Philips LX3000D User Manual

11-4
ELECTRICAL PARTS LIST - SURROUND BOARD
CAPACITORS
C601 5322 121 42489 33NF 5% 250V
C602 5322 121 42489 33NF 5% 250V
C607 9965 000 12612 0,001UF 50V +80-20%
C609 2038 554 00065 100NF +80-20% Y5V 50V
C610 2038 554 00065 100NF +80-20% Y5V 50V
C611 9965 000 12559 100UF 16V 20%
C612 9965 000 12559 100UF 16V 20%
C613 9965 000 12613 0,22UF 50V +80-20%
C615 9965 000 12614 47PF 50V 5%
C616 2038 554 00065 100NF +80-20% Y5V 50V
C617 9965 000 12559 100UF 16V 20%
C618 9965 000 12615 0,15UF 100V 5%
C619 9965 000 12614 47PF 50V 5%
C620 2038 554 00065 100NF +80-20% Y5V 50V
C621 9965 000 12559 100UF 16V 20%
C623 9965 000 12616 0,082UF 100V 5%
C624 9965 000 12616 0,082UF 100V 5%
C625 9965 000 12616 0,082UF 100V 5%
C626 9965 000 12616 0,082UF 100V 5%
C627 2038 554 00065 100NF +80-20% Y5V 50V
C628 2038 554 00065 100NF +80-20% Y5V 50V
C629 9965 000 12559 100UF 16V 20%
C630 9965 000 12559 100UF 16V 20%
C631 4822 124 40248 10UF 20% 63V
C632 4822 124 40248 10UF 20% 63V
C633 9965 000 12522 4,7UF 50V 20%
C634 9965 000 12522 4,7UF 50V 20%
C636 9965 000 12522 4,7UF 50V 20%
C637 9965 000 12522 4,7UF 50V 20%
C638 9965 000 12522 4,7UF 50V 20%
C639 4822 122 30103 22NF 80% 63V
C640 9965 000 12559 100UF 16V 20%
C641 4822 122 30103 22NF 80% 63V
C642 9965 000 12559 100UF 16V 20%
RESISTORS
R601 4822 051 20102 1K 1/10W 5%
R602 9965 000 09727 56K 1/6W 5% CF
R603 4822 050 21003 10K 1% 0,6W
R604 9965 000 09727 56K 1/6W 5% CF
R605 9965 000 12519 1K 1/6W 5% CF
R606 9965 000 12519 1K 1/6W 5% CF
R607 9965 000 12484 10K 5% 1/10W
R608 4822 117 12955 2K7 5% 1/10W
R609 4822 051 20102 1K 1/10W 5%
R610 4822 051 20102 1K 1/10W 5%
R612 9965 000 12484 10K 5% 1/10W
R613 4822 050 21503 15K 1% 0,6W
R615 9965 000 12549 220R 1/6W 5% CF
R616 9965 000 09727 56K 1/6W 5% CF
R617 4822 117 10837 100K 5% 1/10W
R618 9965 000 09727 56K 1/6W 5% CF
R620 4822 051 20333 33K 5% 1/10W
R621 9965 000 12884 12K 1/10W 5%
R622 9965 000 12549 220R 1/6W 5% CF
R623 4822 050 21503 15K 1% 0,6W
R624 4822 116 83933 15K 5% 1/10W
R625 4822 051 20333 33K 5% 1/10W
R626 4822 051 20333 33K 5% 1/10W
R627 9965 000 12519 1K 1/6W 5% CF
R628 4822 051 20102 1K 1/10W 5%
R629 9965 000 12549 220R 1/6W 5% CF
R630 9965 000 12549 220R 1/6W 5% CF
R631 4822 050 23303 33K 1% 0,6W
R632 4822 050 23303 33K 1% 0,6W
R633 4822 050 21003 10K 1% 0,6W
R634 9965 000 09727 56K 1/6W 5% CF
R635 9965 000 12519 1K 1/6W 5% CF
R636 9965 000 13180 47K 5% 1/10W
R637 9965 000 12549 220R 1/6W 5% CF
R638 9965 000 12549 220R 1/6W 5% CF
R640 4822 051 20102 1K 1/10W 5%
R641 4822 050 21003 10K 1% 0,6W
DIODES
ZD601 4822 130 80272 MTZJ7,5C
ZD602 4822 130 80272 MTZJ7,5C
TRANSISTORS & INTEGRATED CIRCUITS
IC601 4822 209 83631 NJM4558DD
IC602 4822 209 83631 NJM4558DD
IC603 4822 209 83631 NJM4558DD
IC604 9965 000 12492 TC4053BFN CHIP
Q601 4822 130 41198 2SC945P
Q602 4822 130 41198 2SC945P
Note: Only the parts mentioned in this list are normal service spare
parts.
