Philips LX3600D Service Manual

8-13
ELECTRICAL PARTS LIST - AMPLIFIER BOARD
DIODES
6600 3198 020 55680 BZX384-C5V6
6713 4822 130 11397 BAS316
6714 4822 130 11397 BAS316
6715 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7100 9352 705 74518 TDA8920TH/N1
7200 9352 705 74518 TDA8920TH/N1
7300 9352 705 74518 TDA8920TH/N1
7600 5322 209 11517 PC74HCU04T
7602 5322 130 60159 BC847B
7607 5322 209 14477 HEF4013BT
7608 4822 130 60373 BC857B
7710 5322 130 60159 BC847B
7716 4822 130 60373 BC857B
Note: Only the parts mentioned in this list are normal service
spare parts.

Philips LX3600D Specifications

Picture/Display

aspect ratio	4:3, 16:9

Sound

D/A converter	24 bit, 96 kHz
frequency response	30-20000 Hz
output power (RMS)	6 x 50 W

Loudspeakers

satellite speaker freq range	120-20000 Hz
satellite speaker impedance	4 ohm
subwoofer freq range	30-120 Hz

Video Playback

number of discs	1
video disc playback system	NTSC, PAL
video enhancement	Progressive Scan

Audio Playback

compression format	Dolby Digital, DTS, MP3, PCM
MP3 bit rates	32-256 kbps and VBR
playback media	CD, CD-R, CD-RW, MP3-CD

Tuner/Reception/Transmission

auto digital tuning	Yes
number of preset channels	20
tuner bands	FM Stereo, MW

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 2 W
total sound power (RMS)	300 W

Dimensions

center speaker dimensions (W x H x D)	234 x 96 x 70 mm
set dimensions (W x H x D)	360 x 54 x 316 mm
subwoofer dimensions (W x H x D)	220 x 230 x 360 mm
