
8500 3139 131 05861 Cable 32P/280/32P
8600 3139 131 03761 Cable Phono/280/Phono
8735 3104 311 10601 Cable 2p3/1400/Posi
8736 3104 311 10591 Cable 2p3/1000/Posi
8900 3104 311 07911 Cable ring/180/ring
b
5213 2441 257 30020 Loudsp. 8Ω 10W
5214 2441 257 30020 Loudsp. 8Ω 10W
eSoftware (see Philips Service Website)
7050
7051
7055
42PF7520D/10
1004 9322 225 38682 PDP S42AX-YD01
1004
h 9322 227 20682 PDP FPF42C128128UE
1005 3104 328 42741 PDP FHP PSU [A]
1012 3104 328 39571 LED Panel [J]
1014 3104 328 39561 Side Control Assy [E]
1062 2422 549 00148 Socket 3p m
1062 2422 549 00151 Socket 3p m
1081 3139 188 85021 IBO Zapper [K]
1116 3104 328 40501 Side I/O Assy [G] 42"/50"
1174 3104 328 40312 Audio-Stdby Assy [C]
8101 3104 311 10751 Cable 3p/1K7/3p
8102 3104 311 03241 Cable 7p/280/7p Wh
8102 3104 311 07241 Cable 7p/1000/7p
8103 3104 311 06511 Cable 10p/280/10p
8103 3104 311 07971 Cable 10p/280/10p
8120
h 3104 311 06941 Cable 6p/680/6p
8120
h 3104 311 07421 Cable 6p/680/6p
8136 3104 311 10733 Cable 11p/1000/11p
8146 3104 311 08621 Cable 11p/220/11p
8150 3104 311 08082 Cable 31p/350/30p
8150 3104 311 08831 Cable 31p/300/31p
8152
h 3104 311 09921 Cable 9p/680/9p
8202
h 3104 311 08651 Cable 9p/340/9p
8301 3139 131 06371 Cable 04P/220/03P
8301 3139 131 06771 Cable PH 04P/820/03P
8321 3104 311 08731 Cable Posi/100/posi
8323 3104 311 10361 Cable 10p/280/10p
8500 3139 131 05861 Cable 32P/280/32P
8600 3139 131 03761 Cable Phono/280/Phono
8735 3104 311 10601 Cable 2p3/1400/Posi
8736 3104 311 10591 Cable 2p3/1000/Posi
8900
h 3104 311 07911 Cable ring/180/ring
8900
h 3104 311 08251 Wire ring/180/Posi
b
5213 2441 257 30020 Loudsp. 8Ω 10W
5214 2441 257 30020 Loudsp. 8Ω 10W
eSoftware (see Philips Service Website)
7050
7051
7052
7055
PDP FHP Supply Panel (.1) [A]
Various
0308 4822 265 20723 Connector 2p
0309 4822 267 10973 Connector 1p
0311 2422 025 10769 Connector 9p m
0323 2422 025 15085 Connector 10p m
0342 4822 267 10618 Connector 7p
0352 4822 267 10618 Connector 7p
1002 4822 267 10618 Connector 7p
1004 2422 086 00676 Fuse 2A T 250V
1082 2422 086 00677 Fuse 2.5A T 250V
1083 2422 086 00677 Fuse 2.5A T 250V
1084 2422 086 10849 Fuse 1A F 250V
1110 2422 086 00678 Fuse 5A T 250V
1200 2422 086 00676 Fuse 2A T 250V
1260 4822 252 51186 Fuse 2A
1400 4822 070 36302 Fuse 6.3A
1402 4822 252 60151 Surge protect
1450 4822 280 10382 SDT-SS-109DM
1460 4822 280 10382 SDT-SS-109DM
1M03 2422 025 10771 Connector 10p m
1M05 2422 025 16374 Connector 2p m
1M10 2422 025 09406 Connector 4p m
