Philips LX3000D User Manual

10-3
MISCELLANEOUS
JK181 9965 000 12607 DIN JACK, S-VIDEO OUT
JK182 9965 000 12608 RCA JACK YELLOW, VIDEO OUT
JK183 9965 000 12610 SLIDE SWITCH 1P2T LX3500D
JK184 9965 000 12609 RCA JACK R/G/B
CAPACITORS
C181 9965 000 12590 15PF 50V 5%
C182 9965 000 12590 15PF 50V 5%
C183 9965 000 12590 15PF 50V 5%
C184 9965 000 12590 15PF 50V 5%
C185 9965 000 12590 15PF 50V 5%
C187 9965 000 12590 15PF 50V 5%
ESC1 9965 000 13094 0,068UF 50V 10%
ELECTRICAL PARTS LIST - RGB BOARD (NOT FOR /22 VERSION)
ELECTRICAL PARTS LIST - SCART BOARD (FOR /22S VERSION ONLY)
DIODES
ZD181 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD182 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD183 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD184 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD185 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD186 4822 130 10209 ZENER 4,1-4,3V 0,5W
Note: Only the parts mentioned in this list are normal service spare
parts.
MISCELLANEOUS
JK101 9965 000 12611 SCART SOCKET
JK103 9965 000 12608 RCA JACK YELLOW, VIDEO OUT
JK104 9965 000 12607 DIN JACK, S-VIDEO OUT
CAPACITORS
C1058 9965 000 12590 15PF 50V 5%
C1059 9965 000 12590 15PF 50V 5%
C1060 9965 000 12590 15PF 50V 5%
C1061 9965 000 12590 15PF 50V 5%
C1062 9965 000 12590 15PF 50V 5%
C1063 9965 000 12590 15PF 50V 5%
C1064 9965 000 12590 15PF 50V 5%
C1065 9965 000 12590 15PF 50V 5%
C1066 9965 000 12590 15PF 50V 5%
C1067 9965 000 12590 15PF 50V 5%
C1098 4822 124 40248 10UF 20% 63V
C1099 4822 124 40248 10UF 20% 63V
ESC1 5322 122 32331 1NF 10% 100V
ESC2 5322 122 32331 1NF 10% 100V
RESISTORS
R1095 9965 000 12519 1K 1/6W 5% CF
R1096 9965 000 12519 1K 1/6W 5% CF
R1100 4822 050 22203 22K 1% 0,6W
R1101 9965 000 12519 1K 1/6W 5% CF
R1102 4822 050 21003 10K 1/6W 5%
R1103 4822 050 24703 47K 1/6W 5%
R1104 4822 050 24703 47K 1/6W 5%
R1106 4822 050 21003 10K 1/6W 5%
COILS & FILTERS
FB137 9965 000 12470 FE BEAD D3,5X6MM 100R
FB138 9965 000 12470 FE BEAD D3,5X6MM 100R
FB139 9965 000 12470 FE BEAD D3,5X6MM 100R
FB140 9965 000 12470 FE BEAD D3,5X6MM 100R
FB141 9965 000 12470 FE BEAD D3,5X6MM 100R
FB142 9965 000 12470 FE BEAD D3,5X6MM 100R
FB143 9965 000 12470 FE BEAD D3,5X6MM 100R
FB144 9965 000 12470 FE BEAD D3,5X6MM 100R
FB145 9965 000 12470 FE BEAD D3,5X6MM 100R
FB146 9965 000 12470 FE BEAD D3,5X6MM 100R
FB147 9965 000 12470 FE BEAD D3,5X6MM 100R
DIODES
D1100 4822 130 34167 BZX79-B6V2
ZD101 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD102 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD103 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD104 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD105 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD106 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD107 4822 130 10209 ZENER 4,1-4,3V 0,5W
ZD108 4822 130 10209 ZENER 4,1-4,3V 0,5W
TRANSISTORS
Q1100 4822 130 41198 2SC945P
Q1101 4822 130 10211 2SA952
Q1102 4822 130 41198 2SC945P
Q1103 4822 130 41651 2SC2001L
Note: Only the parts mentioned in this list are normal service spare
parts.
