13-2 13-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT
SCREW LISTS - MAIN UNIT
185 M3 x 6
186 D3 x 10
187 M3 x 6
188 M3 x 6
228 M3 x 6
229 M3 x 6
230 D3 x 10
231 D3 x 10
232 D3 x 10
233 M3 x 6
101 3139 118 19351 Cabinet Front
MX5500D/21S
101 3139 118 19341 Cabinet Front MX5500D/37
101 3139 257 50801 Cabinet Front MX5600D/37
101 3139 257 51111 Cabinet Front MX5700D/22S/25S
101 3139 257 51361 Cabinet Front MX5700D/21R/21S
102 3139 118 18801 Cover Cabinet Side Left
103 3139 118 18811 Cover Cabinet Side Right
105 3139 118 19361 Cover Tray Disc1 MX5500D/MX5700D
105 3139 118 19961 Cover Tray Disc1 MX5600D
106 3139 118 19371 Cover Tray Disc2 MX5500D/MX5700D
106 3139 118 19771 Cover Tray Disc2 MX5600D
107 3139 118 19381 Cover Tray Disc3 MX5500D/MX5700D
107 3139 118 19981 Cover Tray Disc3 MX5600D
108 3139 118 19391 Cover Tray Disc4 MX5500D/MX5700D
108 3139 118 19991 Cover Tray Disc4 MX5600D
109 3139 118 19401 Cover Tray Disc5 MX5500D/MX5700D
109 3139 257 50001 Cover Tray Disc5 MX5600D.
110 3139 114 78491 Cover Tray 5DTC MX5600D
120 3139 118 19441 Button Set CD Open/Close Chrome
122 3139 113 27511 Cutsheet Shield CD Open/Close
123 3139 118 19411 Panel Left
MX5500D/MX5700D
123 3139 257 50011 Panel Left MX5600D
126 3139 118 19431 Panel Control MX5500D/MX5700D
126 3139 257 50031 Panel Control MX5600D
127 3139 118 18871 Button Set Power Eco
128 3139 114 77041 Lightguide Power Eco Stdby
133 3139 118 18941 Ring Ornamental
134 3139 118 18931 Cap Knob Rotary Chrome
135 3139 118 18921 Knob Source/Vol Rotary
136 3139 118 19461 Button Set Bass Chrome
137 3139 118 19471 Button Set Treble Chrome
138 3139 257 51531 Window Display
139 3139 118 19421 Panel Display MX5500D/MX5700D
139 3139 257 50021 Panel Display MX5600D
140 3139 118 19451 Button Set Ctrl Chrome
141 3139 118 19481 Ring Orn Display MX5500D/MX5700D
141 3139 257 50891 Ring Orn Display MX5600D
142 3139 114 77551 Lightguide Volume
143 3139 257 51541 Cover PCMCIA
144 3139 111 10011 Spring Cover PCMCIA
145 3139 257 50791 Knob Eject PCMCIA
148 3139 257 50141 Knob Karaoke
/21R/21S
256 3139 113 27220 Foot Rubber
259 3139 111 01470 Spring Grounding
296 3139 110 40691 Screw Cap Hd Soc Hex Mac M5x6
345 3139 119 00581 Satellite LS pack
MX5500D/21S
345 3139 119 00601 Satellite LS pack not for MX5500D/21S
346 3139 119 00591 Subwoofer Box MX5500D/21S
346 3139 119 00571 Subwoofer Box MX5500D/37
346 3139 119 00611 Stand Subwoofer Box MX5600D
346 3139 119 00651 Stand Subwoofer Box MX5700D
351 4822 303 50063 FM Antenna
352 4822 303 50082 AM Loop Antenna
353 3139 228 61701 Remote Control RC19241001/01
356 2422 070 98151
!
Mains Cord 2A5 1,5M /21R/21S/22S
356 9965 000 07586
!
Mains Cord 2A5 1,5M /25S
356 2422 070 98246
!
Mains Cord UL 7A 1,5M /37
357 3139 128 73010
!
Adapter Plug 6A 250V /21S
358 4822 263 21206 Cinch Cable 1,7M Yel not for /22S/25S
361 2422 076 00374 Cinch Cable 1,5M 3P not for /22S/25S
362 3103 308 92610 Audio Cable 1,5M not for /22S/25S
363 2422 076 00528 Scart Cable 1,5M 21P /22S/25S
370 3139 115 22261 Instr. For Use MX5500D/21S
370 3139 115 22061 Instr. For Use MX5500D/37
370 3139 115 22121 Instr. For Use MX5600D/37
370 3139 115 22281 Instr. For Use MX5700D/22S/25S
370 3139 115 22681 Instr. For Use MX5700D/21R/22S
371 3139 115 22551 Instr. For Use Book 2 MX5700D/22S
1100 3139 119 00831 LCD Module MX5500D-01
1106 3139 118 56571 PCMCIA Board
1110 2822 031 01494 Fan 12Vdc 0,8W 3100rpm B
5001 3139 118 32641
!
