9-9
ELECTRICAL PARTS LIST - MPEG BOARD
RESISTORS
R24 4822 117 11927 75R 1% 0,1W
R25 4822 117 11927 75R 1% 0,1W
R26 4822 051 20102 1K 5% 0,1W
R27 4822 051 20472 4K7 5% 0,1W
R28 4822 051 20562 5K6 5% 0,1W 0805
R29 4822 051 20122 1K2 5% 0,1W
R30 4822 051 20102 1K 5% 0,1W
R31 4822 051 20472 4K7 5% 0,1W
R32 4822 051 20562 5K6 5% 0,1W 0805
R33 4822 051 20122 1K2 5% 0,1W
R34 4822 051 20102 1K 5% 0,1W
R35 4822 051 20472 4K7 5% 0,1W
R36 4822 051 20562 5K6 5% 0,1W 0805
R37 4822 051 20122 1K2 5% 0,1W
R38 4822 051 20102 1K 5% 0,1W
R39 4822 051 20472 4K7 5% 0,1W
R40 4822 051 20562 5K6 5% 0,1W 0805
R41 4822 051 20122 1K2 5% 0,1W
R42 4822 051 20102 1K 5% 0,1W
R43 4822 051 20472 4K7 5% 0,1W
R44 4822 051 20562 5K6 5% 0,1W 0805
R45 4822 051 20122 1K2 5% 0,1W
R46 4822 051 20102 1K 5% 0,1W
R47 4822 051 20472 4K7 5% 0,1W
R48 4822 051 20562 5K6 5% 0,1W 0805
R49 4822 051 20122 1K2 5% 0,1W
R51 4822 117 11373 100R 1% RC12H 0805
R52 4822 117 11373 100R 1% RC12H 0805
R53 4822 051 20622 6K2 5% 0,1W
R54 4822 051 20333 33K 5% 0,1W
R55 4822 051 20622 6K2 5% 0,1W
R56 4822 051 20333 33K 5% 0,1W
R57 4822 051 20622 6K2 5% 0,1W
R58 4822 051 20333 33K 5% 0,1W
R59 4822 051 20622 6K2 5% 0,1W
R60 4822 051 20333 33K 5% 0,1W
R61 4822 051 20622 6K2 5% 0,1W
R62 4822 051 20333 33K 5% 0,1W
R63 9965 000 12482 47K 1/10W 5%
R64 9965 000 12482 47K 1/10W 5%
R65 9965 000 12482 47K 1/10W 5%
R66 9965 000 12482 47K 1/10W 5%
R67 9965 000 12482 47K 1/10W 5%
R68 4822 116 83933 15K 1% 0,1W
R69 9965 000 12482 47K 1/10W 5%
R70 9965 000 12483 12K 1/10W 5%
R71 9965 000 12483 12K 1/10W 5%
R72 4822 051 20243 24K 5% 0,1W
R73 9965 000 12483 12K 1/10W 5%
R74 9965 000 12484 10K 1/10W 5%
R77 4822 117 11148 56K 1% 0,1W
R78 4822 117 11373 100R 1% RC12H 0805
R79 4822 117 11373 100R 1% RC12H 0805
R80 9965 000 12485 150R 1/6W 5% CF
R81 9965 000 12485 150R 1/6W 5% CF
R82 4822 051 20102 1K 5% 0,1W
R83 4822 051 20102 1K 5% 0,1W
R84 4822 051 20102 1K 5% 0,1W
R85 4822 051 20102 1K 5% 0,1W
R86 4822 051 20102 1K 5% 0,1W
R87 4822 051 20102 1K 5% 0,1W
R88 4822 051 20202 2K 5% 1/10W
R89 4822 051 20202 2K 5% 1/10W
R90 4822 051 20202 2K 5% 1/10W
R91 4822 051 20202 2K 5% 1/10W
R92 4822 051 20202 2K 5% 1/10W
R93 4822 051 20202 2K 5% 1/10W
R94 2322 734 63309 33R 1% RC12H 0805
R95 2322 734 63309 33R 1% RC12H 0805
R96 4822 051 20472 4K7 5% 0,1W
R97 4822 051 20102 1K 5% 0,1W
R98 4822 051 20202 2K 5% 0,1W
R99 9965 000 12484 10K 1/10W 5%
R1001 4822 051 20202 2K 5% 1/10W
R1002 4822 051 20202 2K 5% 1/10W
R1003 4822 051 20202 2K 5% 1/10W
R1004 4822 051 20202 2K 5% 1/10W
