PM 2517 E
-
Instruments with serial number
Dl\4600 upto Dl\.4900.
version
/0'1.
Interconnect
points
2
and 3 of the
power plug.
Note:
Some instruments with
serial numbers DM60O
upto DMgOj
are already equipped with a voltage
regulator diode
as shown
in figurc 1. For
these instuments
proceed
as for instruments with serial
numbeß
greater
than DMg00.
-
Instruments with
serial numbers
greater
than DM900.
Interconnect
points
2 and 3 of the
power plug.
Short-circuit the voltage regulator
diode.
Note: The voltage regulator
diode is
used for decreasing
the external
g
V
to
7 V for
the instrument.
2.
ACCESSORTES
2.1.
Accessories
supplied
with
the Instrument
-
l/easuring
leads
with
test
pins
2
Fuses
315 mA
quick
I
V
power
supply
PM
9218
Directions
for
use
to
2.2.
OPTTONAL ACCESSOR
tES
2.2.1.
Temperature probe
PM
9248
(Fig.2)
The
resistance
thermometer Pl\4
9248 is
a contact
probe,
suitable for measurement
of surface temperatures
between
-60
oC
and
+200
oC.
Range
Resolution
Accuracy
(combined
with
Pt\l
2517)
Perm
issible
voltage
at
probe
tip
-60
oc
to
+2oo
oc
0.1
0c
-
60
oC
to
+100
oC
+
100
oC
to
+200
oC
60v
I
1
o/o
of reading
+
1% to
-3%
of
reading
!2
0C
!2
0C
2-2.2.
Data
hold
probe
pM
9263
(Fig.3)
The
PM
9263 is
a
DATA
HOLD
probe
which
can be
used in combination with multimeters
which
have a
data hold
facilities
on
the s'pole
DIN
probe
input.
A
switch
ring
on the
probe
is
pushed
forward
to
hold
the
data for
display.
Depending
on the
multimeter,
voltage, resistance
and current measurements
can
be made
in
combination
with
the
probe.