Mains Transfo 6x75W MX5500D/21S
5001 3139 118 32702
!
Mains Transfo 6x100W MX5600D/37
5001 3139 118 32631
!
Mains Transfo 6x100W MX5700D/22S/25S
5001 3139 118 32621
!
Mains Transfo 6x100W MX5700D/21R/21S
5101 3139 110 53431 VU Meter FG-PH16CATS00 Black
8000 3139 110 35031 Flex Cable 8P 14cm AD
8001 3139 111 02001 Flex Cable 13P 40cm BD
8002 3139 111 02461 Flex Cable 14P 40cm AD
8003 3139 111 02211 Flex Cable 16P 10cm AD
8005 3139 111 02051 Flex Cable 7P 34cm AD
8006 3139 110 34431 Flex Cable 8P 34cm AD
/21R/21S
8006 3139 110 34861 Flex Cable 4P 34cm AD not for/21R/21S
8008 3139 111 02021 Flex Cable 4P 22cm AD
8009 3139 111 02281 Flex Cable 40P 28cm AD
8010 3139 111 01971 Flex Cable 18P 18cm AD
/21R/21S
8010 3139 111 02601 Flex Cable 16P 18cm AD not for/21R/21S
8011 3139 111 02591 Flex Cable 10P 28cm AD
8012 3139 111 02581 Flex Cable 13P 18cm AD
8013 3139 111 02571 Flex Cable 10P 18cm BD for 75W
8014 3139 111 02571 Flex Cable 10P 18cm BD
8016 3139 110 36140 Flex Cable 4P 18cm AD
8018 3139 111 02231 Flex Cable 5P 12cm AD
8025 3139 111 02401 Flex Cable 10P 22cm BD
Note: Only the parts mentioned in this list are normal service
spare parts.
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT
Breakdown of Satellite LS Package (For MX5500D/21S only)
9965 000 18060 Front Speaker Box Left
9965 000 18061 Front Speaker Box Right
9965 000 18065 Center Speaker Box
9965 000 18062 Surr. Speaker Box Left
9965 000 18063 Surr. Speaker Box Right
9965 000 18064 Front/Surround Spk Front Grille Assy
9965 000 18066 Center Speaker Grille Assembly
9965 000 17046 Philips Logo
9965 000 18067 Base Plate Front/Surround Speaker
9965 000 18068 Mounting Bracket + Screw Pack
Breakdown of Satellite LS Package (Not for MX5500D/21S)
9965 000 18070 Front Speaker Box Left
9965 000 18071 Front Speaker Box Right
9965 000 18074 Center Speaker Box
9965 000 18072 Surr. Speaker Box Left
9965 000 18073 Surr. Speaker Box Right
9965 000 18064 Front/Surround Spk Front Grille Assy
9965 000 18066 Center Speaker Grille Assembly
9965 000 17046 Philips Logo
9965 000 18067 Base Plate Front/Surround Speaker
9965 000 18068 Mounting Bracket + Screw Pack
MECHANICAL PARTS LIST - LOUDSPEAKERS BREAKDOWN
Breakdown of Subwoofer Box (For MX5500D family)
9965 000 18059 Front Metal Grille Assembly
9965 000 17046 Philips Logo
Breakdown of Subwoofer Box (For MX56../MX57.. family)
Refer to Exploded view on page 13-3
9965 000 18406 2-Pins Terminal
9965 000 18407 Locking Top
9965 000 18413 2-Spring
9965 000 18405 4" Woofer Speaker 8R 100W
9965 000 18411 4-Pins Terminal (White & Purple)
9965 000 18412 4-Pins Terminal (Red & Purple)
Note: Only the parts mentioned in this list are normal service
spare parts.
234 D3 x 10
235 D3 x 10
236 D3 x 10
276 D3 x 10
277 D3 x 10
278 D3 x 10
279 D2 x 8
280 D2 x 8
281 D2 x 8
282 M3 x 6
283 M3 x 6
284 M3 x 6
285 D3 x 10
286 M3 x 6
287 M3 x 6
288 D3 x 10
290 D3 x 10
291 D3 x 10
292 D3 x 10
293 D3 x 10
295 M3 x 6
296 M5 x 6 Hex W/Head
297 M3 x 6
310 D3 x 10
311 D3 x 10
312 M3 x 6