1M46 2422 025 10655 Connector 11p m
g
2000 2022 554 04155 470pF 20% 250V
2001 2222 338 22474 470nF 20% 275V
2005 2238 867 18101 100pF 1% 50V 0603
2006 2020 552 96618 1nF 10% 50V 0402
2007 2238 586 59812 100nF 20% 50V 0603
2008 5322 126 11583 10nF 10% 50V 0603
2009 3198 030 82280 2.2μF 20% 50V
2010 5322 126 11583 10nF 10% 50V 0603
2011 2222 375 24153 15nF 5% 1kV
2012 4822 126 11254 330pF 10% 2kV
2013 4822 126 11254 330pF 10% 2kV
2014 4822 126 13862 1.5nF 10% 2kV
2015 5322 126 11583 10nF 10% 50V 0603
2016 3198 030 82280 2.2μF 20% 50V
2017 2222 375 24153 15nF 5% 1kV
2018 2238 867 18101 100pF 1% 50V 0603
2019 2022 554 04155 470pF 20% 250V
2020 2020 024 90737 3300μF 20% 100V
2021 2020 024 90737 3300μF 20% 100V
2022 2020 021 91354 1000μF 20% 50V
2023 2222 580 15649 100nF 10% 50V 0805
2024 3198 035 03320 3.3nF 5% 50V 0402
2025 4822 124 12084 1μF 20% 50V
2026 2020 552 96623 2.2nF 10% 50V 0402
2027 2020 552 96631 15nF 10% 16V 0402
2028 2238 930 11541 220pF 5% 200V
2029 2238 930 11541 220pF 5% 200V
2030 2238 586 59812 100nF 20% 50V 0603
2031 2020 552 96628 10nF 10% 16V 0402
2032 2238 586 15641 22nF 10% 50V 0603
2033 2238 586 59812 100nF 20% 50V 0603
2034 4822 126 14525 47pF 5% 1kV
2035 2020 552 96618 1nF 10% 50V 0402
2036 2238 586 15641 22nF 10% 50V 0603
2037 4822 126 14525 47pF 5% 1kV
2038 2020 552 96618 1nF 10% 50V 0402
2039 2020 552 96623 2.2nF 10% 50V 0402
2040 3198 034 02790 47pF 1% 50V 0402
2041 2238 869 15101 100pF 5% 50V 0402
2042 3198 035 03310 330pF 5% 50V 0402
2043 4822 124 12084 1μF 20% 50V
2044 2238 930 11541 220pF 5% 200V
2045 2238 930 11541 220pF 5% 200V
2046 2252 568 08305 33pF 5% 500V
2047 2238 586 59812 100nF 20% 50V 0603
2048 2020 552 96683 220nF 10% 50V
2049 2238 867 18101 100pF 1% 50V 0603
2050 2238 586 15641 22nF 10% 50V 0603
2051 4822 122 33177 10nF 20% 50V
2052 4822 124 12056 1000μF 20% 35V
2053 2022 031 00308 22μF 20% 35V
2054 2020 552 00216 220pF 5% 50V 0402
2055 2020 552 96621 1.5nF 10% 50V 0402
2056 2020 552 00216 220pF 5% 50V 0402
2057 2020 552 96621 1.5nF 10% 50V 0402
2058 4822 124 41828 1μF 20% 250V
2059 2238 586 59812 100nF 20% 50V 0603
2060 2020 552 96683 220nF 10% 50V
2061 2238 586 59812 100nF 20% 50V 0603
2062 3198 030 82280 2.2μF 20% 50V
2070 2020 552 96618 1nF 10% 50V 0402
2071 2020 552 96618 1nF 10% 50V 0402
2090 2020 021 91729 4.7μF 20% 35V
2112 2020 552 96618 1nF 10% 50V 0402
2113 4822 124 12379 220μF 25V
2114 2020 552 96683 220nF 10% 50V
2117 2222 780 15656 330nF 10% 16V
2118 4822 126 13449 1nF 10% 2kV
2121 2020 024 90736 2200μF 20% 100V
