8-8 8-8
ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - MAIN BOARD
MISCELLANEOUS
F901 9965 000 12501
!
FUSE 6,3A 250V SLOW
F902 9965 000 12501
!
FUSE 6,3A 250V SLOW
F903 9965 000 12500
!
FUSE 3,15A 250V SLOW
JK105 9965 000 12507 CINCH SOCKET 1P BLACK
JK106 9965 000 12506 SOCKET OPTICAL OUT
JK401 9965 000 12505 CINCH SOCKET 6P WHITE/RED
JK402 9965 000 12504 CINCH SOCKET 2P WHITE/RED
JK501 9965 000 12502
!
LOUDSPEAKER SOCKET 10P
RB102 9965 000 12503 SOCKET FFC 28PIN VERT,
CAPACITORS
C401 4822 126 13221 100PF 2% NP0 63V
C402 4822 126 13221 100PF 2% NP0 63V
C403 4822 126 13221 100PF 2% NP0 63V
C404 4822 126 13221 100PF 2% NP0 63V
C405 4822 126 13221 100PF 2% NP0 63V
C406 4822 126 13221 100PF 2% NP0 63V
C407 4822 126 14585 100NF 10% X7R 0805 50V
C408 4822 124 40433 47UF 20% 25V
C409 4822 126 14585 100NF 10% X7R 0805 50V
C410 4822 124 40433 47UF 20% 25V
C411 4822 126 14585 100NF 10% X7R 0805 50V
C412 9965 000 12522 4,7UF 50V 20%
C413 4822 126 13692 47PF 1% NP0 63V
C414 9965 000 12522 4,7UF 50V 20%
C415 4822 126 14585 100NF 10% X7R 0805 50V
C416 9965 000 12522 4,7UF 50V 20%
C417 4822 126 13692 47PF 1% NP0 63V
C418 9965 000 12522 4,7UF 50V 20%
C419 4822 126 14585 100NF 10% X7R 0805 50V
C420 9965 000 12522 4,7UF 50V 20%
C421 9965 000 12522 4,7UF 50V 20%
C422 4822 126 13692 47PF 1% NP0 63V
C423 9965 000 12522 4,7UF 50V 20%
C424 4822 126 14585 100NF 10% X7R 0805 50V
C425 4822 126 13692 47PF 1% NP0 63V
C426 9965 000 12522 4,7UF 50V 20%
C427 4822 126 14585 100NF 10% X7R 0805 50V
C428 9965 000 12523 0,22UF 50V 20%
C429 9965 000 12523 0,22UF 50V 20%
C430 9965 000 12523 0,22UF 50V 20%
C431 9965 000 12523 0,22UF 50V 20%
C432 4822 126 14585 100NF 10% X7R 0805 50V
C433 4822 126 14585 100NF 10% X7R 0805 50V
C434 9965 000 12524 0,047UF 50V 20%
C435 9965 000 12522 4,7UF 50V 20%
C436 4822 126 14585 100NF 10% X7R 0805 50V
C437 9965 000 12522 4,7UF 50V 20%
C438 9965 000 12522 4,7UF 50V 20%
C439 9965 000 12522 4,7UF 50V 20%
C440 9965 000 12522 4,7UF 50V 20%
C441 9965 000 12522 4,7UF 50V 20%
C442 9965 000 12522 4,7UF 50V 20%
C443 4822 124 40433 47UF 20% 25V
C444 4822 126 14585 100NF 10% X7R 0805 50V
C445 4822 124 40433 47UF 20% 25V
C446 4822 126 14585 100NF 10% X7R 0805 50V
C447 9965 000 12522 4,7UF 50V 20%
C448 4822 126 13692 47PF 1% NP0 63V
C449 9965 000 12522 4,7UF 50V 20%
C450 4822 124 40433 47UF 20% 25V
C451 4822 126 14585 100NF 10% X7R 0805 50V
C452 9965 000 12522 4,7UF 50V 20%
C453 4822 126 13692 47PF 1% NP0 63V
C454 9965 000 12522 4,7UF 50V 20%
C455 4822 124 40433 47UF 20% 25V
C456 4822 126 14585 100NF 10% X7R 0805 50V
