MISCELLANEOUS
CN001 9965 000 12565 CONNECTOR 2PIN, AM ANTENNA
EF001 9965 000 12566 TUNER FRONTEND FTE3-500H
EF001 9965 000 14228 TUN. FRONTEND KST-F404VA2FM
/22S
JK001 9965 000 12567 FM ANTENNA SOCKET
XL151 9965 000 12572 CRYSTAL 4,332MHZ
/22S
XL152 4822 242 82184 CRYSTAL 4,5MHZ
CAPACITORS
C001 2238 861 18339 33PF 1% 50V 0805
C003 9965 000 12573 0,022UF 50V 20%
C005 9965 000 12574 5PF 50V +/-0,5PF
C006 4822 126 14585 100NF 10% X7R 0805 50V
C007 2038 554 00065 100NF +80-20% Y5V 50V
C008 9965 000 12585 0,022UF 50V 10%
C009 9965 000 12573 0,022UF 50V 20%
C010 9965 000 12573 0,022UF 50V 20%
C011 4822 122 30103 22NF 80% 63V
C012 9965 000 12575 47UF 16V 20%
C013 9965 000 13454 8PF 50V 5%
C014 9965 000 12577 560PF 50V 5%
C015 4822 122 30103 22NF 80% 63V
C016 4822 126 14585 100NF 10% X7R 0805 50V
C101 4822 122 30103 22NF 80% 63V
C104 9965 000 13074 33UF 100V 20%
C105 9965 000 12573 0,022UF 50V 20%
C106 9965 000 13074 33UF 100V 20%
C107 9965 000 13075 22UF 16V 20%
C108 4822 126 14585 0,1UF 50V 10%
C109 9965 000 12580 10UF 16V 20%
C110 9965 000 12581 200PF 50V 5%
C111 9965 000 12582 30PF 50V 5%
C112 9965 000 12524 0,047UF 50V 20%
C113 9965 000 13076 47UF 16V 20%
C114 9965 000 12524 0,047UF 50V 20%
C115 9965 000 12524 0,047UF 50V 20%
C116 9965 000 12573 0,022UF 50V 20%
C117 9965 000 13076 47UF 16V 20%
C118 9965 000 12583 1UF 50V 20%
C119 9965 000 13077 1500PF 50V 10%
C120 5322 122 32658 22PF 5% 50V
C122 9965 000 12573 0,022UF 50V 20%
C123 9965 000 12583 1UF 50V 20%
C124 9965 000 12584 0,47UF 50V 20%
C125 9965 000 12580 10UF 16V 20%
C126 9965 000 12580 10UF 16V 20%
C127 9965 000 12583 1UF 50V 20%
C129 9965 000 12585 0,0022UF 50V 10%
C130 9965 000 12585 0,0022UF 50V 10%
C131 5322 126 10223 4,7NF 10% X7R 63V
C132 5322 126 10223 4,7NF 10% X7R 63V
C133 9965 000 12573 0,022UF 50V 20%
C134 9965 000 12573 0,022UF 50V 20%
ELECTRICAL PARTS LIST - TUNER BOARD ELECTRICAL PARTS LIST - TUNER BOARD
C135 4822 126 13344 1,5NF 5% 63V
C136 4822 126 13344 1,5NF 5% 63V
C137 4822 126 13188 15NF 5% X7R 63V
C138 4822 126 13188 15NF 5% X7R 63V
C139 9965 000 12586 4,7UF 16V 20%
C140 9965 000 12586 4,7UF 16V 20%
C141 9965 000 12585 0,0022UF 10% 50V
C142 9965 000 12585 0,0022UF 10% 50V
C143 9965 000 12575 47UF 16V 20%
C144 9965 000 12573 0,022UF 50V 20%
C145 9965 000 12573 0,022UF 50V 20%
C151 9965 000 14227 2,2UF 16V 20%
/22S
C152 5322 116 80853 560PF 5%NP0 63V /22S
C153 9965 000 13078 330PF 50V 5% /22S
C154 5322 122 32072 33PF 2%NP0 100V /22S
C155 5322 122 32072 33PF 2%NP0 100V /22S
C156 9965 000 12575 47UF 16V 20% /22S
C157 9965 000 12575 47UF 16V 20% /22S
C161 4822 126 14585 100NF 10% X7R 0805 50V
C163 9965 000 12575 47UF 16V 20%
C164 4822 122 30103 22NF 80% 63V
C165 9965 000 12588 1000PF 50V 5%
C166 9965 000 13079 3,3UF 16V 20%
C167 4822 122 30103 22NF 80% 63V
C169 9965 000 12573 0,022UF 50V 20%
C170 9965 000 12573 0,022UF 50V 20%
C171 9965 000 13076 47UF 16V 20%
C173 9965 000 12546 27PF 50V 5%
C174 9965 000 12546 27PF 50V 5%
TC001 4822 125 50692 TRIMMER 3-10PF
TC002 4822 125 50693 TRIMMER 4,2-20PF
RESISTORS
R001 9965 000 12591 6,8K 1/10W 5%