RA1 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA4 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA5 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA6 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA7 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA8 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA9 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA10 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA11 9965 000 12487 RES ARRAY 4X10R 1/10W 5%
RA12 9965 000 12487 RES ARRAY 4X10R 1/10W 5%
RA13 9965 000 12487 RES ARRAY 4X10R 1/10W 5%
RA14 9965 000 12488 RES ARRAY 4X4,7K 1/10W 5%
RA15 9965 000 12488 RES ARRAY 4X4,7K 1/10W 5%
RA16 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA17 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA18 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA19 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA20 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA21 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
RA22 9965 000 12486 RES ARRAY 4X33R 1/10W 5%
COILS & FILTERS
FB1 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB2 9965 000 12470 BEAD FERITE 100R/ AT 100MHZ
FB3 9965 000 12471 BEAD FERITE 600R AT 100MHZ
FB4 9965 000 12471 BEAD FERITE 600R AT 100MHZ
L1 4822 157 10568 CHOKE COIL 10UH
9-10
L4 4822 157 10568 CHOKE COIL 10UH
L5 4822 157 10568 CHOKE COIL 10UH
L7 9965 000 12472 CHOKE 2,4UH
L8 9965 000 12472 CHOKE 2,4UH
L9 9965 000 12472 CHOKE 2,4UH
L10 9965 000 12472 CHOKE 2,4UH
DIODES
D1 4822 130 30621 1N4148
ZD1 4822 130 80272 MTZJ7,5C
ZD2 4822 130 80272 MTZJ7,5C
ZD3 4822 130 80272 MTZJ7,5C
ZD4 4822 130 80272 MTZJ7,5C
ZD5 4822 130 80272 MTZJ7,5C
ZD6 4822 130 80272 MTZJ7,5C
ZD7 4822 130 80272 MTZJ7,5C
ZD8 4822 130 80272 MTZJ7,5C
ZD9 4822 130 80272 MTZJ7,5C
ZD10 4822 130 80272 MTZJ7,5C
TRANSISTORS & INTEGRATED CIRCUITS
IC1 9965 000 12489 EEPROM AM29F080B-90CE
IC2 9965 000 12494 74HC374
IC3 9965 000 12494 74HC374
IC4 9965 000 12494 74HC374
IC6 9965 000 12495 ES6018 MICRO CPU LX3000D
IC6 9965 000 12496 ES6028 MICRO CPU LX3500D
IC7 9965 000 12497 EEPROM AT24C02
IC8 9965 000 12498 74HCU04D PHILIPS
IC9 9965 000 12499 SYNCHRO, DRAM 4MX16 Y3V TW
IC10 9965 000 12490 CS4360
IC11 9965 000 12491 JRC4558D JRC
IC12 9965 000 12491 JRC4558D JRC
IC13 9965 000 12491 JRC4558D JRC
IC14 9965 000 12491 JRC4558D JRC
IC15 9965 000 12491 JRC4558D JRC
IC16 9965 000 12491 JRC4558D JRC
IC17 9965 000 12491 JRC4558D JRC
IC18 9965 000 12492 TC4053BFN CHIP
IC19 9965 000 12493 BA033T REGULATOR 3,3V 1A
Q1 4822 130 41651 2SC2001L
Q2 4822 130 41651 2SC2001L
Note: Only the parts mentioned in this list are normal service spare
parts.
ELECTRICAL PARTS LIST - MPEG BOARD
COILS & FILTERS
