Philips LX3600D Service Manual

8-11
ELECTRICAL PARTS LIST - AMPLIFIER BOARD
MISCELLANEOUS
8 3104 211 29861 Spring 6-Channel
10 3104 211 29881 Earth Spring
1302 4822 267 10729 Flex Socket 10P Vert.
1303 4822 267 10729 Flex Socket 10P Vert.
1600 2422 540 98514 Ceram Resonator 602,7kHz
1601 2422 540 98568 Ceram Resonator 700kHz
CAPACITORS
2101 2222 580 15649 100nF 10% 50V
2102 2222 580 15649 100nF 10% 50V
2104 2222 601 55649 100nF 10% 100V
2105 2222 580 15649 100nF 10% 50V
2106 2020 021 91431 22uF 20% 100V
2107 2222 601 55649 100nF 10% 100V
2108 2222 580 15649 100nF 10% 50V
2111 4822 126 13188 15nF 5% 63V
2114 2238 600 15619 560pF 10% 100V
2115 2238 600 15619 560pF 10% 100V
2116 4822 121 51252 470nF 5% 63V
2117 2222 601 55649 100nF 10% 100V
2120 4822 126 13188 15nF 5% 63V
2122 2238 600 15619 560pF 10% 100V
2124 2222 601 55649 100nF 10% 100V
2125 4822 121 51252 470nF 5% 63V
2126 2238 600 15619 560pF 10% 100V
2127 2222 580 15649 100nF 10% 50V
2128 2222 580 15649 100nF 10% 50V
2129 2222 580 15649 100nF 10% 50V
2130 2222 580 15649 100nF 10% 50V
2131 4822 126 14241 330pF 50V
2134 2238 780 55654 220nF 10% 16V
2135 4822 126 13956 6,8pF 5% 63V
2136 4822 126 14241 330pF 50V
2201 2222 580 15649 100nF 10% 50V
2202 2222 580 15649 100nF 10% 50V
2204 2222 601 55649 100nF 10% 100V
2205 2222 580 15649 100nF 10% 50V
2206 2020 021 91431 22uF 20% 100V
2207 2222 601 55649 100nF 10% 100V
2208 2222 580 15649 100nF 10% 50V
2211 4822 126 13188 15nF 5% 63V
2214 2238 600 15619 560pF 10% 100V
2215 2238 600 15619 560pF 10% 100V
2216 4822 121 51252 470nF 5% 63V
2217 2222 601 55649 100nF 10% 100V
2220 4822 126 13188 15nF 5% 63V
2222 2238 600 15619 560pF 10% 100V
2224 2222 601 55649 100nF 10% 100V
2225 4822 121 51252 470nF 5% 63V
2226 2238 600 15619 560pF 10% 100V
2227 2222 580 15649 100nF 10% 50V
2228 2222 580 15649 100nF 10% 50V
2229 2222 580 15649 100nF 10% 50V
2230 2222 580 15649 100nF 10% 50V
2231 4822 126 14241 330pF 50V
2234 2238 780 55654 220nF 10% 16V
2235 4822 126 13956 6,8pF 5% 63V
2236 4822 126 14241 330pF 50V
2301 2222 580 15649 100nF 10% 50V
2302 2222 580 15649 100nF 10% 50V
2304 2222 601 55649 100nF 10% 100V
2305 2222 580 15649 100nF 10% 50V
2306 2020 021 91431 22uF 20% 100V
2307 2222 601 55649 100nF 10% 100V
2308 2222 580 15649 100nF 10% 50V
2311 4822 126 13188 15nF 5% 63V
2314 2238 600 15619 560pF 10% 100V
2315 2238 600 15619 560pF 10% 100V
2316 4822 121 51252 470nF 5% 63V
2317 2222 601 55649 100nF 10% 100V
2320 4822 126 13188 15nF 5% 63V
2322 2238 600 15619 560pF 10% 100V
2324 2222 601 55649 100nF 10% 100V
2325 4822 121 51252 470nF 5% 63V
2326 2238 600 15619 560pF 10% 100V
2327 2222 580 15649 100nF 10% 50V
2328 2222 580 15649 100nF 10% 50V
2329 2222 580 15649 100nF 10% 50V
2330 2222 580 15649 100nF 10% 50V
2331 4822 126 14241 330pF 50V
2334 2238 780 55654 220nF 10% 16V
2335 4822 126 13956 6,8pF 5% 63V
2336 4822 126 14241 330pF 50V
2400 2222 580 15649 100nF 10% 50V
2401 4822 124 80062 470uF 20% 35V
2402 4822 124 80062 470uF 20% 35V
2403 2222 580 15649 100nF 10% 50V
2404 4822 124 80062 470uF 20% 35V
2405 4822 124 80062 470uF 20% 35V
2406 4822 123 14026 470uF 20% 35V
2407 4822 123 14026 470uF 20% 35V
2408 5322 126 11578 1nF 10% 50V
2409 5322 126 11578 1nF 10% 50V
2410 5322 126 11578 1nF 10% 50V
2411 5322 126 11578 1nF 10% 50V
2412 5322 126 11578 1nF 10% 50V
2413 5322 126 11578 1nF 10% 50V
2414 5322 126 11578 1nF 10% 50V
2415 5322 126 11578 1nF 10% 50V
2416 5322 126 11578 1nF 10% 50V
2417 5322 126 11578 1nF 10% 50V
2418 5322 126 11578 1nF 10% 50V
2419 2238 586 59812 100nF +80/-20% 50V
2420 5322 126 11578 1nF 10% 50V

Philips LX3600D Specifications

Picture/Display

aspect ratio	4:3, 16:9

Sound

D/A converter	24 bit, 96 kHz
frequency response	30-20000 Hz
output power (RMS)	6 x 50 W

Loudspeakers

satellite speaker freq range	120-20000 Hz
satellite speaker impedance	4 ohm
subwoofer freq range	30-120 Hz

Video Playback

number of discs	1
video disc playback system	NTSC, PAL
video enhancement	Progressive Scan

Audio Playback

compression format	Dolby Digital, DTS, MP3, PCM
MP3 bit rates	32-256 kbps and VBR
playback media	CD, CD-R, CD-RW, MP3-CD

Tuner/Reception/Transmission

auto digital tuning	Yes
number of preset channels	20
tuner bands	FM Stereo, MW

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 2 W
total sound power (RMS)	300 W

Dimensions

center speaker dimensions (W x H x D)	234 x 96 x 70 mm
set dimensions (W x H x D)	360 x 54 x 316 mm
subwoofer dimensions (W x H x D)	220 x 230 x 360 mm