C457 4822 126 14585 100NF 10% X7R 0805 50V
C458 4822 124 40433 47UF 20% 25V
C459 9965 000 12522 4,7UF 50V 20%
C460 9965 000 12522 4,7UF 50V 20%
C461 9965 000 13068 0,0015UF 100V 5%
C462 9965 000 12526 0,015UF 100V 5%
C463 9965 000 12527 0,47UF 100V 5%
C464 9965 000 13068 0,0015UF 100V 5%
C465 9965 000 12526 0,015UF 100V 5%
C466 9965 000 12527 0,47UF 100V 5%
C467 4822 126 14585 100NF 10% X7R 0805 50V
C468 4822 124 40433 47UF 20% 25V
C469 4822 124 40433 47UF 20% 25V
C470 4822 126 14585 100NF 10% X7R 0805 50V
C471 9965 000 12522 4,7UF 50V 20%
C472 5322 116 80853 560PF 5%NP0 63V
C473 9965 000 12522 4,7UF 50V 20%
C474 4822 126 14585 100NF 10% X7R 0805 50V
C475 4822 124 40433 47UF 20% 25V
C476 9965 000 12522 4,7UF 50V 20%
C477 5322 116 80853 560PF 5%NP0 63V
C478 9965 000 12522 4,7UF 50V 20%
C479 4822 126 14585 100NF 10% X7R 0805 50V
C480 4822 124 40433 47UF 20% 25V
C481 9965 000 12522 4,7UF 50V 20%
C482 5322 116 80853 560PF 5%NP0 63V
C483 9965 000 12522 4,7UF 50V 20%
C484 4822 126 14585 100NF 10% X7R 0805 50V
C485 9965 000 12522 4,7UF 50V 20%
C486 5322 116 80853 560PF 5%NP0 63V
C487 9965 000 12522 4,7UF 50V 20%
C488 4822 126 14585 100NF 10% X7R 0805 50V
C489 9965 000 12522 4,7UF 50V 20%
C490 5322 116 80853 560PF 5%NP0 63V
C491 9965 000 12522 4,7UF 50V 20%
C492 4822 126 14585 100NF 10% X7R 0805 50V
C493 9965 000 12522 4,7UF 50V 20%
C494 5322 116 80853 560PF 5%NP0 63V
C495 9965 000 12522 4,7UF 50V 20%
C496 4822 126 14585 100NF 10% X7R 0805 50V
C498 4822 124 40207 100UF 20% 25V
C499 4822 126 14585 100NF 10% X7R 0805 50V
C501 9965 000 12528 4700PF 50V 10%
C502 9965 000 12528 4700PF 50V 10%
C503 9965 000 12529 0,1UF 50V +80-20%
C504 9965 000 12529 0,1UF 50V +80-20%
C505 9965 000 12528 4700PF 50V 10%
C506 9965 000 12529 0,1UF 50V +80-20%
C507 9965 000 12529 0,1UF 50V +80-20%
C508 9965 000 12528 4700PF 50V 10%
C509 9965 000 12528 4700PF 50V 10%
C510 9965 000 12529 0,1UF 50V +80-20%
C511 9965 000 12529 0,1UF 50V +80-20%
C512 5322 121 42578 100NF 5% 250V
C513 5322 121 42578 100NF 5% 250V
C514 5322 121 42578 100NF 5% 250V
C515 5322 121 42578 100NF 5% 250V
C516 5322 121 42578 100NF 5% 250V
C517 9965 000 12529 0,1UF 50V +80-20%
C518 9965 000 12529 0,1UF 50V +80-20%
C519 9965 000 12529 0,1UF 50V +80-20%
C520 9965 000 12529 0,1UF 50V +80-20%
C521 9965 000 12529 0,1UF 50V +80-20%
C523 9965 000 12558 220UF 20% 16V
C524 9965 000 13453 0,22UF 50V 20%
C525 9965 000 13069 2200UF 25V 20%
C901 9965 000 08286 0,022UF 5% 100V MYLAR
C902 9965 000 08286 0,022UF 5% 100V MYLAR
C903 9965 000 08286 0,022UF 5% 100V MYLAR
C904 9965 000 08286 0,022UF 5% 100V MYLAR
C905 9965 000 12531
!