R002 4822 117 10837 100K 1% 0,1W
R003 4822 117 10837 100K 1% 0,1W
R004 4822 051 20102 1K 5% 0,1W
R005 9965 000 12592 330R 5% 1/6W
R006 4822 117 11373 100R 1% RC12H 0805
R007 4822 050 21004 100K 1% 0,6W
R008 4822 050 21001 100R 1% 0,6W
R009 4822 051 20102 1K 5% 0,1W
R101 4822 051 20274 270K 1% 0,1W
R102 4822 051 20479 47R 5% 0,1W
R103 4822 117 13577 330R 1% RC12H 0805 1,25W
R104 9965 000 12592 330R 1/6W 5% CF
R105 4822 050 21001 100R 1% 0,6W
R106 4822 051 20274 270K 1% 0,1W
R107 4822 051 20109 10R 5% 0,1W
R108 4822 050 21003 10K 1% 0,6W
R109 4822 117 10837 100K 1% 0,1W
R110 9965 000 12593 47R 1/6W 5% CF
R112 4822 051 20202 2K 5% 0,1W
R114 4822 117 13577 330R 1% RC12H 0805 1,25W
R115 4822 051 20332 3K3 5% 0,1W
R116 4822 051 20102 1K 5% 0,1W
R117 2120 108 92641 180K 1% 0,1W
R118 4822 051 20479 47R 5% 0,1W
R119 4822 051 20519 51R 5% 0,1W
R122 4822 051 20392 3K90 5% 0,1W
R123 9965 000 09725 4,7K 1/6W 5% CF
R124 4822 051 20302 3K 5% 0,1W
R125 4822 051 20102 1K 5% 0,1W
R126 9965 000 12482 47K 1/10W 5%
R129 4822 051 20472 4K7 5% 0,1W
R130 4822 051 20472 4K7 5% 0,1W
R131 9965 000 12591 6,8K 1/10W 5%
R132 9965 000 12591 6,8K 1/10W 5%
R133 4822 117 11449 2K2 5% 0,1W 0805
R134 4822 117 11449 2K2 5% 0,1W 0805
R135 9965 000 12482 47K 1/10W 5%
R136 9965 000 12482 47K 1/10W 5%
R137 4822 117 12955 2K7 5% 1/10W
R138 9965 000 12484 10K 1/10W 5%
R151 9965 000 12484 10K 1/10W 5% /22S
R154 9965 000 12484 10K 1/10W 5%
R155 9965 000 12519 1K 1/6W 5% CF
R156 4822 051 20332 3K3 5% 0,1W
R157 4822 051 20102 1K 5% 0,1W
R158 4822 051 20332 3K3 5% 0,1W
R159 4822 051 20472 4K7 5% 0,1W
R160 4822 051 20472 4K7 5% 0,1W
R161 4822 051 20472 4K7 5% 0,1W
R162 4822 051 20472 4K7 5% 0,1W
R163 4822 051 20472 4K7 5% 0,1W
R165 4822 051 20472 4K7 5% 0,1W
R167 4822 051 20223 22K 5% 0,1W
R168 4822 051 20223 22K 5% 0,1W
VR102 4822 051 20392 3K9 5% 0,1W
COILS & FILTERS
CF101 4822 242 82181 CER FILTER SFE10,7MA
CF102 9965 000 12564 CER FILTER 10,7MHZ SFE-10,7MS
CF103 9965 000 13181 CER FILTER 450KHZ SFU450B
L102 9965 000 12568 CHOKE 10UH
L103 9965 000 12569 CHOKE 39 MH
L104 9965 000 12568 CHOKE 10UH
L151 9965 000 12568 CHOKE 10UH
/22S
L152 9965 000 12568 CHOKE 10UH /22S
L153 9965 000 12568 CHOKE 10UH
L154 9965 000 12568 CHOKE 10UH
T001 9965 000 12597 OSC FM S-8N
T002 9965 000 12598 ANT OSC AM 4-6:10T 1-3:86T
T003 9965 000 13081 OSC AM 108UH
T101 9965 000 12599 FILTER 78KHZ
T102 9965 000 12570 IFT AM 455KHZ Q=130
T103 9965 000 12600 FILTER 16KHZ
T104 9965 000 12600 FILTER 16KHZ
T105 9965 000 12571 FM IFT 10,7MHZ Q=MIN, 60
DIODES
D001 4822 130 30621 1N4148
D002 4822 130 30621 1N4148
D003 4822 130 30621 1N4148
D004 4822 130 30621 1N4148
D101 4822 130 30621 1N4148
VD001 4822 130 81673 1SV149
VD002 4822 130 81673 1SV149
TRANSISTORS & INTEGRATED CIRCUITS
IC101 9965 000 12594 LA1837 SANYO
IC151 9965 000 12596 BU1923F /22S
IC152 9965 000 12595 LC72131M
Q001 4822 130 63173 2SK192AY
Q101 4822 130 41595 2SC1675L
Q102 4822 130 41595 2SC1675L
Q103 4822 130 63876 2SA733R
Q104 4822 130 41198 2SC945P
Q105 4822 130 41198 2SC945P
Note: Only the parts mentioned in this list are normal service spare
parts.
