5-5
ELECTRICAL PARTS LIST - KEY, VOLUME & LED BOARD
MISCELLANEOUS
DP251 9965 000 12538 VFD DISPLAY
SN201 9965 000 13071 IRT SENSOR IRM-2038F4 W/GND
TA202 4822 276 13648 TACT SWITCH
TA204 4822 276 13648 TACT SWITCH
TA205 4822 276 13648 TACT SWITCH
TA206 4822 276 13648 TACT SWITCH
TA207 4822 276 13648 TACT SWITCH
TA208 4822 276 13648 TACT SWITCH
TA209 4822 276 13648 TACT SWITCH
TA210 4822 276 13648 TACT SWITCH
VR201 9965 000 12539 ROTARY ENCODER EC16B24-204
XL981 9965 000 12540 CRYSTAL 4,00MHZ
CAPACITORS
C201 9965 000 12541 100UF 16V 20%
C202 9965 000 13179 0,022UF 50V
C203 9965 000 13070 100UF 50V 20%
C204 4822 126 14585 0,1UF 50V 5%
C205 9965 000 12544 0,1UF 50V 5%
C207 4822 126 13486 15PF 2% NP0 63V
C208 4822 126 13486 15PF 2% NP0 63V
C209 9965 000 12545 15PF 50V 5%
C212 9965 000 12541 100UF 16V 20%
C213 9965 000 13179 0,022UF 50V
C214 9965 000 12546 27PF 50V 5%
C215 9965 000 12546 27PF 50V 5%
C991 9965 000 12547 10UF 50V 20%
C992 5322 122 32658 22PF 5% 50V
C993 5322 122 32658 22PF 5% 50V
C994 4822 126 13692 47PF 1% NP0 63V
RESISTORS
R201 9965 000 12484 10K 1/10W 5%
R202 9965 000 12484 10K 1/10W 5%
R203 9965 000 12484 10K 1/10W 5%
R204 4822 050 21001 100R 1% 0,6W
R205 4822 050 21001 100R 1% 0,6W
R206 4822 050 21001 100R 1% 0,6W
R213 4822 051 20472 4K7 5% 0,1W
R214 9965 000 09727 56K 1/6W 5% CF
R215 4822 051 20223 22K 5% 0,1W
R216 4822 050 21001 100R 1% 0,6W
R218 9965 000 12548 220R 1/10W 5%
R223 4822 050 21003 10K 1% 0,6W
R224 4822 050 21003 10K 1% 0,6W
R225 9965 000 12549 220R 1/6W 5% CF
R227 9965 000 12549 220R 1/6W 5% CF
R228 4822 050 21003 10K 1% 0,6W
R229 9965 000 12484 10K 1/10W 5%
R230 9965 000 12484 10K 1/10W 5%
R231 4822 050 21003 10K 1% 0,6W
R232 4822 050 22203 22K 1% 0,6W
R233 4822 117 10837 100K 1% 0,1W
R234 4822 050 22203 22K 1% 0,6W
R235 4822 117 10837 100K 1% 0,1W
R236 4822 050 22203 22K 1% 0,6W
R237 4822 117 10837 100K 1% 0,1W
R238 9965 000 12515 2,2K 1/6W 5% CF
R239 9965 000 12515 2,2K 1/6W 5% CF
R240 9965 000 12515 2,2K 1/6W 5% CF
R241 4822 117 11449 2K2 5% 0,1W 0805
R242 9965 000 12515 2,2K 1/6W 5% CF
R987 4822 117 11373 100R 1% RC12H 0805
R988 9965 000 09725 4,7K 1/6W 5% CF
R991 4822 050 21003 10K 1% 0,6W
R992 9965 000 12484 10K 1/10W 5%
R993 9965 000 12484 10K 1/10W 5%
R994 9965 000 12484 10K 1/10W 5%
R995 9965 000 12484 10K 1/10W 5%
R996 4822 117 10837 100K 1% 0,1W
R998 9965 000 12484 10K 1/10W 5%
R9001 9965 000 12592 330R 1/6W 5%
R9002 4822 051 20102 1K 5% 0,1W
R9003 9965 000 12484 10K 1/10W 5% CF
R9004 9965 000 12482 47K 5% 0,1W
DIODES
D201 4822 130 30621 1N4148
D202 4822 130 30621 1N4148
D203 4822 130 30621 1N4148
D301 4822 130 30621 1N4148
D302 4822 130 30621 1N4148
D985 4822 130 30621 1N4148
LD201 9965 000 12537 LED 3 DIA RED ROUND
ZD201 9965 000 12554 ZENER 3,8-4,0V 0,5W
TRANSISTORS & INTEGRATED CIRCUITS
IC251 9965 000 12550 PT6311(PTC)
IC981 9965 000 12551 CF745
Q201 4822 130 63876 2SA733R
Q202 4822 130 63876 2SA733R
Q203 4822 130 63876 2SA733R
Q204 9965 000 09584 2SC945
Q983 4822 130 63876 2SA733R
Note: Only the parts mentioned in this list are normal service spare
parts.
5-6
MISCELLANEOUS
FB301 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB302 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
JK301 9965 000 12555 HEADPHONE JACK D3,5
CAPACITORS
C328 4822 124 40248 10UF 20% 63V
C331 9965 000 12558 220UF 16V 20%
C332 9965 000 12558 220UF 16V 20%
C333 9965 000 12559 100UF 16V 20%
C334 9965 000 12559 100UF 16V 20%
C339 4822 124 22652 2,2UF 50V +80-20%
C340 2038 554 00065 100NF +80-20% Y5V 50V
C341 2038 554 00065 100NF +80-20% Y5V 50V
C342 9965 000 12559 100UF 50V +80-20%
C343 2038 554 00065 100NF +80-20% Y5V 50V
C344 2038 554 00065 100NF +80-20% Y5V 50V
C345 2038 554 00065 100NF +80-20% Y5V 50V
C348 9965 000 12558 220UF 16V 20%
C350 2038 554 00065 100NF +80-20% Y5V 50V
RESISTORS
R349 9965 000 09724 3,9K 1/6W 5% CF
R350 9965 000 12560 56K 1/6W 5%
R353 9965 000 12482 47K 1/10W 5%
R354 9965 000 12482 47K 1/10W 5%
R355 4822 050 24703 47K 1/6W 5%
R356 9965 000 12562 9,1K 1/6W 5% CF
R357 4822 050 24703 47K 1/6W 5%
R358 9965 000 12562 9,1K 1/6W 5% CF
R359 9965 000 09724 3,9K 1/6W 5% CF
R360 4822 050 21001 100R 1% 0,6W
R361 4822 050 21001 100R 1% 0,6W
R362 4822 050 21502 1K5 1% 0,6W
R363 4822 050 24703 47K 1% 0,6W
R364 9965 000 09728 750R 5% 1/6W
R365 9965 000 09728 750R 5% 1/6W
R366 4822 050 21001 100R 1% 0,6W
R367 4822 050 21001 100R 1% 0,6W
R368 4822 050 22203 22K 5% 1/6W
DIODES
ZD302 4822 130 80272 MTZJ7,5C
TRANSISTORS & INTEGRATED CIRCUITS
IC304 9965 000 12563 TDA2822
Q306 4822 130 43818 2SC2878
Q307 4822 130 43818 2SC2878
Q308 4822 130 41651 2SC2001L
Note: Only the parts mentioned in this list are normal service spare
parts.
ELECTRICAL PARTS LIST - EARPHONE BOARD
