Philips LX3600D Service Manual

6-7
ELECTRICAL PARTS LIST - FRONT BOARDS
MISCELLANEOUS
1100 3141 010 50311 VFD Display HNV-07SS54T
1101 4822 265 11515 Flex Socket 8P Vert
1103 4822 276 13775 Tact Switch
1104 4822 276 13775 Tact Switch
1105 4822 276 13775 Tact Switch
1106 4822 276 13775 Tact Switch
1107 4822 276 13775 Tact Switch
1108 4822 276 13775 Tact Switch
1111 2422 129 16975 Rotary Encoder 12P
1201 4822 267 10733 Flex Socket 4P Vert
1202 4822 276 13775 Tact Switch
CAPACITORS
2100 4822 124 80483 47uF 20% 6,3V
2101 2238 586 59812 100nF +80/-20% 50V
2102 2238 586 59812 100nF +80/-20% 50V
2103 4822 126 14238 2,2nF 50V
2104 2238 586 59812 100nF +80/-20% 50V
2105 2020 552 96305 4,7uF +80/-20% 10V
2107 2238 586 59812 100nF +80/-20% 50V
2108 3198 028 44790 47uF 20% 35V
2109 4822 126 14549 33nF 16V
2110 4822 124 23052 100uF 20% 16V
2112 4822 124 40207 100uF 20% 25V
2113 4822 122 33761 22pF 5% 50V
2114 4822 124 40207 100uF 20% 25V
2116 2238 586 59812 100nF +80/-20% 50V
2117 2238 916 15641 22nF 10% 25V
2201 5322 126 11583 10nF 10% 50V
RESISTORS
3100 4822 052 10478 4R7 5% 0,33W
3101 4822 051 30102 1k 5% 0,062W
3102 4822 051 30103 10k 5% 0,062W
3103 4822 051 30101 100R 5% 0,062W
3104 4822 051 30101 100R 5% 0,062W
3105 4822 051 30101 100R 5% 0,062W
3106 4822 051 30101 100R 5% 0,062W
3107 4822 051 30103 10k 5% 0,062W
3108 4822 051 30103 10k 5% 0,062W
3109 4822 051 30103 10k 5% 0,062W
3110 4822 117 12925 47k 1% 0,063W
3111 4822 051 30472 4k7 5% 0,062W
3112 4822 051 30472 4k7 5% 0,062W
3113 4822 051 30472 4k7 5% 0,062W
3115 4822 051 30109 10R 5% 0,062W
3116 4822 051 30103 10k 5% 0,062W
3117 4822 051 30331 330R 5% 0,062W
3118 4822 051 30331 330R 5% 0,062W
3119 4822 051 30331 330R 5% 0,062W
3120 4822 051 30471 470R 5% 0,062W
3121 4822 051 30472 4k7 5% 0,062W
3122 4822 051 30472 4k7 5% 0,062W
3123 4822 051 30103 10k 5% 0,062W
3125 4822 051 30103 10k 5% 0,062W
3126 4822 051 30103 10k 5% 0,062W
3127 4822 051 30109 10R 5% 0,062W
3201 4822 051 30102 1k 5% 0,062W
3202 4822 051 30472 4k7 5% 0,062W
3203 4822 051 30103 10k 5% 0,062W
4101 4822 051 30008 0R Jumper 0603
4102 4822 051 30008 0R Jumper 0603
4201 4822 051 30008 0R Jumper 0603
4202 4822 051 30008 0R Jumper 0603
4203 4822 051 30008 0R Jumper 0603
4204 4822 051 30008 0R Jumper 0603
4205 4822 051 30008 0R Jumper 0603
4206 4822 051 30008 0R Jumper 0603
4207 4822 051 30008 0R Jumper 0603
4210 4822 051 30008 0R Jumper 0603
4213 4822 051 30008 0R Jumper 0603
DIODES
6105 4822 130 30621 1N4148
6106 4822 130 30621 1N4148
6108 4822 130 34173 BZX79-C5V6
6109 4822 130 34173 BZX79-C5V6
6110 4822 130 34173 BZX79-C5V6
6112 4822 130 34167 BZX79-B6V2
6201 9322 179 76676 LTL-816EELC
6202 4822 130 34173 BZX79-C5V6
TRANSISTORS & INTEGRATED CIRCUITS
7100 9322 186 03671 UPD16312GB-3B4
7101 9322 185 95667 IR RECEIVER TSOP4836
7102 4822 130 42804 BC817-25
7103 4822 130 60373 BC857B
7104 5322 130 60159 BC847B
7201 5322 130 60159 BC847B
Note: Only the parts mentioned in this list are normal service
spare parts.

Philips LX3600D Specifications

Picture/Display

aspect ratio	4:3, 16:9

Sound

D/A converter	24 bit, 96 kHz
frequency response	30-20000 Hz
output power (RMS)	6 x 50 W

Loudspeakers

satellite speaker freq range	120-20000 Hz
satellite speaker impedance	4 ohm
subwoofer freq range	30-120 Hz

Video Playback

number of discs	1
video disc playback system	NTSC, PAL
video enhancement	Progressive Scan

Audio Playback

compression format	Dolby Digital, DTS, MP3, PCM
MP3 bit rates	32-256 kbps and VBR
playback media	CD, CD-R, CD-RW, MP3-CD

Tuner/Reception/Transmission

auto digital tuning	Yes
number of preset channels	20
tuner bands	FM Stereo, MW

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 2 W
total sound power (RMS)	300 W

Dimensions

center speaker dimensions (W x H x D)	234 x 96 x 70 mm
set dimensions (W x H x D)	360 x 54 x 316 mm
subwoofer dimensions (W x H x D)	220 x 230 x 360 mm
