Alignments
EN 38 Q548.1E LA6.
2009-Apr-03
Miscellaneous Region Europe/AP-PAL-MULTI/Australia Select Region/country.
Tuner type HD1816-MK1/TD1716-MK4/
TD1716-MK3/HD1816-MK2
Select type of Tuner used.
System RC support Off/On Select System RC support On/Off.
Embedded user manual Off/On Select Embedded user manual On/Off.
Start-up screen Off/On Select Start-up screen On/Off.
Wallpaper Off/On Select Wallpaper On/Off.
Hotel mode Off Hotel mode is Off.
Option number Group 1 e.g. “08192.02181.01387.45160” The first line (group 1) indicates hardware options 1
to 4.
Group 2 e.g. “10185.12448.00164.00000” The second line (group 2) indicates software options
5 to 8.
Store Store after changing.
Initialise NVM N.A
Store
Select Store in the SAM root menu after making any
changes.
Software maintenance Software events Display Display information is for development purposes.
Clear
Test reboot
Test reboot is to restart the TV.
Hardware events Display Display information is for development purposes.
Clear
Operation hours display 0003 In case the display must be swapped for repair, you
can reset the “Display operation hours” to “0”. So, this
one does keeps up the lifetime of the display itself
(mainly to compensate the degeneration behaviour).
Test setting Digital information QAM modulation: 64-QAM Display information is for development purposes.
Symbol rate: 23:29
Original network ID: 12817
Network ID:12817
Transport stream ID: 2
Service ID: 3
Hierarchical modulation: 0
Selected video PID: 35
Selected main audio PID: 99
Selected 2nd audio PID: -1
Install start frequency 000 Install start frequency from 0 MHz
Install end frequency 999 Install end frequency as 999 MHz
Default install frequency
Installation Digital only Select Digital only or Digital + Analogue before instal-
lation.
Digital + Analogue
Development file ver-
sions
Development 1 file version Display parameters DISPT 4.0.8.11 Display information is for development purposes.
Acoustics parameters ACSTS 3.0.6.1
PQF - Fixed settings 1
“4.54.34.32.34”
PQS - Profile set 1 “4.57.34.32.34”
PQU - User styles 1 “4.56.34.32.34”
Development 2 file version 12NC one zip software Display information is for development purposes.
Initial main software
NVM version Q5431_0.4.3.0
Flash units SW Q5431_0.16.48.24
Upload to USB Channel list To upload several settings from the TV to an USB
stick
Personal settings
Option codes
Display-related alignment
History list
Download from USB Channel list To download several settings from the USB stick to
the TV.
Personal settings
Option codes
Display-related alignment
Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description