2122 4822 121 51319 1μF 10% 63V
2123 3198 035 03320 3.3nF 5% 50V 0402
2126 2238 586 59812 100nF 20% 50V 0603
2133 4822 124 81151 22μF 50V
2203 2238 586 59812 100nF 20% 50V 0603
2205 2020 021 91729 4.7μF 20% 35V
2210 4822 124 80151 47μF 16V
2211 3198 035 04710 470pF 50V 0402
2212 2020 552 96326 220nF 10% 16V
2213 3198 035 03320 3.3nF 5% 50V 0402
2214 3198 035 03320 3.3nF 5% 50V 0402
2215 3198 035 04710 470pF 50V 0402
2217 2222 780 15656 330nF 10% 16V
2218 2222 375 90141 3.3nF 1.6kV 5%
2222 2238 869 15101 100pF 5% 50V 0402
2223 2238 869 15101 100pF 5% 50V 0402
2225 2020 021 91551 2200μ
F 20% 25V
2226 2238 586 59812 100nF 20% 50V 0603
2227 2238 869 15101 100pF 5% 50V 0402
2229 2020 021 00036 470μF 20% 16V
2230 2020 021 00036 470μF 20% 16V
2231 4822 124 80151 47μF 16V
2232 2238 869 15101 100pF 5% 50V 0402
2234 2022 552 05679 1μF 10% 16V 0805
2236 4822 124 23002 10μF 16V
2237 4822 124 23002 10μF 16V
2261 3198 026 51020 1000μF 50V
2263 2222 861 15272 2.7nF 5% 50V 0805
2264 4822 126 14583 470nF 10% 16V 0805
2265 3198 035 03310 330pF 5% 50V 0402
2266 2020 021 91729 4.7μF 20% 35V
2267 5322 122 32531 100pF 5% 50V
2268 2020 552 96683 220nF 10% 50V
2269 4822 123 14025 2200μF 20% 16V
2270 4822 124 40433 47μF 20% 25V
2273 2238 586 59812 100nF 20% 50V 0603
2274 2020 552 96628 10nF 10% 16V 0402
2290 5322 126 11583 10nF 10% 50V 0603
2291 3198 035 04710 470pF 50V 0402
2292 3198 026 51020 1000μF 50V
2293 3198 035 04710 470pF 50V 0402
2294 3198 026 51020 1000μF 50V
2295 3198 035 04710 470pF 50V 0402
2296 3198 035 04710 470pF 50V 0402
2304 2020 552 96618 1nF 10% 50V 0402
2305 2238 586 59812 100nF 20% 50V 0603
2306 2238 586 59812 100nF 20% 50V 0603
2322 2238 586 59812 100nF 20% 50V 0603
2324 2238 586 59812 100nF 20% 50V 0603
2343 3198 030 82280 2.2μF 20% 50V
2350 4822 124 12095 100μF 20% 16V
2352 2238 586 59812 100nF 20% 50V 0603
2364 2238 586 59812 100nF 20% 50V 0603
2376 2238 586 59812 100nF 20% 50V 0603
2377 2238 586 59812 100nF 20% 50V 0603
2381 2238 586 59812 100nF 20% 50V 0603
2385 2020 552 96628 10nF 10% 16V 0402
2386 2020 552 96628 10nF 10% 16V 0402
2387 4822 124 12095 100μF 20% 16V
2388 2020 552 96628 10nF 10% 16V 0402
2389 2020 552 96618 1nF 10% 50V 0402
2390 2020 552 96618 1nF 10% 50V 0402
2397 4822 124 12095 100μF 20% 16V
2398 4822 124 23002 10μF 16V
2400 2222 338 22474 470nF 20% 275V
2401 2222 338 22474 470nF 20% 275V
2404 4822 126 14525 47pF 5% 1kV
2405 2022 554 04155 470pF 20% 250V
2406 4822 126 14525 47pF 5% 1kV
2407 2022 554 04155 470pF 20% 250V
