Philips LX3600D Service Manual

10-4
MAIN ENCASING & ACCESSORIES PARTS LIST
110 3139 257 51241 Cover Tray DVD
113 3139 114 79611 Lens Orn Cover Tray
121 3139 114 79591 Knob Volume
123 3139 114 79601 Cap Volume
254 4822 532 60948 Bush, Mains cord
345 3139 119 01421 LS Box Package (CS & Subwoofer)
351 2422 076 00546 FM Antenna Wire
352 2422 549 45386 AM Loop Antenna
353 3139 238 04751 Remote Control RC19245015/01H
363 2422 076 00468 Scart Cable 1,1M 21Pin
/22/25
364 3103 308 92610 Audio Cable 1,5M not for /22/25
365 4822 263 21206 Video Cable 1,7M Yel not for /22/25
370 3139 115 22851 Instruction For Use /17
370 3139 115 22611 Instruction For Use Book 1 /22
370 3139 115 22701 Instruction For Use /25
370 3139 115 22831 Instruction For Use /69
370 3139 115 22941 Instruction For Use /75
370 3139 115 22931 Instruction For Use /78
371 3139 115 22721 Instruction For Use Book 2 /22
8521 3139 110 34580 Flex Cable 4P 28cm AD
8531 3139 111 03671 Flex Cable 10P 14cm AD
8532 3139 111 03671 Flex Cable 10P 14cm AD
8540 3139 110 35390 Flex Cable 8P 48cm BD
8580 3139 110 35911 Flex Cable 11P 10cm BD
FRONT CABINET ASSEMBLY PARTS LIST
1 3139 257 51571 Cabinet Front
/17
1 3139 257 51221 Cabinet Front /22/25
1 3139 257 51411 Cabinet Front /69/75/78
3 3139 247 51831 Badge Philips Silver
9 3139 257 51231 Button Power/Standby
11 3139 114 79541 Lightguide Standby
13 3139 257 51271 Button Set Control
19 3139 257 51251 Window Display
21 3139 114 79571 Window Display Right
BOTTOM PLATE ASSEMBLY PARTS LIST
3 3139 243 10080 Cushion Foot
9 8204 055 76161 Spacer Locking KGLS-4S
356 2422 070 98235
!
Main Cord UL 6A 1,8M /17
356 2422 070 98231
!
Main Cord IEC 2A5 1,8M /22/69/78
356 2422 070 98236
!
Main Cord UK 5A 1,8M /25
SCREW LIST
13 M3 x 4
275 M3 x 6
276 D3 x 8
277 D3 x 8
278 M3 x 6
279 M3 x 6
280 M3 x 6
281 M3 x 4
282 D3 x 8
283 D3 x 8
284 D3 x 8
285 D3 x 8
286 D3 x 8
287 D3 x 8
288 M3 x 4
289 M3 x 4
293 D3 x 10
356 2422 070 98233
!
Main Cord Aust. 7A5 1,8M /75
1210 3141 018 03810 DVD Loader A97SL
1215 3122 429 00261 PSU Board 120V
/17
1215 3122 429 00191 PSU Board 220-240V /22/25/75
1215 3122 429 00241 PSU Board Voltage Selector /69/78
1216 2422 542 90137 Tuner Module Eur /22/25
1216 2422 542 90138 Tuner Module non-Eur /17/69/75/78
LOUDSPEAKER PACKAGE BREAKDOWN PARTS
9965 000 20170 Front Speaker Box Left
9965 000 20171 Front Speaker Box Right
9965 000 20172 Rear Speaker Box Left
9965 000 20173 Rear Speaker Box Right
9965 000 20174 Center Speaker Box
9965 000 20175 Subwoofer Box
9965 000 17047 Mounting Bracket + Screw Pack
Note: Only the parts mentioned in this list are normal service
spare parts.

Philips LX3600D Specifications

Picture/Display

aspect ratio	4:3, 16:9

Sound

D/A converter	24 bit, 96 kHz
frequency response	30-20000 Hz
output power (RMS)	6 x 50 W

Loudspeakers

satellite speaker freq range	120-20000 Hz
satellite speaker impedance	4 ohm
subwoofer freq range	30-120 Hz

Video Playback

number of discs	1
video disc playback system	NTSC, PAL
video enhancement	Progressive Scan

Audio Playback

compression format	Dolby Digital, DTS, MP3, PCM
MP3 bit rates	32-256 kbps and VBR
playback media	CD, CD-R, CD-RW, MP3-CD

Tuner/Reception/Transmission

auto digital tuning	Yes
number of preset channels	20
tuner bands	FM Stereo, MW

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 2 W
total sound power (RMS)	300 W

Dimensions

center speaker dimensions (W x H x D)	234 x 96 x 70 mm
set dimensions (W x H x D)	360 x 54 x 316 mm
subwoofer dimensions (W x H x D)	220 x 230 x 360 mm
