Philips LX3600D Service Manual

ELECTRICAL PARTS LIST - MONO AV BOARD ELECTRICAL PARTS LIST - MONO AV BOARD
7-21 7-21
RESISTORS
3793 4822 051 30008 0R Jumper 0603
not for /22/25
3794 4822 051 30008 0R Jumper 0603 not for /22/25
3795 4822 051 30472 4k7 5% 0,062W /22/25
3796 4822 051 30472 4k7 5% 0,062W /22/25
3797 4822 051 30102 1k 5% 0,062W /22/25
3798 4822 051 30102 1k 5% 0,062W /22/25
3801 4822 051 30008 0R Jumper 0603
3802 4822 051 30008 0R Jumper 0603
3803 4822 051 30008 0R Jumper 0603
3808 4822 051 30339 33R 5% 0,062W
3813 4822 051 30102 1k 5% 0,062W /22/25
3814 4822 051 30103 10k 5% 0,062W /22/25
3817 4822 051 30103 10k 5% 0,062W /22/25
3818 4822 051 30103 10k 5% 0,062W /22/25
3819 4822 051 30471 470R 5% 0,062W /22/25
3820 4822 051 30471 470R 5% 0,062W /22/25
3825 4822 051 30221 220R 5% 0,062W /22/25
4107 4822 051 30008 0R Jumper 0603
4108 4822 051 30008 0R Jumper 0603
4110 4822 051 30008 0R Jumper 0603
4111 4822 051 30008 0R Jumper 0603
4112 4822 051 30008 0R Jumper 0603
4114 4822 051 30008 0R Jumper 0603
4117 4822 051 30008 0R Jumper 0603
4118 4822 051 30008 0R Jumper 0603
4201 4822 051 30008 0R Jumper 0603
4202 4822 051 30008 0R Jumper 0603
4220 4822 051 30008 0R Jumper 0603
4230 4822 051 30008 0R Jumper 0603
4310 4822 051 30008 0R Jumper 0603
4316 4822 051 30008 0R Jumper 0603
4551 4822 051 30339 33R 5% 0,062W
4552 4822 051 30339 33R 5% 0,062W
4555 4822 051 30339 33R 5% 0,062W
4556 4822 051 30339 33R 5% 0,062W
4557 4822 051 30339 33R 5% 0,062W
4558 4822 051 30339 33R 5% 0,062W
4562 4822 051 30339 33R 5% 0,062W
4563 4822 051 30339 33R 5% 0,062W
4564 4822 051 30339 33R 5% 0,062W
4565 4822 051 30339 33R 5% 0,062W
4566 4822 051 30339 33R 5% 0,062W
4567 4822 051 30339 33R 5% 0,062W
4568 4822 051 30339 33R 5% 0,062W
4569 4822 051 30339 33R 5% 0,062W
4570 4822 051 30339 33R 5% 0,062W
4572 4822 051 30339 33R 5% 0,062W
4573 4822 051 30339 33R 5% 0,062W /22/25
4574 4822 051 30339 33R 5% 0,062W /22/25
4576 4822 051 30008 0R Jumper 0603
4577 4822 051 30008 0R Jumper 0603
4578 4822 051 30339 33R 5% 0,062W
COILS & FILTERS
5100 3198 018 63390 Coil 33uH 5% 1008
5101 3198 018 63390 Coil 33uH 5% 1008
5110 4822 157 71206 Fixed Ind 600R 100MHz 0805
5111 4822 157 71206 Fixed Ind 600R 100MHz 0805
5210 2422 549 44607 Fixed Ind 600R 100MHz 0603
5211 4822 157 71206 Fixed Ind 600R 100MHz 0805
5213 2422 549 44607 Fixed Ind 600R 100MHz 0603
5214 2422 549 44607 Fixed Ind 600R 100MHz 0603
5215 2422 549 44607 Fixed Ind 600R 100MHz 0603
5216 2422 549 44607 Fixed Ind 600R 100MHz 0603
5217 3198 018 52280 Coil 2,2uH 10% 0603
5218 3198 018 52280 Coil 2,2uH 10% 0603
5410 4822 157 11414 Coil 1,8uH 5% 1210
5602 4822 157 11499 Fixed Ind 60R 100MHz 0603
5603 2422 549 45186 Fixed Ind 60R 100MHz 0805
5604 2422 549 45186 Fixed Ind 60R 100MHz 0805
5605 4822 051 30008 0R Jumper 0603
5606 4822 051 30008 0R Jumper 0603
5607 4822 157 11414 Coil 1,8uH 5% 1210
5608 2422 549 45186 Fixed Ind 60R 100MHz 0805
5609 4822 157 11414 Coil 1,8uH 5% 1210
5610 2422 549 45186 Fixed Ind 60R 100MHz 0805
5613 4822 157 11499 Fixed Ind 60R 100MHz 0603
5614 4822 157 11499 Fixed Ind 60R 100MHz 0603
5615 4822 157 11414 Coil 1,8uH 5% 1210
5616 4822 157 11414 Coil 1,8uH 5% 1210
5617 4822 157 11414 Coil 1,8uH 5% 1210
5620 4822 157 11414 Coil 1,8uH 5% 1210
5621 4822 157 11414 Coil 1,8uH 5% 1210
5623 4822 051 30471 470R 5% 0,062W
5624 4822 051 30471 470R 5% 0,062W
5625 4822 157 11499 Fixed Ind 60R 100MHz 0603
5626 4822 157 11499 Fixed Ind 60R 100MHz 0603
