ELECTRICAL PARTS LIST - MAIN BOARD
IC408 9965 000 12514 M62446FP
IC409 9965 000 12491 JRC4558D JRC
IC410 9965 000 12491 JRC4558D JRC
IC411 9965 000 12491 JRC4558D JRC
IC413 9965 000 12491 JRC4558D JRC
IC501 9965 000 12511
!
TDA7265 SGS THOMSON
IC502 9965 000 12511
!
TDA7265 SGS THOMSON
IC503 9965 000 12511
!
TDA7265 SGS THOMSON
IC901 5322 209 81856
!
LM7912CT
IC902 4822 209 70084
!
NJM7812A
IC903 5322 209 81331
!
MC7805ACT
IC904 9965 000 12512
!
BA05T ROHM
Q401 4822 130 43818 2SC2878
Q402 4822 130 43818 2SC2878
Q403 4822 130 43818 2SC2878
Q404 4822 130 41198 2SC945P
Q405 4822 130 43818 2SC2878
Q501 4822 130 41198 2SC945P
Q502 4822 130 41198 2SC945P
Q503 4822 130 41198 2SC945P
Q504 9965 000 12513 2SC719
Q505 4822 130 63876 2SA733R
Q901 4822 130 41651 2SC2001L
Q902 5322 130 44523
!
TIP42C
Q903 5322 130 44506
!
TIP41C
Q910 4822 130 41198 2SC945P
Q911 9965 000 12513 2SC719
Q912 4822 130 41651 2SC2001L
Q913 4822 130 41198 2SC945P
Q914 9965 000 12513 2SC719
Note: Only the parts mentioned in this list are normal service spare
parts.