6800UF 25V 20%
C906 9965 000 12531
!
6800UF 25V 20%
C907 9965 000 12532 3,3UF 50V 20%
C910 9965 000 12529 0,1UF 50V +80-20%
C911 9965 000 12529 0,1UF 50V +80-20%
C912 9965 000 12533 220UF 25V 20%
C913 9965 000 12533 220UF 25V 20%
C914 9965 000 12529 0,1UF 50V +80-20%
C915 9965 000 12529 0,1UF 50V +80-20%
C921 9965 000 08286 0,022UF 5% 100V MYLAR
C922 9965 000 08286 0,022UF 5% 100V MYLAR
C923 9965 000 08286 0,022UF 5% 100V MYLAR
C924 9965 000 08286 0,022UF 5% 100V MYLAR
C925 9965 000 12529 0,1UF 50V +80-20%
C926 9965 000 12534
!
3300UF 25V 20%
C927 4822 124 40248 10UF 20% 63V
C928 9965 000 12533 220UF 25V 20%
C929 9965 000 12533 220UF 25V 20%
C930 9965 000 12529 0,1UF 50V +80-20%
C931 9965 000 12533
!
220UF 25V 20%
C932 9965 000 12533 220UF 25V 20%
C933 9965 000 12529 0,1UF 50V +80-20%
C937 9965 000 12529 0,1UF 50V +80-20%
C938 9965 000 12529 0,1UF 50V +80-20%
C940 9965 000 12533 220UF 25V 20%
C941 9965 000 12533 220UF 25V 20%
C942 9965 000 12533 220UF 25V 20%
C943 9965 000 12536 100UF 50V 20%
C4001 4822 126 13221 100PF 2% NP0 63V
C4004 9965 000 12522 4,7UF 50V 20%
C4005 4822 126 14585 100NF 10% X7R 0805 50V
C4007 5322 116 80853 560PF 5%NP0 63V
C4008 9965 000 12522 4,7UF 50V 20%
C4009 4822 126 14585 100NF 10% X7R 0805 50V
C4011 5322 122 32658 22PF 5% 50V
C4012 5322 122 32658 22PF 5% 50V
C4013 5322 122 32658 22PF 5% 50V
C4014 5322 122 32658 22PF 5% 50V
C4015 5322 122 32658 22PF 5% 50V
C4016 5322 122 32658 22PF 5% 50V
C4030 5322 122 32658 22PF 5% 50V
C4031 5322 122 32658 22PF 5% 50V
C4032 5322 122 32658 22PF 5% 50V
RESISTORS
R401 9965 000 12482 47K 1/10W 5%
R402 9965 000 12482 47K 1/10W 5%
R403 9965 000 12482 47K 1/10W 5%
R404 9965 000 12482 47K 1/10W 5%
R405 4822 051 20471 470R 5% 0,1W
R406 4822 051 20332 3K3 5% 0,1W
R407 4822 051 20471 470R 5% 0,1W
R408 4822 051 20332 3K3 5% 0,1W
R409 4822 051 20202 2K 5% 0,1W
R410 9965 000 12482 47K 1/10W 5%
R411 4822 051 20472 4K7 5% 1/10W
R412 4822 051 20472 4K7 5% 1/10W
R413 4822 051 20472 4K7 5% 1/10W
R414 4822 051 20472 4K7 5% 1/10W
R415 4822 051 20472 4K7 5% 1/10W
R416 4822 051 20472 4K7 5% 1/10W
R417 4822 117 10837 100K 1% 0,1W
R418 9965 000 12484 10K 5% 1/10W
R419 4822 117 10837 100K 1% 0,1W
R420 4822 051 20102 1K 5% 0,1W
R421 9965 000 12483 12K 5% 1/10W
R422 4822 051 20472 4K7 5% 0,1W
R423 4822 117 10837 100K 1% 0,1W
R424 9965 000 12484 10K 5% 1/10W
R425 4822 117 10837 100K 1% 0,1W
R426 4822 051 20102 1K 5% 0,1W