5627 4822 157 11499 Fixed Ind 60R 100MHz 0603
5701 2422 543 01393 X’tal Resonator 27MHz
DIODES
6250 4822 130 11551 BZX384-C10
6251 4822 130 11564 BZX384-C3V9
6291 4822 130 11522 PDZ15B
not for /22/25
6292 4822 130 11522 PDZ15B not for /22/25
6293 4822 130 11522 PDZ15B not for /22/25
6310 4822 130 11397 BAS316
6351 4822 130 11522 PDZ15B
not for /22/25
6410 4822 130 11522 BZX384-C15
6601 4822 130 11397 BAS316
/22/25
6602 4822 130 11397 BAS316 /22/25
6603 4822 130 11397 BAS316 /22/25
6604 9322 128 69685 S1D
6605 4822 130 11397 BAS316
6606 4822 130 11522 BZX384-C15 /22/25
6607 4822 130 11522 BZX384-C15 /22/25
6609 4822 130 11522 BZX384-C15 /22/25
6611 4822 130 11522 BZX384-C15 /22/25
6612 4822 130 11522 BZX384-C15
6613 4822 130 11522 BZX384-C15
/22/25
6620 4822 130 11397 BAS316 /22/25
6621 4822 130 11397 BAS316 /22/25
6622 4822 130 11397 BAS316 /22/25
6623 4822 130 11397 BAS316 /22/25
6627 4822 130 11522 BZX384-C15 /22/25
TRANSISTORS & INTEGRATED CIRCUITS
7101 9965 000 12490 CS4360KZ
7121 4822 209 30095 LM833D
7141 4822 209 30095 LM833D
7161 4822 209 30095 LM833D
7201 5322 130 44647 BC368
7202 5322 130 60159 BC847B
7203 5322 130 60159 BC847B
7204 4822 130 60373 BC857B
7205 5322 130 60159 BC847B
7220 4822 209 15765 74HC4052D
7221 9322 190 52668 CS5333-KZ
7310 5322 130 60159 BC847B
7311 5322 130 60159 BC847B
7312 5322 130 60159 BC847B
7313 5322 130 60159 BC847B
7314 5322 130 60159 BC847B
7315 5322 130 60159 BC847B
7316 5322 130 60159 BC847B
7317 5322 130 60159 BC847B
7318 4822 130 60373 BC857B
7319 4822 130 60373 BC857B
7322 4822 130 60373 BC857B
7500 4822 209 17398 LD1117DT33
7501 9322 165 15685 NCP303LSN30
7502 5322 130 60159 BC847B
7590 4822 130 60373 BC857B /22/25
7591 5322 130 60159 BC847B /22/25
7601 4822 209 17398 LD1117DT33
7602 3141 018 51841 MT1336E
7603 9322 187 63668 BA5954FP
7604 3141 018 51660 BA6208F
7605 5322 209 11517 PC74HCU04T
7606 3141 018 51831 MT1379BE
7609 9322 166 67668 MT48LC4M16A2TG-7E
7610 4822 209 17226 M24C08-WMN6
7611 9965 000 20304 M29W160ET70N6 with SW program
7613 4822 209 30095 LM833D
7614 4822 209 33411 MC78L05ACD
7615 9322 177 09685 AK4382AVT
7616 4822 130 60373 BC857B /22/25
7617 4822 130 60373 BC857B /22/25
7618 4822 130 60373 BC857B /22/25
7620 4822 130 11565 2SB1132
7621 4822 130 11565 2SB1132
7630 3141 018 51690 2SK3018
7631 3141 018 51690 2SK3018
7632 5322 130 60159 BC847B
7637 5322 130 60159 BC847B
/22/25
7638 5322 130 60159 BC847B /22/25
7653 5322 130 60159 BC847B /22/25
7654 5322 130 60159 BC847B /22/25
Note: Only the parts mentioned in this list are normal service
spare parts.

Philips LX3600D Specifications

Picture/Display

aspect ratio	4:3, 16:9

Sound

D/A converter	24 bit, 96 kHz
frequency response	30-20000 Hz
output power (RMS)	6 x 50 W

Loudspeakers

satellite speaker freq range	120-20000 Hz
satellite speaker impedance	4 ohm
subwoofer freq range	30-120 Hz

Video Playback

number of discs	1
video disc playback system	NTSC, PAL
video enhancement	Progressive Scan

Audio Playback

compression format	Dolby Digital, DTS, MP3, PCM
MP3 bit rates	32-256 kbps and VBR
playback media	CD, CD-R, CD-RW, MP3-CD

Tuner/Reception/Transmission

auto digital tuning	Yes
number of preset channels	20
tuner bands	FM Stereo, MW

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 2 W
total sound power (RMS)	300 W

Dimensions

center speaker dimensions (W x H x D)	234 x 96 x 70 mm
set dimensions (W x H x D)	360 x 54 x 316 mm
subwoofer dimensions (W x H x D)	220 x 230 x 360 mm
